Side 1/6

American DJ

4295 Charter Street

Los Angeles, CA. 90058

www.americandj.com

Revised 09/02

Unpacking:

Thank you for purchasing the Epsilon™ by American DJ

Every Epsilon™ has been thoroughly tested and has been shipped in

perfect operating condition. Carefully check the shipping carton for

damage that may have occurred during shipping. If the carton appears

to be damaged, carefully inspect your  xture for any damage and be

sure all accessories necessary to operate the unit have arrived intact.

In the event damage has been found or parts are missing, please

contact our toll free customer support number for further instructions.

Please, do not return this unit to your dealer without  rst contacting

customer support.

Introduction:

The Epsilon™ is a colorful hightech effect with 32

multi-

colored, sharp beams of light that bounce up and down to the beat of

music. This unit

is part of the Advanced Drive Series (ADS). Any unit

that has the ADS logo is designed to interconnect and work together.

When several ADS effects are linked together they can form an inex-

pensive system that creates an intelligent look. This unit is best used in

multiples of four or more. For best results mix and match several ADS

units together with a fog or haze machine to enhance the beam output.

An optional MINI/C controller may be purchased separately and will

control a blackout function.

Warning!

The 1/4” phone plug on the unit is for the optional MINI/C.

Do not attempt to connect an audio signal to this jack, this will dam-

age the PC board and void your manufactures warranty!

Customer Support:

American DJ

provides a toll free customer sup-

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to 5:

00 p.m. Paci c Standard Time.

Voice:

(800) 322-6337

Fax:

(323) 582-2610

E-mail:

support@americandj.com

Caution!

There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures

warranty. In the unlikely event your unit may require service please

contact American DJ

customer support.

Epsilon™ Introduction

American DJ

www.americandj.com Epsilon™ Instruction Manual Page 2

ADVANCED

DRIVE

SERIES

User Instructions

To reduce the risk of electrical shock or  re, do not expose this unit

rain or moisture

Do not spill water or other liquids into or on to your unit

Do not attempt to operate this unit if the power cord has been fray-

ed or broken. Do not attempt to remove or break off the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and  re in case of an internal short

Disconnect from main power before making any type of connection

•

Do not remove the cover under any conditions. There are no user

serviceable parts inside

Never plug this unit in to a dimmer pack

Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall

Do not attempt to operate this unit, if it becomes damaged

This unit is intended for indoor use only, use of this product out-

doors voids all warranties

During long periods of non-use, disconnect the unit’s main power

Always mount this unit in safe and stable matter

Power cords should be routed so they are not likely to be walked

on, pinched by items placed upon or against them.

• Cleaning -The  xture should be cleaned only as recommended by

the manufacturer. See page 7 for cleaning details

Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (in-

cluding ampli ers) that produce heat.

The  xture should be serviced by quali ed service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the unit.

C. The unit has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

American DJ

www.americandj.com Epsilon™ Instruction Manual Page 3

American DJ

www.americandj.com Epsilon™ Instruction Manual Page 4

• Advanced Drive Series Lighting Effect - Units Link Together with

other Advanced Drive Series Lights via XLR In and Out

• MINI/C Blackout Controller (Sold Separately)

• 30 Rich, Sharp Beams of Multi-Colored Light

• Fan Cooled

• 2 Sound Activated Modes: Slow Sound Active or Fast Sound Active

• Master/Slave Compatible

• Includes Built-In Mounting Bracket

• Two LL-64514 120v/300w Lamps

• Volume Sensitivity Knob

Introduction..........................................................................2

Features................................................................................3

Safety Precautions...................................................................3

Operation..............................................................................5

Dip Switch Settings..............................................................6

Set-Up................................................................................7

Lamp Replacement...............................................................8

Cleaning.............................................................................9

Trouble Shooting.............................................................9

Warranty............................................................................10

Specifications...........................................................................11

Epsilon™ Warranty Registration

The Epsilon™

carries a one year (365 days) limited warranty. Please

fill out the enclosed warranty card to validate your purchase. All

returned service items whether under warranty or not, must be

freight pre-paid and accompany a return authorization (R.A.) num-

ber. The R.A. number must be clearly written on the outside of the

return package. A brief description of the problem as well as the R.A.

number must also be written down on a piece of paper and included

in the shipping container. If the unit is under warranty, you must pro-

vide a copy of your proof of purchase invoice. You may obtain a R.A.

number by contacting customer support at (800) 322-6337.

Epsilon™ Features

Epsilon™ Contents

Epsilon™ Safety Precautions

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Epsilon™ General Instructions
