RCB736D7MB User Manual
Freezer - Fridge
EN
USER
MANUAL
Manuale per l’uso
Congelatore - Frigorifero
IT
Bedienungsanleitung
Kühl-Gefrierkombination
DE
Manuel d’utilisation
Congélateur – Réfrigérateur
FR
EN -2-
EN FIRE Warning; Risk of fire / flammable materials
EN -3-
INDEX
BEFORE USING THE APPLIANCE ...................................................... 6
General warnings 6 .............................................................................................
Old and out-of-order fridges or freezer 10 ...........................................................
Safety warnings 10 ..............................................................................................
Installing and operating your fridge freezer .................................................... 11
Before Using your Fridge 12 ...............................................................................
Dimensions 13 .....................................................................................................
THE VARIOUS FUNCTION AND POSSIBILITIES ............................. 14
Information about New Generation Cooling Technology 14 ................................
Display and Control Panel 15 ..............................................................................
Operating Your Fridge Freezer 15 .......................................................................
High temperature alarm [for selected models only] 15 .................................................
Super Freeze Mode 16 ................................................................................................
Super Cool Mode 17 ....................................................................................................
Economy Mode 17 .......................................................................................................
Holiday Mode 18 ..........................................................................................................
Drink Cool Mode 18 .....................................................................................................
Screen Saver Mode 19 ................................................................................................
The Child Lock Function 19 .........................................................................................
Door Open Alarm Function ......................................................................................19
Temperature Settings 20 .....................................................................................
Freezer Temperature Settings .................................................................................20
Cooler Temperature Settings ..................................................................................20
Temperature Adjustment Warnings ................................................................ 21
Temperature indicator 22 .....................................................................................
Accessories 23 ....................................................................................................
Ice Tray ...................................................................................................................23
The Freezer Box 23 .....................................................................................................
Extra Chill Drawer 23 .................................................................................................
The Fresh Dial 24 .........................................................................................................
CustomFlex 24 .............................................................................................................
ARRANGING FOOD IN THE APPLIANCE ......................................... 25
Refrigerator compartment 25 ..............................................................................
Freezer compartment 26 .....................................................................................
CLEANING AND MAINTENANCE ....................................................... 29
Defrosting 30 ................................................................................................................
EN -4-
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION .............................................................................................. 30
Repositioning the Door 30 ...................................................................................
BEFORE CALLING YOUR AFTER SALES SERVICE ...................... 31
Hints for Energy Saving 34 ..................................................................................
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ... 35
TECHNICAL DATA ................................................................................ 36
INFORMATION FOR TEST INSTITUTES ........................................... 36
EN -5-
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading to
get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
EN -7-
If your appliance uses R600a as a refrigerant (this information
will be provided on the label of the cooler) you should take care
during transportation and installation to prevent the cooler
elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your fridge away
from open flames or heat sources and ventilate the room where
the appliance is located for a few minutes.
• Keep all packaging away from children and dispose of it
appropriately.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
• This appliance is for storing food and beverages only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualified persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes or 10 amperes
according to country where the product will be sold. If there
is no such socket in your house, please have it installed by
an authorized electrician.
EN -9-
• Store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.
• Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making ice cream and making ice
cubes.
• One-, two- and three-star compartments are not suitable for
the freezing of fresh food.
• If the refrigerating appliance is left empty for long periods,
switch off, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.
Service
• To repair the appliance contact the Authorised Service Centre.
Use original spare parts only.
• Please note that self-repair or nonprofessional repair can
have safety consequences and might void the guarantee.
• The following spare parts will be available for 7 years after
the model has been discontinued: thermostats, temperature
sensors, printed circuit boards, light sources, door handles,
door hinges, trays and baskets.
• Please note that some of these spare parts are only available
to professional repairers, and that not all spare parts are
relevant for all models.
• Door gaskets will be available for 10 years after the model
has been discontinued.
EN -10-
Old and out-of-order fridges or freezer
• If your old fridge or freezer has a lock, break or remove the lock before discarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges.
Disposal of your old appliance
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city office, your household
waste disposal service or the shop where you purchased the product.
Notes:
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specified purposes. It is not suitable for commercial or common
use. Such use will cause the guarantee of the appliance to be cancelled and our company
will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing
foods. It is not suitable for commercial or common use and/or for storing substances
except for food. Our company is not responsible for the losses to be occurred in the
contrary case.
Safety warnings
• Do not connect your fridge freezer to the mains electricity supply using
an extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by adults. Do not allow children to
play with the appliance or hang off the door.
• Never touch the power cord/plug with wet hands. This may cause a short
circuit or electric shock.
• Do not place glass bottles or cans in the ice-making compartment as
they will burst when the contents freeze.
