QUICK START GUIDE
VARIA- -ACS 810A 8” & 10.1” Angle-Select Tabletop Stand
VARIA- -ACS 150A 15.6” Angle- Select Tabletop Stand
Overview
The Angle Varia - Select Tabletop stands are designed for 8” VARIA- , 1 80 0.1”
VARIA VARIA- 100, & 15.6” -150 , Touch Panels and give them a sleek & modern
tabletop solution that can be installed at one of three angles to best suit the
users’ needs.
FIG. 1 Varia - Touch Panel on Angle Select Tabletop Stand
Model Availability & Compatibility
ANGLE- SELECT TABLETOP STANDS
VARIA- - A ACS 810
(AMX- ) UMT8111
V - - ) ARIA 80 Touch Panel (AMX UTP0811
V - - ARIA 100 Touch Panel (AMX UTP1011)
V -1 -ARIA 00N Touch Panel (AMX UTP1011N)
VARIA- -1 A ACS 50
(AMX- UMT1511)
V -15 - ARIA 0 Touch Panel (AMX UTP1511)
V -15 - ARIA 0N Touch Panel (AMX UTP1511N)
Other Models Available
FIXED TABLETOP STANDS
VARIA- - ACS 80F
(AMX- UMT0801) VARIA- - 80 Touch Panel (AMX UTP0811)
VARIA- - ACS 100F
(AMX- UMT1001)
VARIA- - 100 Touch Panel (AMX UTP1011)
VARIA- -100N Touch Panel (AMX UTP1011N)
Installation
Varia Fixed Tabletop Stands are easily installed with the supplied hardware and
a Philips- head screwdriver.
1. Place the panel face-down on a soft cloth and arrange the panel so
that the top of the touch panel is closest to you.
FIG. 2 Varia Touch Panel, rear
2. If they are installed, remove two small screws from the lower cover.
Screw L ocations
FIG. 3 Rear cover screws, if installed
3. Place your thumbs push the on , the rectangular access holes and
lower cover away from you. Do not discard, this will be reinstalled
later.
FIG. 4 Rear Cover Removal
4. Rotate the panel back around so the bottom is closest to you.
5. Route the networking cable through the base first, and then plug the
RJ- 45 connector into the back of the touch panel.
FIG. 5 Angle-Select Tabletop Stand Base
6. Reinstall the lower cover, first snapping it into place. Optionally, two
small screws supplied in the hardware accessory bag may be
installed. Make sure the cable routes out the bottom of the lower
cover.
7. Screw the mount to the rear of the panel using the supplied screws.
FIG. 6 Mounting Plate Installation
NOTE: The three slots should be oriented UP and the set screw
holes should be oriented DOWN.
Top
Top
QUICK START GUIDE
VARIA- -ACS 810A 8” & 10.1” Angle-Select Tabletop Stand
VARIA- -ACS 150A 15.6” Angle- Select Tabletop Stand
© 2023 HARMAN. All rights reserved. SmartScale, NetLink, Enova, AMX, AV FOR AN IT WORLD, and HARMAN, and their respective logos are registered
trademarks of HARMAN. Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their respective
companies.
AMX does not assume responsibility for errors or omissions. AMX also reserves the right to alter specifications without any prior notice at time. The
AMX Warranty and Return Policy and related documents be viewed/downloaded can at www.amx.com .
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 800.222.0193 | AMX.com | 469.624.8000 +1.469.624.7400 | | fax 469.624.7153
1000374846 D REV:
Last Revised 2023-08-18
FIG. 7 Mounting Plate; Slot & Set Screw Locations
8. Select the best angle for installation. The Angle-Select Tabletop Stand
can be installed at one of three (3) angles:
a. Upright 60° angle
b. Mid 45° angle
c. Low 30° angle
30° position
[Most Horizontal]
45° position
60° position
[ ] Most Upright
FIG. 8 Mounting Plate; Install Angle Options
9. Insert the base into the desired position. Insert the tab first and set
flat against the mount.
10. Install the supplied set screw to lock the base in the desired position.
FIG. 9 Varia Touch Panels on Angle-Select Tabletop Stand, various angles
Removing
To remove the panel, follow the installation directions in reverse.
Slots
Set Screws
