Notebook PC User Manual
July 2012
E7596
2
Notebook PC User Manual
Table of Contents
Chapter 1: Introducing the Notebook PC
About This User’s Manual ................................................................................ 6
Notes for This Manual ....................................................................................... 6
Safety Precautions ............................................................................................. 7
Preparing your Notebook PC .......................................................................11
Chapter 2: Knowing the parts
Top Side ...............................................................................................................14
Bottom Side ........................................................................................................18
Right Side ............................................................................................................22
Left Side ...............................................................................................................24
Rear Side ..............................................................................................................26
Front Side ............................................................................................................27
Chapter 3: Getting Started
Power System ....................................................................................................30
Using AC Power ...............................................................................................30
Using Battery Power ......................................................................................32
Battery Care ......................................................................................................33
Powering ON the Notebook PC .................................................................34
The Power-On Self Test (POST) ..................................................................34
Checking Battery Power ...............................................................................36
Charging the Battery Pack ...........................................................................37
Power Options .................................................................................................38
Power Management Modes .......................................................................40
Sleep and Hibernate ......................................................................................40
Thermal Power Control .................................................................................42
Special Keyboard Functions .........................................................................43
Hot Keys .............................................................................................................43
Microsoft Windows Keys ..............................................................................45
Keyboard as Numeric Keypad (on selected models) .........................46
Keyboard as Pointers (on selected models) ..........................................46
Multimedia Control Keys ............................................................................47
Button and Status Indicators .......................................................................48
Notebook PC User Manual
3
Button .............................................................................................................48
Status Indicators .............................................................................................49
Chapter 4: Using the Notebook PC
Touchpad ............................................................................................................52
Using the touchpad .......................................................................................53
Touchpad usage illustrations .....................................................................54
Caring for the touchpad ...............................................................................56
Disabling the touchpad automatically ...................................................57
Storage Devices ................................................................................................58
Optical Drive (on selected models) ..........................................................58
Memory Card Reader ....................................................................................62
Hard Disk Drive ................................................................................................63
Memory (RAM) .................................................................................................66
Network Connections .....................................................................................69
Wired Network Connections ......................................................................69
Wireless Network Connections .................................................................71
Bluetooth Wireless Connection (on selected models) ......................75
USB Charger+ ....................................................................................................77
Instant On ...........................................................................................................77
Appendix
Optional Accessories .....................................................................................A-2
Optional Connections .................................................................................A-2
Operating System and Software ...............................................................A-3
System BIOS Settings ..................................................................................A-4
Troubleshooting ....................................................................................... A-10
Recovery options for your Notebook PC ............................................ A-15
Using Recovery Partition ........................................................................ A-15
Using DVD Recovery (on selected models) ...................................... A-16
DVD-ROM Drive Information ................................................................. A-18
(on selected models) .................................................................................. A-18
Blu-ray ROM Drive Information(on selected models) .................... A-20
Internal Modem Compliancy .................................................................. A-21
Declarations and Safety Statements .................................................... A-25
4
Notebook PC User Manual
Federal Communications Commission Statement ........................ A-25
FCC Radio Frequency (RF) Exposure Caution Statement ............ A-26
Declaration of Conformity(R&TTE directive 1999/5/EC) .............. A-26
CE Marking ................................................................................................... A-27
IC Radiation Exposure Statement for Canada ................................. A-27
Wireless Operation Channel for Different Domains ...................... A-28
France Restricted Wireless Frequency Bands .................................. A-28
UL Safety Notices ....................................................................................... A-30
Power Safety Requirement .................................................................... A-31
TV Tuner Notices ........................................................................................ A-31
REACH ........................................................................................................ A-31
Nordic Lithium Cautions (for lithium-ion batteries) ...................... A-32
Optical Drive Safety Information ......................................................... A-33
Laser Safety Information ......................................................................... A-33
Service warning label ............................................................................... A-33
CDRH Regulations ..................................................................................... A-33
Macrovision Corporation Product Notice ......................................... A-34
CTR 21 Approval(for Notebook PC with built-in Modem) .......... A-35
European Union Eco-label ...................................................................... A-37
Global Environmental Regulation
Compliance and Declaration ................................................................ A-38
ASUS Recycling/Takeback Services ..................................................... A-38
Copyright Information .............................................................................. A-39
Limitation of Liability ................................................................................. A-40
Service and Support ................................................................................... A-40
1
Chapter 1:
Introducing the
Notebook PC
6
Notebook PC User Manual
About This User’s Manual
You are reading the Notebook PC User’s Manual. This User’s Manual
provides information regarding the various components in the
Notebook PC and how to use them. The following are major sections
of this User’s Manual:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional
information.
The actual bundled operating system and applications differ by
models and territories. There may be differences between your
Notebook PC and the pictures shown in this manual. Please
accept your Notebook PC as being correct.
Notes for This Manual
A few notes and warnings are used throughout this guide, allowing
you to complete certain tasks safely and effectively. These notes have
different degrees of importance as follows:
WARNING! Important information that must be followed for safe
operation.
IMPORTANT! Vital information that must be followed to prevent
damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.
Notebook PC User Manual
7
Safety Precautions
The following safety precautions will increase the life of the
Notebook PC. Follow all precautions and instructions. Except as
described in this manual, refer all servicing to qualified personnel.
Battery safety warning:
DO NOT throw the
battery in fire. DO NOT
short circuit the contacts.
DO NOT disassemble the
battery.
DO NOT leave the
Notebook PC on your lap
or any part of the body
to prevent discomfort
or injury from heat
exposure.
DO NOT expose to dirty
or dusty environments.
DO NOT operate during a
gas leak.
DO NOT expose to
strong magnetic or
electrical fields.