• Do not place explosive or flammable material in your fridge. Place drinks
with high alcohol content vertically in the fridge compartment and make
sure their tops are tightly closed.
EN -12-
Before Using your Fridge
• When using your fridge for the first time, or after transportation, keep it
in an upright position for at least 3 hours before plugging into the mains.
This allows efficient operation and prevents damage to the compressor.
• Your fridge may have a smell when it is operated for the first time. This is
normal and the smell will fade away when your fridge starts to cool.
Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this product and spare part lamps sold separately: These
lamps are intended to withstand extreme physical conditions in household appliances,
such as temperature, vibration, humidity, or are intended to signal information about the
operational status of the appliance. They are not intended to be used in other applications
and are not suitable for household room illumination.
EN -13-
Dimensions
3 the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air, plus
the space necessary to allow
door opening to the minimum
angle permitting removal of all
internal equipment
Overall dimensions 1
H1* mm 2010
W1 mm 595
D1 mm 650
Space required in use 2
H2 mm 2050
W2 mm 600
D2 mm 718
1 the height, width and depth of the
appliance without the handle
* including the height of the top
hinge (10 mm)
2 the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air
Overall space required in use
3
W3 mm 913
D3 mm 1158
H1
H2
W1
D1
W2
D2
D3
90o
W3
EN -14-
THE VARIOUS FUNCTION AND POSSIBILITIES
Information about New Generation Cooling Technology
Fridges with new-generation cooling technology have a different operating
system to static fridges. Other (static) fridges may experience a build up
of ice in the freezer compartment due to door openings and humidity in
the food. In such fridges, regular defrosting is required; the fridge must
be switched off, the frozen food moved to a suitable container and the
ice which has formed in the freezer compartment removed.
In fridges with new-generation cooling technology, a fan blows dry cold
air evenly throughout the fridge and freezer compartments. The cold air
cools your food evenly and uniformly, preventing humidity and ice build-up.
In the refrigerator compartment, air blown by the fan, located at the top
of the refrigerator compartment, is cooled while passing through the gap
behind the air duct. At the same time, the air is blown out through the
holes in the air duct, evenly spreading cool air throughout the refrigerator
compartment.
There is no air passage between the freezer and refrigerator compartments,
therefore preventing the mixing of odours.
As a result, your fridge, with new-generation cooling technology, provides
you with ease of use as well as a huge volume and aesthetic appearance.
PART - 2.
EN -15-
Display and Control Panel
Operating Your Fridge Freezer
1
3
2
4
5
6
7
9
8
10
Using the Control Panel
1. It is cooler set value screen.
2. It is super cooling indicator.
3. It is freezer set value screen.
4. It is super freeze indicator.
5. It is economy mode symbol.
6. It is holiday mode symbol.
7. It is child-lock symbol.
8. It is alarm symbol.
9. Door open alarm symbol.
10. It enables the modes (economy, holiday…) to be activated if
desired.
Lighting (If available)
When the product is plugged in for the rst time, the interior lights
may turn on 1 minute late due to opening tests.
High temperature alarm [for selected models only]
The alarm goes o when you plug the appliance for the rst time.
Refrigerator compartment
The alarm goes o when the refrigerator's temperature is higher than 10°C.
During the alarm:
• the display shows blinking error code,E10
• the alarm indicator flashes,
• the acoustic alarm beeps.
Freezer compartment
The alarm goes o when the freezer's temperature is higher than -9°C.
EN -16-
Super Freeze Mode
Purpose
• To freeze a large quantity of food that cannot fit on the fast freeze shelf.
• To freeze prepared foods.
• To freeze fresh food quickly to retain freshness.
How Would It Be Used?
Press freezer set button until Super freeze symbol will be seen on the screen. Buzzer
will sound beep beep. Mode will be set.
During This Mode:
• Temperature of cooler and super cool mode may be adjusted. In this case super
freeze mode continues.
• Economy and Holiday mode can not be selected.
• Super freeze mode can be cancelled by the same operation of selecting.
Notes:
• The maximum amount of fresh food (in kilograms) that can be frozen within 24 hours is
shown on the appliance label.
• For optimal appliance performance in maximum freezer capacity, activate Super Freeze
mode 3 hours before you put fresh food into the freezer.
• At the end of this period, the fridge will sound an audible alarm notifying that it is ready.
Super freeze mode will automatically cancel after 24 hours or when the freezer sensor
temperature drops below -32 °C.
During the alarm:
• the display shows blinking error code,E09
• the alarm indicator flashes,
• the acoustic alarm beeps.
Turning o the alarm
• Press any key on the control panel to turn off the alarm. The maximum temperature
reached by the compartment appears on the display and the alarm indicator flashes
until the temperature is restored.
• Alarm beeping turns off automatically after 1 hour. Alarm indicator blinks and error code
remains on the display.
