SURFACE MOUNT LOUDSPEAKER

SWITCH POWER IMPEDANCE AMPLIFIER

1 6 Watt 100 Volt1.6KΩ

2 3 Watt 100 Volt3.3KΩ

3 1.5 Watt 100 Volt6.6KΩ

4 OFF OFF OFF

516Ω / 40 Watt 16Ω HiFi amp

SDQ3T

WWW.APART-AUDIO.COM INFO@APART-AUDIO.COM

• type : 2-way hiFi Pro, sealed box

• woofer : 3,2” CP type

• tweeter : 1” mylar ferro cooled

• protection : system auto-reset 1-guard

• impedance : 16Ω

• 100Volt trafo selector: 6-3-1,5W-OFF-16Ω

• RMS power low-imp.

AES rated : 30 Watts

music - program : 40 Watts

dynamic peak : (lo-cut)70 Watts

SPL 1 watt / 1 m : 86dB

SPL max peak : 104dB

• Freq range : 90 - 20000 Hz

• dispersion : 120° H x 100° V

• IP rating : 54

• enclosure material : enforced PolyPlastic

• bracket included : swivel ball type

• dimensions (h x w x d) : 152 x 105 x 104

• weight : 0,85 Kg

Technical Specifications

The SDQ3T 2-way design cabinet loud-

speaker is loved by every interior designer

and architect for its small dimensions and perfect sound

quality. The loudspeaker can be used as a 16Ω or 100V

loudspeaker. In 16Ω use, you can connect up to 4

loudspeakers in parallel on each channel of a standard

4Ω amplifier. For 100V use, the loudspeaker is equipped

with a high quality 6 Watt transformer with several power

taps. Further, the SDQ3T is equipped with an auto-reset

protection system. It makes the SDQ3T loudspeaker

very suitable for the distribution of background music or

microphone calls. The loudspeaker comes standard with

a swivel ball type bracket. The SDQ3T loudspeakers can

be used outdoor. However, be aware of the fact that the

loudspeaker terminals are not protected and that the grill

is made of plasticized painted metal. This means direct

exposure to rain or water is not recommended. In case

this is really needed, we recommend to use the APart

MASK loudspeaker series.

Power Tappings

6 6 6 3 3 3 1.5 1.5++ + + + + +30 Watt =

40 Watt Amplier

Amplier power must be higher than total power of all speakers.

Het versterkervermogen moet hoger zijn dan de som van de vermogens van de luidsprekers.

La puissance de l’amplicateur doit etre plus élevée que la puissance totale des haut parleurs.

100 Volt Technology

16 ohm Technology

16Ω 16Ω 16Ω 16Ω 16Ω 16Ω 16Ω 16Ω

4Ω 4Ω

Produkt Specifikationer

Mærke:	APart
Kategori:	Højttaler
Model:	SDQ3T-BL
Type:	I væggen/på væggen/i loftet højttalere
Vægt:	850 g
Produktfarve:	Sort
Udgangseffekt (RMS):	35 W
Dimensioner (BxDxH):	105 x 104 x 152 mm
Frekvensområde:	90 - 20000 Hz
Impedens:	16 ohm (Ω)
Lyd-output kanaler:	2.0 kanaler
Diskanthøjttaler:	Ja
Peak Music-Udgangseffekt (PMPO):	50, 70 W
Diskant diameter:	25.4 mm
Woofer diameter:	81.3 mm
