Side 1/2

Telescoping pole extends

upward from 17 inches to

29 inches.

Compatibility:

Fits smartphones with

cases weighing up to 2

pounds and measuring

up to 4” wide.

IMPORTANT:

Do not overtighten ring.

Overtightening may

damage threads on

holder and also make it

difﬁcult to adjust phone

and tablet holders.

3 4

Insert pole into base.

PLEASE NOTE—this will be a tight ﬁt and will require some force.

Your Remarkable Creators Bundle will arrive in eight pieces:

Telescoping Pole

25mm to 1/4”-20

Camera Bolt Adapter

(optional)

Weighted Base

with Allen Wrench

RV B

Attach overhead arm assembly by un

the pole until

Unscrew tightening ring from holder.

Place ring over the 17mm end of mount

then snap the holder onto the ball. Set to

desired position, then tighten ring.

Using two hands, insert phone into the

holder by pushing the device into one of the

spring-loaded support arms. Expand the other

support arm and fully insert device until it lays

ﬂat against the blue rubber pad.

SP25MMCAM

Assembled Mount

S 0

SPHD8BASE

SPHD8L29

Tighten clockwise

to secure.

Tighte

Teles

Pol

Tightening

Knob

Collar

M al de

Continued on page 2

RCBTABLED | Remarkable Creators Video Phone Stand Bundle rev.053118

SPHD8L29

SPHD8BASE

Phone Holder

LED Ring Light

RV001WR-B

Overhead Arm

Assembly

SP3RMPR0

Clamp Post Mount

GN031-SBH-B

SPLEDRING

TAB001

GN031-SBH-B

5Shafts can be adjusted by unscrewing

the shafts’ knobs to loosen. Tighten

knobs to set.

Tablet Holder

TAB001

To attach camera/pico projector adapter, unscrew shaft knob and optional

remove phone holder, ring, and ball adapter. Attach the 25mm ball end of the

camera adapter to the shaft and tighten clockwise to secure.

Unscrew mount’s knob to loosen grip. Place mount around pole and

tighten knob to secure. Push down on lower legs of spring-loaded holder to insert tablet.

Ring light clips onto phone.

For instructions on how to assemble tablet holder, refer to included

TAB001 manual. Attach tablet holder by inserting the mount’s Dual

T-Tabs into the holder’s Dual T-Slots.

Adjust the height of the pole by loosening the adjustment collar

counterclockwise. Tighten clockwise to set height.

Consumer Hotline:

USA (800) 841-0884

INT’L (626) 254-9005

Monday - Friday 9 am - 5 pm, PST

www.arkon.com

Arcadia, CA 91006 USA

Designed in USA | Made in Taiwan and USA

Safety Precautions

Always use two hands (one on shaft, and one on base) when carrying.

Failure to properly secure the stand’s shaft to the base could cause

bodily injury or harm. The Arkon Pro Stand is designed for use with

smartphones and small cameras. If using heavier devices, be sure to add

a counterbalance in order to prevent the stand from falling over. Arkon

Resources, Inc. is not responsible for any damages caused to your device

or yourself due to the installation or use of this mount.

page 2

htening

RCBTABLED | Remarkable Creators Video Phone Stand Bundle rev.053118

OPTIONAL
