Side 1/2

QUICKSTARTGUIDE



MA‐AGLK‐07

AngledMountKitforModeroG5Series

Wall‐mountTouchPanels&SchedulingPanels



MA‐AGLK‐07AngleMountKits

TheMA‐AGLK‐07AngleMountKits(FIG.1)aredesignedtomountModeroG5SeriesWall

MountTouchPanelsandAMXRoomBookSchedulingPanels(7”)intostandardsizedsingle

anddoublegangboxesintheUS,EU,UKandAustralia.PleasenotetheAMK2AnyMountKit

maybeshowninim

ages,butprocedureisthesamefortheanglemount.



FIG. 1

MA‐AGLK‐07



ModelsAvailable/PanelCompatibility

The Angle Mount Kit is available to accommodate 7” Modero G5 Series (wall mount,

landscape), 7” Modero S Series, AMX Acendo Book and AMX RoomBook SeriesScheduling

TouchPanels:



MODELSAVAILABLE/PANELCOMPATIBILITY

AngleMountKit



Forusewith:



MA‐AGLK‐07



(FG2265‐35)



• MD‐702(FG5969‐55BL):7"ModeroG5SeriesLandscapeWallMountTouch

Panel



• MSD‐701‐L2(FG2265‐32):7"ModeroSSeriesLandscapeWallMountTouch

Panel



• ACB‐2107(FG4221‐07):7”AMXAcendoBookSchedulingTouchPanel

• RMBK‐701(FG2265‐37):7”AMXRoomBookSchedulingTouchPanel



“AGLK”AngleMountKits

TheMA‐AGLK2‐07AngleMountKitsareintendedforusewithModeroG5touchpanels,as

wellassecond‐generation“‐L2”ModeroSSeries(Landscape/WallMount),andAMXAcendo

Book&AMXRoomBookSchedulingtouchpanels.Theyconvenientlyplacethetouchpanel

ata15°upwardangleforeasyrea

dability,idealformountingatalowerheighttocomply

withmanyADArequirements.

Pleasenotethesecannotbeusedupsidedowntocreatea15°downwardanglemount.



ProductSpecifications

PRODUCTSPECIFICATIONS

DimensionsHWD:



• MA‐AGLK‐07:3.97”x6.74”x1.76”(100.84mmx171.20mmx44.70mm)



Weight:



• MA‐AGLK‐07:0.1lbs(45.36g)



Included



Accessories:



• BackBox(5107643‐00)



• Gasket,Foam(66‐2265‐29)



• Screw,M3.5X30mm,PFH,ClearZinc(4)(80‐1620‐04)



• Screw,#6‐32X1.25,PFH,TypeF,ClearZinc(4)(80‐1700‐09)



InstallationoftheAngleMountKit

TheAngleMountKitsaredesignedtoutilizeexistingornewlyinstalledgangboxes,withanew

backboxtoreplacethebackboxincludedwiththetouchpanel.ToinstallanAngleMountKit

anditsaccompanyingtouchpanel:



1. Beforestartingtheinstallation,ensurethatEthernetcablehasbeenpulledtothegang

box,andthatallappropriatePowerOverEthernet(PoE)injectorshavebeenconnected

tothecablegoingtothegangbox.



2. Ifthegangboxalreadyhasanexistingfixtureordeviceinstalledinit,removethefixture

ordevicetoexposethegangbox(FIG.2).



3. PulltheEthernetcableintothegangbox,makingsurethatthemaleRJ‐45connectoris

accessiblewithinthegangbox.



4. Matchthescrewconnectorholesonthegangboxwiththeholesinthebackbox(FIG.

3).



• TheAnyMountKitbackboxhasmultipleholestoallowforsingleordoublegangbox

design,andforstandardgangboxdesignsfromtheUS,UK,EUandAustralia.



• Examinehowthebackboxrestsonthegangbox‐lookforgapsbetweenthebackbox

andthewallsurface.



FIG. 3

TESTINGTHEALIGNMENTOFTHEBACKBOXSCREWHOLES.



• Ifthegapbetweenthewall andthebackbox isexcessive,orif theinstallationofthe

backboxexposestoomuchofthegangbox,youmayapplytheoptionalfoamgasket

(66‐2265‐29)tothebackofthebackbox.Peeltheadhesivebackingoffth

egasketand

carefullyapplyittothebackboxsurface(FIG.4).



•



FIG. 4

APPLYINGTHEOPTIONALFOAMGASKETTOTHEBACKBOX.