• If the appliance is back to the set temperature, the alarm turns off and the normal display
restores. Check if the food inside is not spoiled or thawed. If yes, refer to the "Thawing"
section.
Refer to the "Temperature regulation" section to set the each compartment's
temperature.
EN -17-
Super Cool Mode
Purpose
• To cool and store a large quantity of food in the fridge compartment.
• To quickly cool drinks.
How Would It Be Used?
Press cooler set button until super cool symbol will be seen on the screen. Buzzer
will sound beep beep. Mode will be set.
During This Mode:
• Temperature of freezer and super freeze mode may be adjusted. In this case
super cool mode continues.
• Economy and holiday mode can not be selected.
• Super cool mode can be cancelled by the same operation of selecting.
Economy Mode
Purpose
Energy savings. During periods of less frequent use (door opening) or absence from home,
such as a holiday, Eco program can provide optimum temperature whilst saving power.
How Would It Be Used?
• Push "MODE" button until eco symbol appears.
• If no button is pressed for 1 second. Mode will be set. Eco symbol will blink 3
times. When mode is set, buzzer will sound beep beep.
• Freezer and refrigerator temperature segments will show "E".
• Economy symbol and E will light till mode finishes.
During This Mode:
• Freezer may be adjusted. When economy mode will be cancelled, the selected
setting values will proceed.
• Cooler may be adjusted. When economy mode will be cancelled, the selected
setting values will proceed.
• Super cool and super freeze modes can be selected. Economy mode is
automatically cancelled and the selected mode is activated.
• Holiday mode can be selected after cancelling the economy mode. Then the
selected mode is activated.
• To cancel, you will just need to press on mode button.
EN -18-
Holiday Mode
How Would It Be Used?
• Push "MODE" button until holiday symbol appears
• If no button is pressed for 1 second. Mode will be set. Holiday symbol will blink
3 times. When mode is set, buzzer will sound beep beep.
• Cooler temperature segment will show "--".
• Holiday symbol and "--" will light till mode finishes.
During This Mode:
• Freezer may be adjusted. When holiday mode will be cancelled, the selected
setting values will proceed.
• Cooler may be adjusted. When holiday mode will be cancelled, the selected
setting values will proceed.
• Super cool and super freeze modes can be selected. Holiday mode is
automatically cancelled and the selected mode is activated.
• Economy mode can be selected after cancelling the holiday mode. Then the selected
mode is activated.
• To cancel, you will just need to press on mode button.
Drink Cool Mode
Purpose
This mode is used to cool drinks within an adjustable time frame.
How Would It Be Used?
• Press freezer button for 3 seconds.
• Special animation will start on freezer set value screen and 05 will blink on
cooler set value screen.
• Press cooler button to adjust the time (05 - 10 - 15 - 20 - 25 - 30 minutes).
• When you select the time the numbers will blink 3 times on screen and sound
beep beep.
• If no button is pressed within 2 seconds the time will be set.
• The countdown starts from the adjusted time minute by minute.
• Remaining time will blink on the screen.
• To cancel this mode press freezer set button for 3 seconds.
EN -19-
Screen Saver Mode
Purpose
This mode saves energy by switching off all control panel lighting when the panel
is left inactive.
How To Use?
• This mode will be activated when you press on "MODE" button for 3 seconds.
• If no button is pressed within 30 seconds when he mode is active, lights of the
control panel will go off.
• If you press any button when lights of control panel are off, the current settings
will appear on the screen, and then you can maket he adjustment as you want.
If you neither cancel screen saver mode nor press on any button in 30 seconds,
the control panel will go off again.
• To cancel screen saver mode press on "MODE" button for 3 seconds again.
• When screen saver mode is active you can also activate child lock.
• If no button is pressed within 30 seconds after child lock is activated, the lights of the
control panel will turn off. You can see latest status of settings or modes after you pres
any button. While control panel ‘s light is on, you can cancel child lock as described in
the instruction of this mode.
The Child Lock Function
Purpose
Child lock can be activated to prevent any accidental or unintentional changes being
made to the appliance settings.
Activating Child Lock
Press on freezer and cooler buttons simultaneously for 5 seconds.
Deactivating Child Lock
Press on freezer and cooler buttons simultaneously for 5 seconds.
Door Open Alarm Function
If cooler door is opened more than 2 minutes, appliance sounds ‘beep beep’ and door
open icon will be light.
EN -20-
Temperature Settings
Freezer Temperature Settings
• The initial temperature value for the freezer setting indicator is -18°C.
• Press the set freezer button once.
• When you first push this button, the last set value will blink on the screen.
• Whenever you press this button, temperature will decrease respectively.
• When you push the set freezer button until the super freeze symbol appears,
and if you do not push any other button within 1 second, super freeze will flash.