DO NOT expose to or
use near liquids, rain,
or moisture. DO NOT
use the modem during
electrical storms.
DO NOT press or touch
the display panel. Do not
place together with small
items that may scratch or
enter the Notebook PC.
DO NOT place on
uneven or unstable work
surfaces. Seek servicing
if the casing has been
damaged.
DO NOT place or drop
objects on top and
do not shove any
foreign objects into the
Notebook PC.
Disconnect the AC power and remove the battery pack(s) before
cleaning the Notebook PC. Wipe the Notebook PC using a clean
cellulose sponge or chamois cloth dampened with a solution
of nonabrasive detergent and a few drops of warm water and
remove any extra moisture with a dry cloth.
8
Notebook PC User Manual
SAFE TEMP: This
Notebook PC should
only be used in
environments with
ambient temperatures
between 5°C (41°F) and
35°C (95°F).
DO NOT carry or cover
a Notebook PC that
is powered ON with
any materials that will
reduce air circulation
such as a carrying bag.
DO NOT throw the Notebook PC in municipal waste. This
product has been designed to enable proper reuse of parts
and recycling. The symbol of the crossed out wheeled bin
indicates that the product (electrical, electronic equipment
and mercury-containing button cell battery) should not
be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the battery in municipal waste. The symbol
of the crossed out wheeled bin indicates that the battery
should not be placed in municipal waste.
INPUT RATING: Refer to
the rating label on the
bottom of the Notebook
PC and be sure that your
power adapter complies
with the rating.
Incorrect installation
of battery may cause
explosion and damage
the Notebook PC.
DO NOT use damaged
power cords, accessories,
or other peripherals.
DO NOT use strong
solvents such as
thinners, benzene, or
other chemicals on or
near the surface.
Notebook PC User Manual
9
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it OFF
and disconnect all external peripherals to prevent damage to
the connectors. The hard disk drive’s head retracts when the power
is turned OFF to prevent scratching of the hard disk surface during
transport. Therefore, you should not transport the Notebook PC
while the power is still ON. Close the display panel and check that
it is latched securely in the closed position to protect the keyboard
and display panel.
The Notebook PC’s surface is easily dulled if not properly cared
for. Be careful not to rub or scrape the Notebook PC surfaces.
Sound Pressure warning
Excessive sound pressure from earphones or headphones can cause
hearing damage or loss. Adjustment of the volume control as well as
the equalizer to settings other than the center position may increase
the earphones or headphones output voltage and the sound
pressure level.
DC Fan warning
Please note that the DC fan is a moving part that may cause DANGER.
Ensure to keep your body from the moving fan blades.
Adapter Information
Input voltage: 100-240Vac
Input frequency: 50-60Hz
Rating output current: 3.42A (65W)
Rating output voltage: 19Vdc
The socket-outlet shall be installed near the equipment and shall
be easily accessible.
10
Notebook PC User Manual
Cover Your Notebook PC
Purchase a carrying bag to protect the Notebook PC from dirt, water,
shock, and scratches.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your
battery pack and any optional battery packs before going on long
trips. Remember that the power adapter charges the battery pack as
long as it is plugged into the computer and an AC power source. Be
aware that it takes much longer to charge the battery pack when the
Notebook PC is in use.
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the
airplane. Most airlines will have restrictions for using electronic
devices. Most airlines will allow electronic use only between and not
during takeoffs and landings.
There are three main types of airport security devices: X-ray
machines (used on items placed on conveyor belts), magnetic
detectors (used on people walking through security checks),
and magnetic wands (hand-held devices used on people or
individual items). You can send your Notebook PC and diskettes
through airport X-ray machines. However, it is recommended
that you do not send your Notebook PC or diskettes through
airport magnetic detectors or expose them to magnetic wands.
Notebook PC User Manual
11
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC.
B
A
C
Installing the Battery Pack
A. Move the manual battery lock to the unlocked position.
B. Align and insert the battery pack into the Notebook PC’s battery
slot.
C. Move the manual battery lock back to the locked position after
inserting the battery pack.
B
A
C
Connecting the AC power adapter
A. Plug the AC power adapter into an electrical outlet (100V-240V)
B. Connect the AC power cord to the AC/DC adapter.
C. Plug the DC power connector into your Notebook PC.
12
Notebook PC User Manual
Opening the display panel
A. Hold the base of your Notebook PC then lift up the display
panel with your thumb.
B. Slowly tilt the display panel forward or backward to a
comfortable viewing angle.
Turning the power on
Press the power button.
2
Chapter 2:
Knowing the parts
14
Notebook PC User Manual
Top Side
The keyboard differs for each territory.
The top side may vary in appearance depending on model.
15” model
2
3
5
7
6
1
4
Notebook PC User Manual
15
14" model
2
3
5
7
6
1
4
16
Notebook PC User Manual
1
2
3
4
Microphone (Built-in)
The built-in mono microphone can be used for video
conferencing, voice narrations, or simple audio recordings
Camera
The built-in camera allows picture taking or video
recording. Can be used with video conferencing and other
interactive applications.
Camera Indicator (on selected models)
The camera indicator lights up when the built-in camera is
in use.
Display PanelDisplay Panel
The display panel functions the same as a desktop monitor.
The Notebook PC uses a TFT LCD, which provides excellent
viewing like that of desktop monitors. Unlike desktop
monitors, the LCD panel does not produce any radiation
or flickering. Use a soft cloth without chemical liquids (use
plain water if necessary) to clean the display panel.
Notebook PC User Manual
17
5
6
Power Button
The power button turns the Notebook PC ON and OFF, and
wakes it up from suspend mode. Press the power button
once to turn ON and once to turn OFF the Notebook PC.
The power button only works when the display panel is
opened.