5. Oncethepropermountingpositionofthebackboxisconfirmed,attachthebackboxto

thegangbox,usingeitherthescrewsusedwiththeoriginalfixtureordeviceorwiththe

includedscrewsintheAngleMountKit(FIG.5).



WARNING:Becarefulnottoover‐tightenthescrews‐thiscanbowordamagethe

backbox.



15

º

4.2”

2”

7”



FIG. 2 



Gangbox

Wallsurface

Adhesivebacking

Gasket



FIG. 5

INSTALLINGTHEBACKBOXTOTHEGANGBOX.



6. Afterinstallingthebackbox,inspectthebackbox’splacement.



Note:Ifnecessary,thebackboxcanberemovedandthefoamgasketinstalled.



7. PullenoughslackontheEthernetcablethroughthebackboxtoallowthecabletoreach

thetouchpanel’sRJ45connector(FIG.6).



FIG. 6

ACCESSINGTHEETHERNETCABLETHROUGHTHEBACKBOX.



8. Removethetouchpanel’sbackboxtoaccessthebackofthepanel.



9. Inserteachconnectorintoitscorrespondinglocationalongthebackofthetouchpanel.



Note:Formoreinformationonconnections,pleaserefertotheInstallationHardware

ReferenceManualforthepanelbeinginstalled,availablefromwww.amx.com.



10. Testtheincomingwiringbyattachingthepanelconnectionstotheirterminallocations

andapplyingpower.



Note:Verifythatthepanelisreceivingpowerandfunctioningproperlytoprevent

repetitionoftheinstallation.



11. Latchthepanelontothetophooksonthebackboxandrotateitdown(FIG.7).



FIG. 7

HOOKINGTHETOPOFTHETOUCHPANELONTHEBACKBOX.



12. Pressgentlyandevenlyonthesurfaceofthetouchpaneluntilthepanellocksintoplace

(FIG.8).



FIG. 8

LOCKINGDOWNTHEBOTTOMOFTHETOUCHPANELONTOTHEBACKBOX.



WARNING:ifyouseeagapbetweenthepanelandthebackbox,orfeelanybindingwhile

lockingdownthepanel,stopimmediatelyandverifythatnocablesorotheritemsareinthe

way.Donotforcethepanelintoposition,asthiscancausedamagetothetouchscre

enor

thepanelelectronics.



RemovingtheTouchPanel

Inordertoaccessthebackofthetouchpanel,suchastoinstallaUSBconnectionforfirmware

upgrades,thedevicemayneedtoberemovedfromthebackbox.Toremovethetouchpanel:



1. Fromthebottom,pullgentlyoutwardfromthebackbox.Gentlyrockthepanelback

andforthtofreethebottomfromthebackbox.



2. Rotateituptoreleasethetoplatchhooks,andcarefullypullthedevicefreefromthe

backbox.Takecarenottodamageorpulltheconnectionsonthebackofthedevice,

ortopullthebackboxfromthegangbox.



AdditionalDocumentation

Thefollowingrelatedproductdocumentsareavailabletoview/downloadatwww.amx.com:



• Forinformation oninstallingModeroG5SeriesTouchPanels,refertotheInstallation

HardwareReferenceManual–ModeroG5Series.



• SpecificationdrawingsoftheMA‐AGLK‐07AngleMountKits.



©2020Harman.Allrightsreserved.Modero,ModeroG5Series,AMX,AVFORANITWORLD,HARMAN,andtheirrespectivelogosareregistered

trademarksofHARMAN.Oracle,Javaandanyothercompanyorbrandnamereferencedmaybetrademarks/registeredtrademarksoftheir

respectivecompanies.



AMXdoesnotassumeresponsibilityforerrorsoromissions.AMXalsoreservestherighttoalterspecificationswithoutpriornoticeatanytime.



TheAMXWarrantyandReturnPolicyandrelateddocumentscanbeviewed/downloadedatwww.amx.com.



3000RESEARCHDRIVE,RICHARDSON,TX75082|AMX.com|800.222.0193|469.624.8000|+1.469.624.7400|fax469.624.7153



 AMX(UK)LTD,AMXbyHARMAN‐UnitC,AusterRoad,CliftonMoor,York,YO304GDUnitedKingdom|+441904‐343‐100|www.amx.com/eu/ 



5108277-00 REV: A



Thenrotatethebottomedge

ofthepanelintoplace

1.Latchthetophookson

thepanelontothebackbox

LastRevised:2020‐12‐04