• If you continue to press it, it will restart from -16 °C.
• The temperature value selected before holiday mode, super freeze mode,
super cool mode or economy mode is activated and will remain the same when
the mode is over or cancelled. The appliance continues to operate with this
temperature value.
Cooler Temperature Settings
• Initial temperature value for the cooler setting indicator is +4 °C.
• Press the cooler button once.
• When you first push this button, the last value will appear on the cooler setting
indicator.
• Whenever you press this button, temperature will decrease respectively.
• When you push the cooler set button until the super cool symbol appears, and
if you do not push any button within 1 second, super cool will flash.
• If you continue to press the button, it will restart from +8 °C.
• The temperature value selected before holiday mode, super freeze mode,
super cool mode or economy mode is activated and will remain the same when
the mode is over or cancelled. The appliance continues to operate with this
temperature value.
Recommended Settings for the Freezer and Cooler Compartment Temperature
Freezer Compartment Cooler
Compartment Remarks
-18 oC 4 oC For regular use and best performance.
-20 oC, -22 oC or -24 oC 4 oCRecommended when environmental
temperature exceeds 30 °C.
Super Freeze mode 4 oCMust be used when you wish to freeze food in a
short period of time.
-18 oC, -20
oC, -22 oC or -24 oC 2 oC
These temperature settings must be used
when the environmental temperature is high or
if you think the refrigerator compartment is not
cool enough becuse the door is being opened
frequently.
EN -21-
Temperature Adjustment Warnings
• It is not recommended that you operate your fridge in environments colder than 10°C
in terms of its efficiency.
• Do not start another adjustment while you are already making an adjustment.
• Temperature adjustments should be made according to the frequency of door openings,
the quantity of food kept inside the fridge and the ambient temperature in the location
of your fridge.
• In order to allow your fridge to reach the operating temperature after being connected to
mains, do not open the doors frequently or place large quantities of food in the fridge.
Please note that, depending on the ambient temperature, it may take 24 hours for your
fridge to reach the operating temperature.
• A 5 minute delay function is applied to prevent damage to the compressor of your fridge
when connecting or disconnecting to mains, or when an energy breakdown occurs. Your
fridge will begin to operate normally after 5 minutes.
• Your appliance is designed to operate in the ambient temperature (T/SN = 10°C - 43°C)
intervals stated in the standards, according to the climate class displayed on the
information label. We do not recommend operating your appliance out of the stated
temperature limits in terms of cooling effectiveness.
Climate class Meaning Ambient Temperature
TTropical This refrigerating appliance is intended to be used at
ambient temperatures ranging from 16 °C to 43 °C.
ST Subtropical This refrigerating appliance is intended to be used at
ambient temperatures ranging from 16 °C to 38 °C.
NTemperate This refrigerating appliance is intended to be used at
ambient temperatures ranging from 16 °C to 32 °C.
SN Extended temperate This refrigerating appliance is intended to be used at
ambient temperatures ranging from 10 °C to 32 °C.
This appliance is intended tobe used at ambient temparature ranning from 10°C to 43°C. The
correct operation of the appliance can only be guaranteed within the specified temperature
range.
EN -22-
Temperature indicator
In order to help you better set your refrigerator, we have equipped it with a temperature
indicator located in the coldest area.
To better store the food in your refrigerator, especially in the coldest area, make sure
the message “OK” appears on the temperature indicator. If « OK » does not appear,
this means temperature has not been set properly
It may be difficult to see the indicator, make sure it is properly lit.Each time the
temperature setting device is changed, wait for the stabilisation of the temperature
inside the appliance before proceeding, if necessary, with a new temperature setting.
Please change the position of the temperature setting device progressively and wait at least
12 hours before starting a new check and potential change.
NOTE: Following repeated openings (or prolonged opening) of the door or after putting
fresh food into the appliance, it is normal for the indication “OK” not to appear in the
temperature setting indicator. If there is an abnormal build up of ice crystals of ice crystals
(bottom wall of the appliance) on the refrigerator compartment, evaporator (overloaded
appliance, high room temperature, frequent door openings), put the temperature setting device
on a lower position until compressor off periods are obtained again.
Store food in the colde area of the refrigerator.
Your foods will be better stored if you put them in the most appropriate cooling
area. The coldest area is just above the crisper.
The following symbol indicates the coldest area of your refrigerator.
To be sure to have a low temperature in this area, make sure the shelf is located
at the level of this symbol, as shown in the illustration.
The upper limit of the coldest area is indicated by the lower side of the
sticker (head of the arrow). The coldest area upper shelf must be at the
same level with the arrow head. The coldest area is below this level.
As these shelves are removable, make sure they are always at the
same level with these zone limits described on the stickers, in order
to guarantee temperatures in this area.
