QUICK START GUIDE

VARIA- -ACS 80F 8” Fixed Tabletop Stand

VARIA- -ACS 100F 10.1” Fixed Tabletop Stand

Overview

The Varia -Fixed Tabletop stands are designed for 8” VARIA 80 & 10.1” VARIA-100

Touch Panels, -and give them a sturdy & stylish fixed angle tabletop solution

that’s reminiscent of AMX’s Modero touch panel family.

FIG. 1 Varia Touch Panel on Fixed Tabletop Stand

Model Availability & Compatibility

FIXED TABLETOP STANDS

VARIA- - ACS 80F

(AMX- UMT0801) VARIA- - 1 80 Touch Panel (AMX UTP08 1)

VARIA- - ACS 100F

(AMX- UMT1001)

VARIA- - 1 100 Touch Panel (AMX UTP10 1)

V - - 1 ARIA 100N Touch Panel (AMX UTP10 1N)

Other Models a Av ilable

ANGLE- SELECT TABLETOP STANDS

VARIA- - A ACS 810

(AMX- ) UMT8111

V - - ) ARIA 80 Touch Panel (AMX UTP0811

V - - ARIA 100 Touch Panel (AMX UTP1011)

V -1 -ARIA 00N Touch Panel (AMX UTP1011N)

VARIA- -1 A ACS 50

(AMX- UMT1511)

V -15 - ARIA 0 Touch Panel (AMX UTP1511)

V -15 - ARIA 0N Touch Panel (AMX UTP1511N)

Installation

Varia Fixed Tabletop Stands are easily installed with the supplied hardware and

a Philips- head screwdriver.

1. Place the panel face- down on a soft cloth, and orient the panel so

that the top of the touch panel is closest to you.

FIG. 2 Varia Touch Panel, rear

2. If they are installed, remove two screws from the lower back cover.

Screw L ocations

FIG. 3 Rear cover screws, if installed

3. Place your thumbs push the on the rectangular access holes, and

lower cover away from you. The lower cover can then be placed

aside; it is not used with the Fixed Tabletop Stands.

FIG. 4 R ear cover removal

4. Rotate the panel back around so the bottom is closest to you.

5. On the tabletop stand, remove the black plastic cover by sliding it

away from the aluminum base. It is held on by magnets. Then

unscrew the rubber pads from the base.

6. Install the aluminum base on the back o the touch panel.

Note: In most circumstances, the networking cable can be routed in

after base installation. However, category cable bulky s h wit strain

relief and/or hoods over the RJ-45 connector may need to be installed

before the aluminum base.

FIG.5 Fixed Tabletop Stand, aluminum base, underneath

7. Attach the base with the four (4) supplied screws.

Top

QUICK START GUIDE

VARIA- -ACS 80F 8” Fixed Tabletop Stand

VARIA- -ACS 100F 10.1” Fixed Tabletop Stand

trademarks of HARMAN. Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their respective

companies.

AMX does not assume responsibility for errors or omissions. AMX also reserves the right to alter specifications without any prior notice at time. The

AMX Warranty and Return Policy and related documents be viewed/downloaded can at www.amx.com .

3000 RESEARCH DRIVE, RICHARDSON, TX 75082 800.222.0193 | AMX.com | 469.624.8000 +1.469.624.7400 | | fax 469.624.7153

1000374845 D REV:

Last Revised 2023-08-18

8. Attach the left & right rubber pads to the bottom of the base, and

then stand the unit upright to expose the screw holes. Attach with

the five (5) supplied screws.

Screw L ocations

FIG. 6 Fixed Tabletop Stand, aluminum base, above

FIG. 7 Fixed Tabletop Stand, base bl with assem ed rubber pads

Note: Certain screwdriver handles may interfere with the rear of

the touch panel, - especially the VARIA 80, when attaching screws

that hold the rubber pads. Take care not to make contact.

FIG. 8 Varia Touch Panel, caution

9. Route your through the opening and plug into the networking cable

back of the panel. tuck your cable into the cable management Then

tabs attached to the rubber pad.

10. Align the black plastic cover with the tabs & slots on the aluminum

base. Slide the cover on, and it will seat automatically with its built-

in magnets.

Alignment Tab Locations

Magnets

FIG. 9 Fixed Tabletop Stand, black plastic cover

FIG. 10 Varia Touch Panels on Fixed Tabletop Stand, various angles

Removing

To remove the panel, follow the installation directions in reverse.
