Table of Contents

Table of Contents ...................................................................................... 1

Usage Notice.............................................................................................. 2

Precautions ........................................................................................................ 2

Introduction ............................................................................................... 4

Product Features ................................................................................................ 4

Package Overview ............................................................................................. 5

Product Overview ............................................................................................... 6

Main Unit ....................................................................................................................... 6

Control Panel ................................................................................................................ 7

Connection Ports .......................................................................................................... 8

Remote Control with Mouse Function & Laser Pointer ............................................. 9

Installation ............................................................................................... 10

Connecting the Projector ................................................................................. 10

Powering On/Off the Projector ......................................................................... 11

Powering On the Projector ........................................................................................ 11

Powering Off the projector ......................................................................................... 12

Warning Indicator ....................................................................................................... 12

Adjusting the Projected Image ........................................................................ 13

Adjusting the Projector Image Height ....................................................................... 13

Adjusting the Projector Zoom / Focus ...................................................................... 14

Adjusting Projected Image Size ................................................................................ 14

User Controls ........................................................................................... 15

Control Panel & Remote Control ..................................................................... 15

On-Screen Display Menus ............................................................................... 18

How to operate ............................................................................................................ 18

Color ............................................................................................................................ 19

Image ........................................................................................................................... 21

Management ................................................................................................................ 23

Audio ........................................................................................................................... 25

Personals .................................................................................................................... 26

Language ..................................................................................................................... 27

PIP ............................................................................................................................... 28

Appendices .............................................................................................. 29

Troubleshooting ............................................................................................... 29

Replacing the lamp .......................................................................................... 33

Specifications ................................................................................................... 34

Compatibility Modes ........................................................................................ 35

Ceiling Mount Installation ................................................................................ 36

English ...

Usage Notice

Precautions

Follow all warnings, precautions and maintenance as recom-

mended in this user’s guide to maximize the life of your unit.

Warning- Do not look into the projector’s lens when the lamp is

on. The bright light may hurt your eyes.

Warning- To reduce the risk of fire or electric shock, do not ex-

pose this product to rain or moisture.

Warning- Please do not open or disassemble the product as this

may cause electric shock.

Warning- When changing the lamp, please allow unit to cool

down, and follow all changing instructions.

Warning- This product will detect the life of the lamp itself.

Please be sure to change the lamp when it shows warn-

ing messages.

Warning- Reset the “Lamp Hour Reset” function from the On

Screen Display “Management” menu after replacing

the lamp module (refer to page 24).

Warning- When switching the projector off, please ensure the

projector completes its cooling cycle before disconnect-

ing power.

Warning- Turn on the projector first and then the signal sources.

Warning- Do not use lens cap when projector is in operation.

Warning- When the lamp reaches the end of its life, it will burn

out and may make a loud popping sound. If this

happens, the projector will not turn back on until the

lamp module has been replaced. To replace the lamp,

follow the procedures listed under “Replacing the

Lamp”.

Produkt Specifikationer

Mærke:	Acer
Kategori:	videoprojektorer
Model:	PD723
Bredde:	330 mm
Dybde:	269 mm
Højde:	100 mm
Vægt:	3400 g
Produktfarve:	Black, Grey
Lampe type:	UHP
Produkttype:	Standard kasteprojektor
Understøttede videotilstande:	1080i, 480i, 480p, 576i, 576p, 720p
Indbyggede højttaler(e):	Ja
Format til analogt signal:	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
DVI-port:	Ja
Antal USB 2.0-porte:	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Ethernet LAN:	Ingen
Strømforbrug (standby):	- W
Strømforbrug (typisk):	384 W
Markedspositionering:	Præsentation
Sammensat videoindgang:	1
Understøttede billedformater:	4:3, 16:9
Støjniveau:	28 dB
Fjernbetjening inkluderet:	Ingen
Strømkilde:	Vekselstrøm
Placering:	Desktop
Full HD:	Ingen
Antal indbyggede højttalere:	2
Antal farver:	16,78 millioner farver
Lyd (L, R) indgang:	1
Kontrastforhold (typisk):	2000:1
Horisontal scanningsområde:	31.5 - 100 kHz
Antal VGA-porte (D-sub):	1
Brændviddeområde:	- mm
Projektor lysstyrke:	3100 ANSI lumens
Projektionsteknologi:	DLP
Projektor indbygget opløsning:	XGA (1024x768)
Skærmstørrelse kompatibilitet:	25 - 300 "
Projiceringsafstand:	1.2 - 12 m
Vertikalt scanningsområde:	43 - 120 Hz
RS-232-porte:	1
Levetid for lyskilde:	2000 t
Lampeeffekt:	250 W
Lyskilde type:	Lampe
Antal af S-video-indgange:	1
Seriel grænsefladetype:	RS-232
Digital trapezkorrektion:	+/-16°