OK
EN -23-
Accessories
Ice Tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely frozen, you can twist the tray as shown below to remove
the ice cubes.
The Freezer Box
The freezer box allows food to be accessed more
easily.
Removing the freezer box:
• Pull the box out as far as possible
• Pull the front of the box up and out
Carry out the opposite of this operation when
refitting the sliding compartment.
Always keep hold of the handle of the box while
removing it.
Freezer boxes
Extra Chill Drawer
Ideal to preserve the taste and texture of fresh
cuts and cheese. The pull out drawer assures an
environment with a lower temperature compared
to the rest of the fridge, thanks to the active
circulation of cold air.
To remove the Chill Drawer:
• Pull the chill drawer towards you by sliding
it on the rails.
• Pull the chill drawer up from the rail and
remove it from the fridge.
Chiller shelf
(In some models)
EN -24-
The Fresh Dial
If the crisper is full, the fresh dial located in front of the
crisper should be opened. This allows the air in the crisper
and the humidity rate to be controlled, to increase the life
of food within.
The dial, located behind the shelf, must be opened if any
condensation is seen on the glass shelf.
(In some models)
CustomFlex
CustomFlex offers you the freedom to customize the space
in your refrigerator. Inside of the door there are a storage
container and mobile containers, so you can tailor the space
to your needs. The containers are even removable, so you
can remove them from the refrigerator for easy access.
Visual and text descriptions in the accessories section may vary according
to the model of your appliance.
Fresh dial
(In some models)
EN -26-
Food Maximum storage time How and where to store
Bottled products e.g.
milk and yoghurt
Until the expiry date
recommended by the
producer
On the designated door shelf
Eggs 1 month On the designated egg shelf
Cooked food 2 Days All shelves
Freezer compartment
• Freezer compartment is the one marked with .
• The freezer is used for storing frozen food, freezing fresh food, and making ice cubes.
• Use the fast freezing shelf to freeze home cooking (and any other food which needs to
be frozen quickly) more quickly because of the freezing shelf’s greater freezing power.
Fast freezing shelf is the drawer from the top of the freezer compartment.
• For freezing fresh food; wrap and seal fresh food properly, that is the packaging should
be air tight and shouldn’t leak. Special freezer bags, aluminum foil polythene bags and
plastic containers are ideal.
• Do not store fresh food next to frozen food as it can thaw the frozen food.
• Before freezing fresh food, divide it into portions that can be consumed in one sitting.
• Consume thawed frozen food within a short period of time after defrosting
• Never place warm food in the freezer compartment as it will thaw the frozen food.
• Always follow the manufacturer's instructions on food packaging when storing frozen
food. If no information is provided food, should not be stored for more than 3 months
from the date of purchase.
• When purchasing frozen food, make sure that it has been stored under appropriate
conditions and that the packaging is not damaged.
• Frozen food should be transported in appropriate containers and placed in the freezer
as soon as possible.
• Do not purchase frozen food if the packaging shows signs of humidity and abnormal
swelling. It is probable that it has been stored at an unsuitable temperature and that
the contents have deteriorated.
• The storage life of frozen food depends on the room temperature, the thermostat setting,
how often the door is opened, the type of food, and the length of time required to transport
the product from the shop to your home. Always follow the instructions printed on the
packaging and never exceed the maximum storage life indicated.
• The maximum amount of fresh food (in kg) that can be frozen in 24 hours is indicated
on the appliance label.
NOTE: If you attempt to open the freezer door immediately after closing it, you will find that it will
not open easily. This is normal. Once equilibrium has been reached, the door will open easily.
Important note:
• Never refreeze thawed frozen food.
• The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar,
assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.)
changes and they assume a strong taste when they are stored for a long period of time.
EN -27-
Therefore, add small amounts of spices to food to be frozen, or the desired spice should
be added after the food has thawed.
• The storage time of food is dependent on the type of oil used. Suitable oils are margarine,
calf fat, olive oil and butter. Unsuitable oils are peanut oil and pig fat.
• Food in liquid form should be frozen in plastic cups and other food should be frozen in
plastic folios or bags.
The table below is a quick guide to show you the most efficient way to store the major
food groups in your freezer compartment.
Meat and sh Preparation Maximum storage time
(months)
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/
salami
Should be kept packaged even if it has a
membrane 1 - 3
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild
boar In 2.5 kg portions or as llets 6 - 8
Freshwater sh
(Salmon, Carp,
Crane, Catsh)
After cleaning the bowels and scales of the
sh, wash and dry it. If necessary, remove the
tail and head.