Keyboard
The keyboard provides full-sized QWERTY keys with a
comfortable travel depth for typing and a palm rest for
both hands. It also comes with special keyboard functions
that can enable hot keys, allow quick access to Windows,
and control multimedia functions. For more details, refer to
Special Keyboard functions under Chapter 3.
Touchpad
The touchpad is a pointing device that provides the same
functions as a desktop mouse. A software-controlled
scrolling function is available after setting up the included
touchpad utility to allow easy Windows or web navigation.
7
18
Notebook PC User Manual
Bottom Side
The bottom side may vary in appearance depending on model.
The battery pack size varies depending on model.
15" model
5
Notebook PC User Manual
19
14" model
5
The bottom of the Notebook PC can get very hot. Be careful
when handling the Notebook PC while it is in operation or
recently been in operation. High temperatures are normal during
charging or operation. DO NOT USE ON SOFT SURFACES SUCH
AS BEDS OR SOFAS WHICH MAY BLOCK THE VENTS. DO NOT
PUT THE NOTEBOOK PC ON YOUR LAP OR OTHER PARTS OF
THE BODY TO AVOID INJURY FROM THE HEAT.
20
Notebook PC User Manual
Spring Battery Lock
The spring battery lock is used to keep the battery
pack secured. When the battery pack is inserted, it will
automatically lock. To remove the battery pack, this spring
lock must be held in the unlocked position.
Battery Pack
The battery pack is automatically charged when the
Notebook PC is connected to an AC power source and
maintains power to the Notebook PC when AC power is
not connected. This allows use when moving temporarily
between locations. Battery time varies by usage and by
the specifications for this Notebook PC. The battery pack
cannot be disassembled and must be purchased as a single
unit.
Manual Battery Lock
The manual battery lock is used to keep the battery pack
secured. Move the manual lock to the unlocked position to
insert or remove the battery pack. Move the manual lock to
the locked position after inserting the battery pack.
1
2
3
Notebook PC User Manual
21
4
5
Memory (RAM) CompartmentMemory (RAM) Compartment
The memory compartment provides expansion capabilities
for additional memory. Additional memory will increase
application performance by decreasing hard disk access.
The BIOS automatically detects the amount of memory in
the system and configures CMOS accordingly during the
POST (Power-On-Self-Test) process. There is no hardware or
software (including BIOS) setup required after the memory
is installed. Visit an authorized service center or retailer for
information on memory upgrades for your Notebook PC.
Only purchase expansion modules from authorized retailers
of this Notebook PC to ensure maximum compatibility and
reliability.
Hard Disk Drive Compartment
The hard disk drive is secured in a compartment. Visit an
authorized service center or retailer for information on hard
disk drive upgrades for your Notebook PC. Only purchase
hard disk drives from authorized retailers of this Notebook
PC to ensure maximum compatibility and reliability.
22
Notebook PC User Manual
Right Side
41 2 5 63
41 2 5 63
1
2
/ Headphone Output/Microphone Input Combo Jack
This combo jack can be used to connect the Notebook PC's
audio out signal to amplified speakers or headphones, or
can be used to connect an external microphone or output
signals from audio devices. This jack automatically detects
the connecting device and switches functions.
USB Port (2.0)
The USB (Universal Serial Bus) port is compatible with USB
2.0 or USB 1.1 devices such as keyboards, pointing devices,
cameras, hard disk drives, printers, and scanners connected
in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec
(USB 2.0). USB allows many devices to run simultaneously
on a single computer, with some peripherals acting as
additional plug-in sites or hubs. USB supports hot-swapping
of devices so that most peripherals can be connected or
disconnected without restarting the computer.
15" model
14" model
Notebook PC User Manual
23
4
3
Optical Drive (on selected models)
The Notebook PC comes in various models with different
optical drives. The Notebook PC’s optical drive may support
compact discs (CD) and/or digital video discs (DVD) and
may have recordable (R) or re-writable (RW) capabilities.
See the marketing specifications for details on each model.
Optical Drive Electronic Eject
The optical drive eject has an electronic eject button for
opening the tray. You can also eject the optical drive tray
through any software player or by right clicking the optical
drive in Windows “Computer” and selecting Eject.
Optical Drive Emergency Eject
(location varies by model)
The emergency eject is used to eject the optical drive tray
in case the electronic eject does not work. Do not use the
emergency eject in place of the electronic eject.
Kensington® Lock Port
The Kensington® lock port allows the Notebook PC to
be secured using Kensington® compatible Notebook PC
security products. These security products usually include
a metal cable and lock that prevent the Notebook PC to
be removed from a fixed object. Some may also include a
motion detector to sound an alarm when moved.
5
6
24
Notebook PC User Manual
Power (DC) Input
The supplied power adapter converts AC power to DC
power for use with this jack. Power supplied through this
jack supplies power to the Notebook PC and charges the
internal battery pack. To prevent damage to the Notebook
PC and battery pack, always use the supplied power
adapter.
The adapter may become warm to hot when in use. Ensure
not to cover the adapter and keep it away from your body.
Air Vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
Ensure that paper, books, clothing, cables, or other objects
do not block any of the air vents or else overheating may
occur.
Left Side
1 2 34 5 6
123456
1
15" model
14" model
2
Notebook PC User Manual
25
5
3
4
Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard
VGA-compatible device such as a monitor or projector to
allow viewing on a larger external display.
HDMI
HDMI Port
HDMI (High-Definition Multimedia Interface) is an
uncompressed all-digital audio/video interface between
an audio/video source and an audio and/or video monitor.
HDMI supports standard, enhanced, or high-definition
video, plus multi-channel digital audio on a single cable. It
transmits all ATSC HDTV standards and supports 8-channel
digital audio, with bandwidth to spare to accommodate
future enhancements or requirements.
