QUICK START GUIDE

- 80VARIA SL

Overview

The AMX VARIA (AMX- SL80 - 8 8 - , - , -UTP0 01) ” Ultra Slim Wall Mount Professional

Grade, Persona-Defined Touch Panel redefines control with personas that fit any

application. Personas include Web Kiosk, Zoom Rooms Controller, AMX Book

Scheduling, and AMX G5 Control.

s Microphone

S ettings Button

Function Button

Speakers LAN/POE

Side LED USB

FIG. 1 - T P AMX VARIA SL80 ouch anel

Product Specifications

Varia SL80 SPECIFICATIONS

Dimensions (HWD)

8 13/

” x 5 1/

” x 1 1/

”

( x x 213.22 mm 127.64 mm 26.65 mm)

Weight

17 oz 482 g( )

Power Consumption

PoE, 802.3af, 15.4 watt, compatible w/ PoE+

External Power

Supply Required

Optimal performance requires use of one of the

following AMX PoE power supplies (not included):

• PS- - -POE AF TC, PoE Injector, 802.3AF

Compliant (FG423- 83)

Certifications &

Compliance

• UL

• CE

• CB

•

FCC Class B (- 5dB)

Environmental

Operating Temperature

• 0°C - – 40° C (32°F 104°F)

• 5% - 85% Humidity

Storage Temperature

• -2 – 6 4 – 0 0°C 0° C ( °F 14 °F)

•

5% - 90% Humidity

Included Accessories

• Mounting Plate

• Mounting Hardware

• Set Screw

VARIA-SL80 Installation

The VARIA- SL80 installs into a standard electrical single gang box (US, UK, EU,

AU) using the included mounting plate.

Power Over Ethernet

Power is supplied via Power Over Ethernet (PoE), utilizing an AMX certified PoE

injector such as the PS- - -POE AF TC PoE Injector (FG423-83) or compatible

network switch which is classified as ES1 and PS2 output in accordance with

IEC/EN/UL 62368-1. Connect the incoming Ethernet cable to the RJ-45 port on

the VARIA- . SL80

Mounting Plate

The included mounting plate ole patterns for standard contains h single gang

electrical . boxes in US, UK, EU, & AU

Set Screw Mounting Plate

FIG. 2 Mounting Plate

STEP 1: Installation Prerequisites

Prior to touch panel installation, install single gang electrical box and properly

terminated category cable (networking cable) in accordance with local laws and

building codes.

STEP 2: Install the Mounting Plate

Screw the mounting plate into standard single gang electrical box using

appropriate hardware for the box.

STEP 3: Route Category Cable

Route the networking cable through the large central hole in the mounting plate,

and plug it into the on the back of the touch panelRJ- 45 jack .

STEP 4: Mount the Panel to Plate

Using the top tab & slot, insert the panel to the mounting plate. Make sure the

tabs are fully engaged.

STEP 5: Set Screw

Insert & tighten the set screw on the bottom to secure the panel to the mounting

plate.

FIG. 3 Back Box Installation Examples

Caution: This product is only suitable for installations less than or equal to 2m

(6.56ft) high for CE/UL safety.

Removing

To remove the panel, follow the installation directions in reverse.

trademarks of HARMAN. Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their respective

companies.

AMX does not assume responsibility for omissions. errors or AMX also reserves the right to alter specifications without prior notice at any time. The

AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com .

3000 RESEARCH DRIVE, RICHARDSON, | | TX 75082 AMX.com 800.222.0193 469.624.8000 +1.469.624.7400 | | fax 469.624.7153

1000374212 REV:C

Last Revised 2022- -11 29

Powering On & Panel Setup Wizard

Powering on for the first time (or after a factory reset) will launch a setup

wizard where device settings and the panel’s persona are selected. After being

selected, the panel will boot to that persona on each subsequent power cycle

or reboot.

1. Select your language

2. Select your time zone, date, & time

3. Set up your network

4. Select your panel’s persona:

• Web Kiosk: The touch panel is set up to display a web URL on a full-

screen HTML5 browser.

• Zoom Rooms Controller: The touch panel is set up to control a

Zoom Rooms space.

• AMX Book Scheduling: The touch panel is set up for room

scheduling, connecting to Microsoft Exchange, O365, or Google

Calendar.

• AMX G5 Control: The touch panel is set up for AMX NetLinx control,

utilizing a TP5 file created using TPDesign5.

FIG. 4 Select App page in the Setup Wizard

The persona can be changed at any time in the Advanced Settings menu.

Each selection requires its own setup. After confirming your app selection, the

panel will continue to . Full step through setup for the selected persona step-

by-step walkthroughs can be found in the AMX Varia Programming &

Configuration Guide available on AMX.com.

AMX Varia : Programming & Configuration Guide

https://www.amx.com/en-

US/site_elements/configuration- -programming

manual- - -varia touch panels

Function Button

The touch panel has a rectangular flush button on the top of the bezel, on the

right side.

Function Button

S ettings Button

Microphone

FIG. 5 Panel Buttons’ Location

The Function Button serves multiple purposes:

1. A quick press & release will turn the panel’s display on & off ( i.e.

sleep wake).&

2. A press & hold for 4 seconds will return to the primary persona.

This is useful if another app had been loaded on top of the panel’s

primary persona app.

3. If the panel is shut down, pressing the Function button will boot up

the panel.

4. If the Function button is pressed & held during the boot process, the

panel will launch into Safe Mode.

Settings Button

The touch panel has a pin hole button which serv- es two purposes:

1. A quick press & release will open Panel Settings

2. A press will reboot the panel & hold for 4 seconds

The default PIN to access Panel Settings is 1988.

NOTE: D So not confuse the ettings -button (pin hole button) with any of the

microphone or sensor holes. The button is the Settings larger hole located

closest to the Function Button. Irreparable damage may occur if a foreign

object is pushed down the microphone hole o . r into one of the sensors

Light Sensor & Proximity Sensor

FIG. 6 Panel Camera & Sensor Locations

The ambient light sensor can automatically adjust panel brightness based on

the environment. See ettings to enable automatic brightness.D Sisplay

The laser proximity sensor will detect nearby motion

to wake the panel up without requiring a touch.

Camera

Sensors