2
Lean sh (Bass,
Turbot, Flounder) 4
Fatty shes (Tuna,
Mackerel, Bluesh,
Anchovy)
2 - 4
Shellsh Clean and in a bag 4 - 6
Caviar In its packaging, or in an aluminium or plastic
container 2 - 3
Snails In salty water, or in an aluminium or plastic
container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after
defrosting, it must not be re-frozen.
EN -28-
Vegetables and Fruits Preparation Maximum storage time
(months)
String beans and
beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove the
core and boil in water 8 - 10
Spinach Wash and boil in water 6 - 9
Cauliower
Remove the leaves, cut the heart into pieces
and leave it in water with a little lemon juice
for a while
10 - 12
Eggplant Cut into pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry,
sourberry Wash and hull the stems 8 - 12
Maximum storage
time (months)
Thawing time at
room temperature
(hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Dairy products Preparation Maximum storage
time (months) Storage conditions
Packet
(Homogenized) Milk In its own packet 2 - 3 Pure Milk – in its own
packet
Cheese - excluding
white cheese In slices 6 - 8
Original packaging may
be used for short-term
storage. Keep wrapped in
foil for longer periods.
Butter, margarine In its packaging 6 -
EN -29-
CLEANING AND MAINTENANCE
Disconnect the unit from the power supply before cleaning.
Do not wash your appliance by pouring water on it.
Do not use abrasive products, detergents or soaps for cleaning the
appliance. After washing, rinse with clean water and dry carefully. When
you have finished cleaning, reconnect the plug to the mains supply with dry
hands.
• Make sure that no water enters the lamp housing and other electrical components.
• The appliance should be cleaned regularly using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately by hand with soap and water.
Do not wash accessories in a dish washer.
• Clean the condenser with a brush at least twice a year.
This will help you to save on energy costs and increase
productivity.
The power supply must be disconnected during cleaning.
PART - 4.
EN -30-
Defrosting
Your refrigerator performs automatic defrosting. The water formed as a
result of defrosting passes through the water collection spout, flows into
the vaporisation container behind your refrigerator and evaporates there.
• Make sure you have disconnected the plug of your refrigerator
before cleaning the vaporisation container.
• Remove the vaporisation container from its position by removing
the screws as indicated. Clean it with soapy water at specific time
intervals. This will prevent odours from forming.
Evaporating
tray
Replacing LED Lighting
To replace any of the LEDs, please contact the nearest Authorised Service Centre.
Note: The numbers and location of the LED strips may change according to the model.
TRANSPORTATION AND CHANGING OF
INSTALLATION POSITION
Transportation and Changing Positioning
• The original packaging and foam may be kept for re-transportation (optional).
• Fasten your appliance with thick packaging, bands or strong cords and follow the
instructions for transportation on the packaging.
• Remove all movable parts (shelves, accessories, vegetable bins, and so on) or fix them
into the appliance against shocks using bands when re-positioning or transporting.
Always carry your appliance in the upright
position.
PART - 5.
Repositioning the Door
• It is not possible to change the opening direction of your appliance door if door handles
are installed on the front surface of the appliance door.
• It is possible to change the opening direction of the door on models without handles and
models with handles mounted on the sides.
• If the door-opening direction of your appliance can be changed, contact the nearest
Authorised Service Centre to change the opening direction.
EN -31-
BEFORE CALLING YOUR AFTER SALES SERVICE PART - 6.
Errors
Your fridge will warn you if the temperatures for the cooler and freezer are at improper levels
or if a problem occurs with the appliance. Warning codes are displayed in the freezer and
cooler indicators.
ERROR TYPE MEANING WHY WHAT TO DO
E01
Sensor warning - Call Service for assistance as
soon as possible.
E02
E03
E06
E07
E08 Low Voltage
Warning
Power supply to the
device has dropped to
below 170 V.
- This is not a device
failure, this error helps to
prevent damages to the
compressor.
- The voltage needs to be
increased back to required
levels
If this warning continues an
authorised technician needs
to be contacted.
E09
Freezer
compartment is not
cold enough
Likely to occur after
long term power failure.
Hot food has been left
in the fridge.
First time the appliance
has been switched on.
1. Set the freezer
temperature to a colder
value or set Super Freeze.
This should remove
the error code once the
required temperature has
been reached. Keep doors
closed to improve time
taken to reach the correct
temperature.
2. Remove any products
which have thawed/
defrosted during this error.
They can be used within a
short period of time.
3. Do not add any fresh
produce to the freezer
compartment until the
correct temperature has
been reached and the error
is no longer.
If this warning continues an
authorised technician needs
to be contacted.
EN -32-
If you are experiencing a problem with your refrigerator, please check the following before
contacting the after-sales service.
Your refrigerator does not operate
Check if:
• Your fridge is plugged in and switched on
• The fuse has blown
• Is the temperature adjustment right?