LAN Port
The RJ-45 LAN port with eight pins is larger than the RJ-11
modem port and supports a standard Ethernet cable for
connection to a local network. The built-in connector allows
convenient use without additional adapters.
USB Port 3.0
The USB (Universal Serial Bus) port is compatible with USB
3.0, 2.0, or USB 1.1 devices such as keyboards, pointing
devices, cameras, hard disk drives, printers, and scanners
connected in a series up to 4.8Gbits/sec (USB 3.0),
480Mbits/sec (USB 2.0), and 12Mbits/sec (USB 1.1). USB
allows many devices to run simultaneously on a single
computer, with some peripherals acting as additional plug-
in sites or hubs. USB supports hot-swapping of devices so
that most peripherals can be connected or disconnected
without restarting the computer.
USB Charger+
USB Charger+ allows you to quick charge your mobile
device via your ASUS Notebook PC’s USB charge port.
6
26
Notebook PC User Manual
Rear Side
Battery Pack
The battery pack is automatically charged when the
Notebook PC is connected to an AC power source and
maintains power to the Notebook PC when AC power is
not connected. This allows use when moving temporarily
between locations. Battery time varies by usage and by
the specifications for this Notebook PC. The battery pack
cannot be disassembled and must be purchased as a single
unit.
1
1
The battery pack size varies depending on model.
Front Side
Memory Card Reader
Normally an external memory card reader must be
purchased separately in order to use memory cards from
devices such as digital cameras, MP3 players, and mobile
phones. This Notebook PC has a built-in high-speed memoryhigh-speed memory
card reader that can conveniently read from and write tofrom and write to
memory cards.
Status Indicators
Status indicators represent various hardware/software
conditions. For detailed information, see Status Indicators in
Chapter 3.
1
1
2
15" model
14" model
1
2
2
3
Chapter 3:
Getting Started
30
Notebook PC User Manual
Power System
Using AC Power
The Notebook PC power is comprised of two parts, the power
adapter and the battery power system. The power adapter converts
AC power from a wall outlet to the DC power required by the
Notebook PC. Your Notebook PC comes with a universal AC/DC
adapter. That means that you may connect the power cord to any
100V-120V as well as 220V-240V outlets without setting switches
or using power converters. Different countries may require that an
adapter be used to connect the provided US-standard AC power
cord to a different standard. Most hotels will provide universal
outlets to support different power cords as well as voltages. It is
always best to ask an experienced traveler about AC outlet voltages
when bringing power adapters to another country.
You can buy travel kits for the Notebook PC that includes power
and modem adapters for almost every country.
DO NOT connect the AC power cord to an AC outlet prior to
connecting the DC plug to the Notebook PC. Doing so may
damage the AC/DC adapter.
The actual location of the power input differs by models. Refer to
the previous chapter to locate the LAN port.
B
A
C
Notebook PC User Manual
31
Damage may occur if you use a different adapter to power the
Notebook PC or use the Notebook PC’s adapter to power other
electrical devices. If there is smoke, burning scent, or extreme
heat coming from the AC/DC adapter, seek servicing. Seek
servicing if you suspect a faulty AC/DC adapter. You may damage
both your battery pack(s) and the Notebook PC with a faulty
AC/DC adapter.
This Notebook PC may come with either a two or three-prong
plug depending on territory. If a three-prong plug is provided,
you must use a grounded AC outlet or use a properly grounded
adapter to ensure safe operation of the Notebook PC.
THE POWER ADAPTER MAY BECOME WARM TO HOT WHEN IN
USE. BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY
FROM YOUR BODY.
Unplug the power adapter or switch off the AC outlet to
minimize the power consumption when the Notebook PC is not
in use.
32
Notebook PC User Manual
Using Battery Power
The Notebook PC is designed to work with a removable battery pack.
The battery pack consists of a set of battery cells housed together.
A fully charged pack will provide several hours of battery life, which
can be further extended by using power management features
through the BIOS setup. Additional battery packs are optional and
can be purchased separately through a Notebook PC retailer.
Installing and Removing the Battery Pack
Your Notebook PC may or may not have its battery pack installed. If
your Notebook PC does not have its battery pack installed, use the
following procedures to install the battery pack.
Never attempt to remove the battery pack while the Notebook
PC is turned ON, as this may result in the loss of working data.
To install the battery pack:
B
A
C
Notebook PC User Manual
33
Only use battery packs and power adapters supplied with this
Notebook PC or specifically approved by the manufacturer or
retailer for use with this model or else damage may occur to the
Notebook PC.
To remove the battery pack:
For safety reasons, DO NOT throw the battery in fire, DO NOT
short circuit the contacts, and DO NOT disassemble the battery. If
there is any abnormal operation or damage to the battery pack
caused by impact, turn OFF the Notebook PC and contact an
authorized service center.
Battery Care
The Notebook PC’s battery pack, like all rechargeable batteries, has a
limit on the number of times it can be recharged. The battery pack’s
useful life will depend on your environment temperature, humidity,
and how your Notebook PC is used. It is ideal that the battery be
used in a temperature range between 10˚C and 35˚C (50˚F and
95˚F). You must also take into account that the Notebook PC’s
internal temperature is higher than the outside temperature. Any
temperatures above or below this range will shorten the life of the
battery. But in any case, the battery pack’s usage time will eventually
decrease and a new battery pack must be purchased from an
authorized dealer for this Notebook PC. Because batteries also have
a shelf life, it is not recommended to buy extras for storing.
C
A
B
34
Notebook PC User Manual
To protect the hard disk drive, always wait at least 5 seconds after
turning OFF your Notebook PC before turning it back ON.
DO NOT carry or cover a Notebook PC that is powered ON with
any materials that will reduce air circulation such as a carrying
bag.
