Accucold VT65ML7BIDPLADA Manual
Læs nedenfor 📖 manual på dansk for Accucold VT65ML7BIDPLADA (32 sider) i kategorien Fryser. Denne guide var nyttig for 63 personer og blev bedømt med 5.0 stjerner i gennemsnit af 32 brugere
Side 1/32
Write Model & Serial No. here:
Écrivez les numéros de modèle et série ici :
Model: ____________________________
Ser.No:____________________________
MEDICAL FREEZERS / CONGÉLATEURS MEDICAUX
s / Model Modèles CM405
CM411L
CM421BL
Instruction Manual / Mode d’emploi
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS
AVANT UTILISATION, S'IL VOUS PLAÎT LIRE ET SUIVRE LES RÈGLES DE SÉCURITÉ ET
INSTRUCTIONS DE FONCTIONNEMENT
FELIX STORCH, INC.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
VT65M, VT65ML series
(including BI and ADA models /
y compris les modèles BI et ADA ),
ALF620, ALF620BI,
ALF620L, ALFB621
1
IMPORTANT SAFEGUARDS
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential
hazards that can kill or injure you and others. All safety messages will
follow the Safety Alert Symbol and either the w o ” ” rd DANGER or
“ ”. WARNING
D ANGER means that failure to heed this
safety statement may result in severe
personal injury or death.
W ARNING means that failure to heed
this safety statement may result in
extensive product damage, serious
personal injury, or death.
S s afety message will alert you to what the potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.
Before the is used, it must be properly positioned and installed as freezer
described in this manual, so read the manual carefully. To reduce the risk
of fire, electrical shock or injury when using the , follow basic prefreezer -
cautions, including the following:
• - o aPlug into a grounded 3 prong outlet. D not remove grounding prong, do not use an ad pter,
and do not use an extension cord.
• , It is recommended that a separate circuit, serving only your freezer be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
• r Never clean freezer parts with flammable fluids. These fumes can create a fire hazard o
explosion. And do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
• Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
• . Do not connect or disconnect the electric plug when your hands are wet
• Unplug the freezer or disconnect power before cleaning or servicing. Failure to do so can the
result in electrical shock or death.
• Do not attempt to repair or replace any part of your freezer unless it is specifically
recommended in this ma l. All other servicing should be referred to a qualified technician.nua
9
For Models VT65MADA, VT65MLADA, ALF620/L, ALF620BI and ALFB621
a. Take off the upper hinge cover from the door and remove the screws that hold the top
hinge.
:
b. Lift the hinge straight up to free the hinge pin from the socket in the top of the door.
c. Lift the door up away to free its bottom socket from the hinge pin.and
d. Remove the screws to the bottom hinge.
e. Remove the decorative caps from opposite side and plug the holes from the the
original side with the decorative caps.
f. Move the bottom hinge to the opposite side and tighten the screws. Use any lock
washers or nuts if they were installed in the original installation.
g. Loosely install the left hand hinge provided with your unit on the top left side of the -
unit, moving the decorative caps to the right side.
h. Replace door onto the hinge pin on the bottom hinge. Place top hinge pin into door.
Insert screws into the top hinge and tighten.
If you notice the door not hanging straight, loosen the top hinge s, adjust the door screw
until it is level and tighten the screws.
Door Handle Installation
The door has two screw holes on each side, allowing you to install a handle (included). To
do so, align the handle with the screw holes on the side you prefer. Fix the handle in place
with the included screws, then cover the screw heads with the handle seal (included).
:
Produkt Specifikationer
| Mærke: | Accucold |
| Kategori: | Fryser |
| Model: | VT65ML7BIDPLADA |