• The socket is faulty. To check this, plug another working appliance into the same socket.
Your refrigerator is performing poorly
Check if:
• Is the temperature adjustment right?
• Is the door of your fridge opened frequently and left open for a long while?
• The appliance is overloaded
• The doors are closed properly
ERROR TYPE MEANING WHY WHAT TO DO
E10
Fridge
compartment is not
cold enough
Likely to occur after:
- Long term power
failure.
- Hot food has been left
in the fridge.
- First time the
appliance has been
switched on.
1. Set the fridge temperature
to a colder value or
set Super Cool. This
should remove the error
code once the required
temperature has been
reached. Keep doors
closed to improve time
taken to reach the correct
temperature.
2. Please empty the location
at the front area of air duct
channel holes and avoid
putting food close to the
sensor.
If this warning continues an
authorised technician needs
to be contacted.
E11
Fridge
compartment is too
cold
Various
1. Check is Super Cool mode
is activated
2. Reduce the fridge
compartment temperature
3. Check to see if vents are
clear and not clogged
If this warning continues an
authorised technician needs
to be contacted.
EN -36-
TECHNICAL DATA PART - 8.
The technical information is situated in the rating plate on the internal side of the appliance
and on the energy label.
The QR code on the energy label supplied with the appliance provides a web link to the
information related to the performance of the appliance in the EU EPREL database.
Keep the energy label for reference together with the user manual and all other documents
provided with this appliance.
It is also possible to find the same information in EPREL using the link https://eprel.ec.europa.eu
and the model name and product number that you find on the rating plate of the appliance.
See the link www.theenergylabel.eu for detailed information about the energy label.
INFORMATION FOR TEST INSTITUTES PART - 9.
Installation and preparation of the appliance for any EcoDesign verification shall be compliant
with EN 62552. Ventilation requirements, recess dimensions and minimum rear clearances
shall be as stated in this User Manual at PART 1. Please contact the manufacturer for any
other further information, including loading plans.
IT -38-
INDICE
PRIMA DI USARE L'ELETTRODOMESTICO ..................................... 41
Avvertenze Generali di Sicurezza 41 ..................................................................
Avvertenze di sicurezza 46 .................................................................................
Installazione e funzionamento del frigorifero 47 ..................................................
Prima di usare il frigo 48 ......................................................................................
Dimensioni 49 ......................................................................................................
USO DELL'APPARECCHIO ................................................................. 50
Informazioni sulla tecnologia di raffreddamento di nuova generazione 50 .........
Display e pannello di controllo 51 ........................................................................
Uso del frigo-congelatore 51 ...............................................................................
Allarme temperatura elevata [solo per modelli selezionati] 51 .....................................
Modalità Super Freeze (super congelamento) 52 ........................................................
Modalità Super Cool (super freddo) 53 .......................................................................
Modalità Economy (risparmio) 53 ................................................................................
Modalità Holiday (vacanza) 54 .....................................................................................
Modalità Drink Cool (bevande fresche) 54 ...................................................................
Modalità Screen Saver 55 ............................................................................................
Funzione Blocco Bambini 55 ........................................................................................
Regolazione della temperatura 56 ......................................................................
Regolazione della temperatura del congelatore 56 ......................................................
Regolazione della temperatura del frigorifero 56 .........................................................
Avvertenze riguardanti la regolazione della temperatura 57 ...............................
Spia della temperatura 58 ...................................................................................
Accessori 59 ........................................................................................................
Vaschetta per il ghiaccio .........................................................................................59
Cassetti del congelatore 59 ..........................................................................................
Scomparto freschezza extra 59 ...................................................................................
Regolatore di umidità 60 ..............................................................................................
CustomFlex 60 .............................................................................................................
CONSERVAZIONE DEGLI ALIMENTI ................................................ 61
Scomparto frigorifero 61 ......................................................................................
Scomparto congelatore 62 ..................................................................................
PULIZIA E MANUTENZIONE ............................................................... 65
TRASPORTO E RIPOSIZIONAMENTO .............................................. 66
Inversione della porta 66 .....................................................................................
IT -41-
PRIMA DI USARE L'ELETTRODOMESTICO PARTE - 1.
Avvertenze Generali di Sicurezza
Prima di installare e utilizzare l'apparecchio leggere attentamente
il manuale di istruzioni. Il produttore declina ogni responsabilità
per danni derivanti da uso improprio.
Seguire tutte le indicazioni riportate sull'apparecchio e sul
manuale di istruzioni. Quest'ultimo va conservato in luogo sicuro
in modo da poter risolvere eventuali problemi in futuro.
Questo apparecchio non è destinato all’uso come apparecchio
a muro.
Se, a causa di una diversa installazione, non vengono rispettate
le corrette esigenze di ventilazione, l'apparecchiatura funzionerà
correttamente.