Before bootup, the display panel flashes when the power is
turned ON. This is part of the Notebook PC’s test routine and is
not a problem with the display.
Powering ON the Notebook PC
The Notebook PC’s power-ON message appears on the screen when
you turn it ON. If necessary, you may adjust the brightness by using
the hot keys. If you need to run the BIOS Setup to set or modify
the system configuration, press [f2] upon bootup to enter the BIOS
Setup. Press [esc] and you will be presented with a boot menu with
selections to boot from your available drives.
The Power-On Self Test (POST)
When you turn ON the Notebook PC, it will first run through a
series of software-controlled diagnostic tests called the Power-On
Self Test (POST). The software that controls the POST is installed
as a permanent part of the Notebook PC’s architecture. The POST
includes a record of the Notebook PC’s hardware configuration,
which is used to make a diagnostic check of the system. This record
is created by using the BIOS Setup program. If the POST discovers
a difference between the record and the existing hardware, it will
display a message on the screen prompting you to correct the
conflict by running BIOS Setup. In most cases the record should be
correct when you receive the Notebook PC. When the test is finished,
you may get a message reporting “No operating system found” if the
hard disk was not preloaded with an operating system. This indicates
that the hard disk is correctly detected and ready for the installation
of a new operating system.
Notebook PC User Manual
35
If warnings are still given during bootup after running a software
disk checking utility, you should take your Notebook PC in for
servicing. Continued use may result in data loss.
Self Monitoring and Reporting Technology
The S.M.A.R.T. (Self Monitoring and
Reporting Technology) checks the
hard disk drive during POST and
gives a warning message if the
hard disk drive requires servicing.
If any critical hard disk drive
warning is given during bootup,
backup your data immediately
and run Windows disk checking
program. To run Window’s disk
checking program: click Windows
> select > right-click Computer
a hard disk drive icon > choose
Properties Tools > click the tab >
click > click . You Check Now Start
can also select “Scan ... sectors” for more effective scan and repair but
the process will run slower.
36
Notebook PC User Manual
You will be warned when battery power is low. If you continue
to ignore the low battery warnings, the Notebook PC eventually
enters suspend mode (Windows default uses STR).
Screen captures shown here are examples only and may not
reflect what you see in your system.
Checking Battery Power
The battery system implements the Smart Battery standard under
the Windows environment, which allows the battery to accurately
report the amount of charge left in the battery. A fully-charged
battery pack provides the Notebook PC a few hours of working
power. But the actual figure varies depending on how you use the
power saving features, your general work habits, the CPU, system
memory size, and the size of the display panel.
Pointer over the battery icon without power adapter.
Pointer over the battery icon with
power adapter.
Right-click the battery icon
Left-click the battery icon
Suspend-to-RAM (STR) does not last long when the battery
power is depleted. STR is not the same as power OFF. STR requires
a small amount of power and will fail and lose data if no power is
available due to complete battery depletion or no power supply
(e.g. removing both the power adapter and battery pack).
Notebook PC User Manual
37
DO NOT leave the battery pack discharged. The battery pack
will discharge over time. If not using a battery pack, it must
continued to be charged every three months to extend recovery
capacity or else it may fail to charge in the future.
The battery stops charging if the temperature is too high or the
battery voltage is too high.
Charging the Battery Pack
Before you use your Notebook PC on the road, you will have to
charge the battery pack. The battery pack begins to charge as
soon as the Notebook PC is connected to external power using the
power adapter. Fully charge the battery pack before using it for the
first time. A new battery pack must completely charge before the
Notebook PC is disconnected from external power. It takes a few
hours to fully charge the battery when the Notebook PC is turned
OFF and may take twice the time when the Notebook PC is turned
ON. The battery status indicator on the Notebook PC turns OFF when
the battery pack is charged.
The battery starts charging when the charge remaining in
the battery drops below 95%. This prevents the battery from
charging frequently. Minimizing the recharge cycles helps
prolong battery life.
38
Notebook PC User Manual
To protect the hard drive, wait at least 5 seconds after turning
OFF your Notebook PC before turning it back ON.
Power Options
The power switch turns ON and
OFF the Notebook PC or putting
the Notebook PC into sleep
or hibernation modes. Actual
behavior of the power switch
can be customized in Windows
Control Panel “Power Options.”
For other options, such as “Switch
User, Restart, Sleep, or Shut Down,” click the arrowhead next to the
lock icon.
Restarting or Rebooting
After making changes to your operating system, you may be
prompted to restart the system. Some installation processes will
provide a dialog box to allow restart. To restart the system manually,
choose . Restart
Notebook PC User Manual
39
Emergency Shutdown
In case your operating system cannot properly turn OFF or restart,
there is an additional way to shutdown your Notebook PC:
Hold the power button over 4
seconds.
DO NOT use emergency shutdown while data is being written;
doing so can result in loss or destruction of your data.
40
Notebook PC User Manual
Sleep and Hibernate
Power management settings
can be found in the Windows
> Control Panel Hardware >
and Sound Power Options > . In
Power Options, you can define
Sleep/Hibernate Shut Down or
for closing the display panel or
pressing the power button. Sleep
and saves power when your Notebook PC is not in use Hibernate
by turning OFF certain components. When you resume your work,
your last status (such as a document scrolled down half way or email
typed half way) will reappear as if you never left. will Shut Down
close all applications and ask if you want to save your work if any are
not saved.
Power Management Modes
The Notebook PC has a number of automatic or adjustable power
saving features that you can use to maximize battery life and lower
Total Cost of Ownership (TCO). You can control some of these
features through the Power menu in the BIOS Setup. ACPI power
management settings are made through the operating system.
