CONTROL PANEL

Electronic Instructions

Lectern

Your lectern may not contain all of the electronic modules as shown and explained here. Speakers and lectern

microphone are pre-wired. To install gooseneck microphone, pull out connector from microphone holder and

snap microphone into connector. Install back into microphone holder.

NEED HELP? Call 800-267-5486

16 CHANNEL WIRELESS RECEIVER

1. MIC 1: Adjusts volume level of gooseneck microphone

on reading table.

2. MIC 2: Adjusts volume level of microphone plugged

into the MIC 2 input jack on amplier.

3. AUX: Controls output level of device that is plugged

into the L/R RCA jacks.

4. This control cuts or boosts the bass level. BASS:

5. This control cuts or boosts the treble level. TREBLE:

RECEIVER / TRANSMITTER SETUP:

· The receiver has its own POWER / VOLUME Control (G).

Turn Power On. A Frequency Channel will appear in the Chan-

nel Display (A). Press Select Buttons ( ) to select a channel. E

Channel number must match channel number on wireless

transmitter.

· The transmitter bodypack is operated by 1 - "AA" 1.5 Volt alka-

line battery. Slide o battery cover and install battery as (H)

shown. Make certain the battery is fully seated in its compart-

ment so the cover slides in place easily. Battery life with alka-

line batteries is approximately 8 hours of operating time.

· Select a channel (1-16) on side panel using the supplied (I)

screw driver to select channel number. Channel selected

should match channel on receiver. When transmitter and

receiver are set to correct channel the RF indicator (B) will

glow red when transmitter is turned on.

· Plug the Lapel microphone into the Mic Input Jack (K). The

microphone can be clipped to a necktie or other clothing,

using the supplied clip. The lapel mic should be placed under

the chin, as close to the center of the body as possible.

· Slide the power switch to the position (the ON/OFF (J) ON

LED indicator light will illuminate green). Replace batteries

when this LED turns red.

● MUTE LEVEL (F) is set at half way mark when it leaves the

factory. If speaker sound is breaking up, turn level clockwise

with small screwdriver until condition improves.

· Channel Display (A)

· RF - Radio Frequency Indicator (B)

· AF - Audio Frequency Indicator (C)

· ASC / IR Auto Channel Select (Handheld Only) (D)

· Select Buttons - Manual Channel Selection (E)

· Mute Level Adjustment (F)

· Volume Control (G)

C D

1 2 3 4 5

Wireless Transmitter - Bodypack

Battery Cover

Channel Selector

Top Panel

If you are using the AmpliVox S1695 Wireless Handheld Microphone Transmitter, screw o the lower bottom section of mi-

crophone and insert 2 - "AA" 1.5 Volt alkaline batteries.

IMPORTANT: Because the microphone has an AUTO SYNC function, you rst select channel you wish to use on the re-

ceiver. Then press the ASC button ( ), the IR light will start to ash. Turn on microphone and point end ( ) of microphone D 6

at the ashing IR light on receiver and the microphone will auto sync to the same channel as selected on the receiver.

WIRELESS HANDHELD MICROPHONE MODEL S1695 —

BATTERIES

1. Hold the body of microphone in hand and twist o

bottom section of microphone.

2. Insert two AA batteries.“ ”

3. Twist bottom section back on to microphone.

BATTERY STATUS

The life expectancy of the two batteries is about 10

hours. When the “BATTERY” symbol on the display

screen keeps ashing the batteries should be replaced

immediately.

· TURN ON MICROPHONE: Push and hold the

“POWER/MUTE ”(3) button until LCD screen

lights up.

· TO MUTE: POWER/MUTE Press “ ” button twice

to MUTE. Channel number will ash when muted.

Press button again twice to remove “MUTE . ”

· TURN OFF MICROPHONE: Push and hold the

“POWER/MUTE ”(3) button for 2 seconds to turn

microphone “OFF”.

· SELECT CHANNEL (Manual): Press and hold

the (4) button for 2 seconds until you “SELECT ”

only see the word Channel and channel number.

To change channel, when ashing, press the

“SELECT” (4) button until you reach the desired

channel. Flashing will stop after 10 seconds and

channel is now set.

· LOCK / UNLOCK CHANNEL: Push the

(3) button and “POWER/MUTE ”“SELECT ”

button at the same time to lock or unlock channel.

When locked, channel cannot be changed.

“LOCKED ”symbol appears in upper left-hand

corner.

Functions

1) Interchangeable Microphone Head

2) LCD Screen

3) Power / Mute Control Switch

4) Select Button

5) Microphone Input Sensitivity Ad-

justment—is used to set the gain of

microphone. If you are a soft talking

speaker you will need to turn the control

counter clockwise. Turn clockwise if you

are a loud talker. Use plastic screwdriver

that is supplied.