AVVERTENZA: Non coprire od ostruire le aperture di
ventilazione del frigorifero.
AVVERTENZA: Non utilizzare dispositivi meccanici o altri
mezzi per accelerare lo sbrinamento, se non esplicitamente
consigliato dal costruttore.
AVVERTENZA: Non usare apparecchiature elettriche
all’interno degli scomparti per la conservazione del cibo, a meno
che non siano del tipo consigliato dal produttore.
AVVERTENZA: Non danneggiare il circuito refrigerante.
AVVERTENZA: Quando si posiziona l'apparecchio, assicurarsi
che il cavo di alimentazione non sia bloccato o danneggiato.
AVVERTENZA: Non posizionare prese di corrente portatili
multiple o alimentatori di corrente portatili multipli sul retro
dell'apparecchio.
AVVERTENZA: Per evitare l’instabilità dell’elettrodomestico,
esso deve essere fissato seguendo le indicazioni del presente
manuale di istruzioni.
IT -48-
Prima di usare il frigo
• Quando viene usato per la prima volta o dopo il trasporto, tenere il
frigorifero dritto per 3 ore, quindi collegare la spina per garantire un
corretto funzionamento. In caso contrario, il compressore potrebbe venire
danneggiato.
• Il frigorifero potrebbe emettere un cattivo odore al primo utilizzo; è normale. Non appena
inizia a raffreddarsi il cattivo odore scompare.
Illuminazione interna
AVVERTENZA!
Rischio di scarica elettrica.
• Riguardo alla/e lampadina/e all’interno di questo prodotto e alle lampadine di ricambio
vendute separatamente: Queste lampadine sono progettate per resistere a condizioni
fisiche estreme negli apparecchi domestici, quali temperatura, vibrazione, umidità, o
sono progettate per segnalare informazioni sullo stato operativo dell’apparecchio. Non
sono destinate all’uso in altre applicazioni e non sono idonee per l’illuminazione di
ambienti domestici.
IT -50-
USO DELL'APPARECCHIO PARTE - 2.
Informazioni sulla tecnologia di raffreddamento di nuova generazione
I freezer con la nuova tecnologia di raffreddamento di nuova generazione
hanno un diverso sistema di funzionamento rispetto ai freezer statici.
Nei normali freezer, l’aria umida che entra nel freezer e il vapore
acqueo emanato dal cibo, si trasforma in brina nel comparto freezer.
Per poter sciogliere questa brina, in altre parole scongelare, il frigo deve
essere scollegato. Per poter tenere al freddo i cibi durante il periodo di
sbrinamento, l’utente deve conservare il cibo altrove e l’utente deve pulire
il ghiaccio residuo e la brina accumulata.
La situazione è completamente diversa nei comparti frigo dotati della
nuova tecnologia di raffreddamento di nuova generazione. Con l’aiuto
del ventilatore, in tutto il comparto freezer viene emessa aria fredda
e secca. Come risultato dell’aria fredda soffiata facilmente in tutto il
comparto, anche negli spazi tra i ripiani, il cibo può essere congelato in
modo uniforme e corretto. E senza brina.
La configurazione del comparto frigorifero sarà simile a quella del
comparto freezer. L’aria emessa dalla ventola situata sulla parte superiore
del comparto frigo viene raffreddata mentre passa tra lo spazio dietro
la condotta d’aria. Allo stesso tempo, l’aria soffiata attraverso i fori sulla
condotta d’aria in modo che il processo di raffreddamento sia completato
con successo nel comparto frigorifero. I fori sulla condotta d’aria sono
progettati per una distribuzione uniforme dell’aria in tutto il comparto.
Poiché tra il comparto frigo e freezer non passa aria, non vengono miscelati odori.
Di conseguenza, il frigo con la tecnologia di raffreddamento di nuova generazione è facile da
utilizzare e offre un accesso ad un elevato volume e un aspetto estetico.
Produkt Specifikationer
| Mærke: | AEG |
| Kategori: | Køleskab |
| Model: | RCB736D7MB |
Har du brug for hjælp?
Hvis du har brug for hjælp til AEG RCB736D7MB stil et spørgsmål nedenfor, og andre brugere vil svare dig
Køleskab AEG Manualer
3 August 2025
3 August 2025
3 August 2025
3 August 2025
3 August 2025
3 August 2025
3 August 2025
1 August 2025
1 August 2025
1 August 2025
Køleskab Manualer
- Lec Medical
- Bompani
- Techwood
- Hoover
- Sanyo
- Coors Light
- Goddess
- Robinhood
- Luxor
- Grundig
- Emperor's Select
- Adler
- Aldi
- Beverage-Air
- Cosmo
Nyeste Køleskab Manualer
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
13 August 2025