The power management features are designed to save as much
electricity as possible by putting components into a low power
consumption mode as often as possible but also allow full operation
on demand.
Notebook PC User Manual
41
Sleep is the same as Suspend-to-
RAM (STR). This function stores
your current data and status in
RAM while many components
are turned OFF. Because RAM
is volatile, it requires power to
keep (refresh) the data. Click
the Windows button and the
arrowhead next to the lock icon
to see this option. You can also use the keyboard shortcut [ ] to fn f1
activate this mode. Recover by pressing any keyboard key except [Fn].
(NOTE: The power indicator will blink while in this mode.)
Hibernate is the same as Suspend-to-Disk (STD) and stores your
current data and status on the hard disk drive. By doing this, RAM
does not have to be periodically refreshed and power consumption
is greatly reduced but not completely eliminated because certain
wake-up components like LAN needs to remain powered. Hibernate
saves more power compared to Sleep. Click the button Windows
and the arrowhead next to the lock icon to see this option. Recover
by pressing the power button. (NOTE: The power indicator will be
OFF in this mode.)
42
Notebook PC User Manual
Thermal Power Control
There are three power control methods for controlling the Notebook
PC’s thermal state. These power control cannot be configured by
the user and should be known in case the Notebook PC should
enter these states. The following temperatures represent the chassis
temperature (not CPU).
• The fan turns ON for active cooling when the temperature reaches
the safe upper limit.
• The CPU decreases speed for passive cooling when the temperature
exceeds the safe upper limit.
• The system shut down for critical cooling when temperature ex-
ceeds the maximum safe upper limit.
Notebook PC User Manual
43
Special Keyboard Functions
Hot Keys
The following defines the hot keys on the
Notebook PC’s keyboard. The commands
can only be accessed by first pressing and
holding the function key while pressing a key
with a command.
The Hot Key locations on the function keys may vary depending
on model but the functions should remain the same. Follow the
icons instead of the function keys.
“Z
Z
” Icon (f1): Places the Notebook PC in suspend mode
(either Save-to-RAM or Save-to-Disk depending on sleep
button setting in power management setup).
Radio Tower (f2): Wireless Models Only: Toggles the
internal wireless LAN or Bluetooth (on selected models)
ON or OFF with an on-screen-display. When enabled,
the corresponding wireless indicator will light. Windows
software settings are necessary to use the wireless LAN
or Bluetooth.
Sun Down Icon (f5): Decreases the display brightness
Sun Up Icon (f6): Increases the display brightness
LCD Icon (f7): Toggles the display panel ON and OFF. (On
certain models; stretches the screen area to fill the entire
display when using low resolution modes.)
44
Notebook PC User Manual
LCD/Monitor Icons (f8): Toggles between the Notebook
PC’s LCD display and an external monitor in this series:
LCD Only -> CRT Only (External Monitor) -> LCD + CRT
Clone -> LCD + CRT Extend. (This function does not
work in 256 Colors, select High Color in Display Property
Settings.) NOTE: Must connect an external monitor
“before” booting up.
Crossed-out Touchpad (f9): Toggles the built-in
touchpad LOCKED (disabled) and UNLOCKED (enabled).
Locking the touchpad will prevent you from accidentally
moving the pointer while typing and is best used with an
external pointing device such as a mouse. NOTE: Selected
models have an indicator between the touchpad buttons
will light when the touchpad is UNLOCKED (enabled) and
not light when the touchpad is LOCKED (disabled).
Crossed Speaker Icons (f10): Toggles the speakers ON
and OFF (only in Windows OS)
Speaker Down Icon (f11):
Decreases the speaker volume (only in Windows OS)
Speaker Up Icon (f12):
Increases the speaker volume (only in Windows OS)
fn+C: Toggles the “Splendid Video Intelligent
Technology” function so you can switch between these
display color enhancement modes: Gamma Correction,
Vivid Mode, Theater Mode, Soft Mode, My Profile, and
Normal.
fn+V: Toggles “Life Frame” software application.
For some models, this function is available only
when you enable the camera.
Notebook PC User Manual
45
Power4Gear Hybrid (fn+Space Bar): This key toggles
power savings between various power saving modes.
The power saving modes control many aspects of the
Notebook PC to maximize performance versus battery
time. Applying or removing the power adapter will
automatically switch the system between AC mode and
battery mode. You can see the current mode through the
on-screen display (OSD).
fn+enter (on selected models): Toggles Windows
“Calculator” application.
insert/num lk (on selected models): Toggles the
numeric keypad (number lock) ON and OFF. Allows you
to use a larger portion of the keyboard for entering
numbers.
delete/scr lk (on selected models): Toggles the “Scroll
Lock” ON and OFF. Allows you to use a larger portion of
the keyboard for cell navigation.
Microsoft Windows Keys
There are two special Windows keys on the keyboard as described
below.
The key with the Windows Logo activates the Start menu
located at the bottom left of the Windows desktop.
The other key, that looks like a Windows menu with
a small pointer, activates the properties menu and is
equivalent to pressing the right mouse button on a
Windows object.
46
Notebook PC User Manual
Keyboard as Numeric Keypad (on selected models)
The numeric keypad is embedded in the keyboard and consists of
15 keys that make number intensive input more convenient. These
dual-purpose keys are labeled in orange on the key caps. Numeric
assignments are located at the upper right hand corner of each
key as shown in the figure. When the numeric keypad is engaged
by pressing [fn][insert/num lk], the number lock LED lights up. If an
external keyboard is connected, pressing the [
insert/num lk] on the
external keyboard enables/
disables the NumLock
on both keyboards
simultaneously. To disable
the numeric keypad while
keeping the keypad on an
external keyboard activated,
press the [fn][insert/num lk] keys
on the Notebook PC.
Keyboard as Pointers (on selected models)
The keyboard can be used as pointers while Number Lock is ON or
OFF in order to increase navigation ease while entering numeric
data in spreadsheets or similar applications.
With Number Lock OFF,
press [fn] and one of the
pointer keys shown below.
For example [fn][8] for up,
[fn][K] for down, [fn][U] for left,
and [fn][O] for right.
With Number Lock ON, use [shift]
and one of the pointer keys shown below. For example [
shift][8] for
up, [shift][K] for down, [shift][U
] for left, and [shift][O] for right.
Notebook PC User Manual
47
Multimedia Control Keys
The multimedia control keys allows for convenient controlling of the
multimedia application. The following defines the meaning of each
multimedia control key on the Notebook PC.
Use the [fn] key in combination with the arrow keys for CD
control functions.
Some control key functions may defer depending on Notebook
PC model.
CD Play/Pause
During CD stop, begins CD play.
During CD play, pauses CD play.
CD Stop
During CD play: Stops CD play.
CD Skip to Previous Track (Rewind)
During CD play, skips to the previous audio track/
movie chapter.
CD Skip to Next Track (Fast Forward)
During CD play, skips to the next audio track/movie
chapter.
48
Notebook PC User Manual
Button
Button and Status Indicators
Power Button
The power button turns the Notebook PC ON and OFF. It also
puts the Notebook PC into sleep or hibernate mode. The actual
behavior of the power button can be customized in Windows
Control Panel “Power Options.”
The top side may vary in appearance depending on model.
Notebook PC User Manual
49
Status Indicators
Power Indicator
The power indicator lights when the Notebook PC is turned ON
and blinks slowly when the Notebook PC is in the Suspend-to-
RAM (Sleep) mode. This indicator is OFF when the Notebook PC
is turned OFF or in the Suspend-to-Disk (Hibernation) mode.
Battery Charge Indicator (dual-color)
The dual-color battery charge indicator shows the status of the
battery’s power as follows:
: Battery power is between 95% and 100% (with AC Green ON
power).
: Battery power is less than 95% (with AC power).Orange ON
: Battery power is less than 10% (without AC Orange Blinking
power).
: Battery power is between 10% and 100% (without AC Off
power).
15” model
14" model
50
Notebook PC User Manual
Drive Activity Indicator
Indicates that the Notebook PC is accessing one or more storage
device(s) such as the hard disk. The light flashes proportional to
the access time.
Bluetooth / Wireless Indicator
This is only applicable on models with internal Bluetooth (BT)
and built-in wireless LAN. This indicator will light to show that
the Notebook PC’s built-in Bluetooth (BT) function is activated.
When the built-in wireless LAN is enabled, this indicator will also
light. (Windows software settings are necessary.)
Number Lock Indicator
Indicates that number lock [Num Lk] is activated when lighted.
Number lock allows some of the keyboard letters to act as
numbers for easier numeric data input.
Capital Lock Indicator
Indicates that capital lock [Caps Lock] is activated when lighted.
Capital lock allows some of the keyboard letters to type using
capitalized letters (e.g. A, B, C). When the capital lock light is OFF,
the typed letters will be in the lower case form (e.g. a,b,c).
4
Chapter 4:
Using the Notebook PC
52
Notebook PC User Manual
DO NOT use any objects in place of your finger to operate the
touchpad. These objects may damage the touchpad’s surface.
Touchpad
The touchpad is an interactive device that interprets the gestures
and position of your fingers to simulate the functions of a regular
mouse. It is also an alternative to mouse to position cursor
onscreen.
The following illustration shows the features of the touchpad:.
Left-click button
(area inside the dotted-line)
Right-click button
(area outside the dotted-line)
Notebook PC User Manual
53
Using the touchpad
The touchpad allows you to use one-finger and multi-finger gestures
to move the pointer so you can select and click items, rotate and
zoom images, scroll lists, as well as swipe and switch between
windows.
Moving the pointer
You can tap or click anywhere on the touchpad to activate its
pointer, then slide your finger on the touchpad to move the pointer
onscreen.
Slide horizontally Slide vertically
Slide diagonally
54
Notebook PC User Manual
Tap once to select an item. Tap twice to open the selected
item.
Touchpad usage illustrations
Tapping - Tapping on the touchpad allows you to select items
onscreen and open files.
Clicking - Clicking on the touchpad simulates the functions of the
left mouse button and right mouse button.
Click once to select an item,
then double-click to open.
Click once to select an item and
view its menu options.
Left click Right click
Dragging and dropping - Doing the drag-and-drop action on the
touchpad allows you to move onscreen items into a new location.
Drag
Select an item by tapping twice,
then slide the same finger
without lifting it off the touchpad.
Release your finger from the
touchpad to drop the item on its
new location.
Drop
Notebook PC User Manual
55
Rotating - Rotating images clockwise or counterclockwise is done
on the touchpad by using two fingers.
To rotate an image, place two fingers on the touchpad then turn one
finger clockwise or counterclockwise while the other stays still.
Scrolling - Using two fingers on the touchpad, you can scroll
through lists vertically and horizontally.
To enable continuous scrolling, hold your fingers on the edge of
the touchpad when moving from up to down or left to right and
vice versa. The mouse pointer changes to a double-headed arrow
pointer when continuous scrolling is activated.
Zooming - Using two fingers on the touchpad, you can enlarge or
reduce the view size of your selected image.
Bring together or spread apart two fingers to zoom in or out.
56
Notebook PC User Manual
The touchpad responds to movement not to force. There is no
need to tap the surface too hard. Tapping too hard does not
increase the responsiveness of the touchpad. The touchpad
responds best to light pressure.
Caring for the touchpad
The touchpad is pressure sensitive. If not properly cared for, it can be
easily damaged. Take note of the following precautions.
• Ensure the touchpad does not come into contact with dirt, liquids or
grease.
• Do not touch the touchpad if your ngers are dirty or wet.
• Do not rest heavy objects on the touchpad or the touchpad
buttons.
• Do not scratch the touchpad with your nger nails or any hard
objects.
Three-finger swiping - Using three fingers on the touchpad, you
can swipe pages from left to right or right to left. You can also use
this gesture to switch between active windows on your desktop.
Notebook PC User Manual
57
Disabling the touchpad automatically
You can automatically disable the touchpad when an external USB
mouse is attached.
To disable the touchpad:
1. Go to Control Panel. Change view settings to Large Icons then
select Mouse.
2. Select the tab.ELAN
3. Tick the box with the Disable when external pointing device
plug in option.
4. Select to save current changes or Select to save Apply OK
changes then exit.
58
Notebook PC User Manual
Storage Devices
Storage devices allow the Notebook PC to read or write documents,
pictures, and other files to various data storage devices.
Optical Drive (on selected models)
Inserting an optical disc
1. While the Notebook PC’s power is ON, press the drive’s eject
button to partially eject the drive’s tray.
2. Gently pull the drive’s front panel to slide the tray out
completely. Be careful not to touch the optical drive lens and
other mechanisms. Ensure that there are no objects that may
get jammed under the drive’s tray.
Notebook PC User Manual
59
3. Hold the disc by the edge and face the disc’s printed side up.
Push down on both sides of the disc’s center until the disc snaps
onto the hub. The hub should be higher than the disc when
correctly mounted.
Place the disc completely inside the center hub to protect the
disc from scratches.
60
Notebook PC User Manual
Actual location will
vary by model.
Removing an optical disc
Eject the tray and gently pry the edge of the disc upwards at an
angle to remove the disc from the hub.
4. Slowly push the drive’s tray back in. The drive will begin reading
the table of contents (TOC) on the disc. Once the drive stops, the
disc is ready to be used.
While data is being read, it is normal to hear the spinning or
vibrating in the optical drive. To decrease vibration, use your
Notebook PC on a flat surface and do not place labels on the
optical disc.
Notebook PC User Manual
61
Emergency eject
The emergency eject is located in a hole on the optical drive and is
used to eject the optical drive tray in case the electronic eject does
not work. Do not use the emergency eject in place of the electronic
eject.
Ensure not to stab the activity indicator located in the same area.
Playing audio/video files using your optical drive
Optical drives provide you with the media to access data files and
play digital files such as audios and videos. You would need a specific
optical drive type to support higher disc formats such as DVDs and
Blu-ray discs.
Depending on your optical disc and its installed software, you
may be prompted to open a specific media player to open the
audio/video file. Once the file is opened, you can adjust the volume
settings using the hot keys on this Notebook PC or the speaker icon
on your desktop tray.
62
Notebook PC User Manual
Memory Card Reader
This Notebook PC has a single built-in memory card reader slot that
supports SD card formats, and utilizes the internal high-bandwidth
PCI bus.
To prevent data loss, use the Safely Remove Hardware and
Eject Media in the Windows® notification area before removing
the memory card.
Memory card compatibility varies depending on Notebook
PC model and memory card specifications. Memory card
specifications constantly change so compatibility may change
without warning.
Never remove cards while or immediately after reading, copying,
formatting, or deleting data on the card or else data loss may
occur.
SD
The memory card is purchased separately.
Notebook PC User Manual
63
Hard Disk Drive
Hard disk drives have higher capacities and operate at much faster
speeds than floppy disk drives and optical drives. The Notebook
PC comes with a replaceable hard disk drive. Current hard drives
support S.M.A.R.T. (Self Monitoring and Reporting Technology)
to detect hard disk errors or failures before they happen. When
replacing or upgrading the hard drive, always visit an authorized
service center or retailer for this Notebook PC.
Poor handling of the Notebook PC may damage the hard disk
drive. Handle the Notebook PC gently and keep it away from
static electricity and strong vibrations or impact. The hard disk
drive is the most delicate component and will likely be the
first or only component that is damaged if the Notebook PC is
dropped.
Disconnect all the connected peripherals, any telephone or
telecommunication lines and power connector (such as external
power supply, battery pack, etc.) before removing the hard disk
cover.
When replacing or upgrading the hard drive, always visit an
authorized service center or retailer for this Notebook PC.
The number of the hard disk drive varies with your purchased
model. The secondary hard disk drive bay may be empty.
Locating the hard disk drives
64
Notebook PC User Manual
Removing the hard disk drive
A
A
B
A
B
A
A
A
Notebook PC User Manual
65
Installing the hard disk drive
B
B
A
A
B
B
B
B
66
Notebook PC User Manual
Memory (RAM)
Additional memory will increase application performance by
decreasing hard disk access. Visit an authorized service center or
retailer for information on memory upgrades for your Notebook PC.
Only purchase expansion modules from authorized retailers of this
Notebook PC to ensure maximum compatibility and reliability.
The BIOS automatically detects the amount of memory in the system
and configures CMOS accordingly during the POST (Power-On-Self-
Test) process. There is no hardware or software (including BIOS)
setup required after the memory is installed.
Disconnect all the connected peripherals, any telephone or
telecommunication lines and power connector (such as external
power supply, battery pack, etc.) before installing or removing a
memory.
Locating the memory (RAM)
Notebook PC User Manual
67
Installing the memory (RAM)
A
A
B
A
B
B
B
A
68
Notebook PC User Manual
Removing the memory (RAM):
A
B
C
A
A
A
B
B
B
A
Notebook PC User Manual
69
Network Connections
Your Notebook PC allows you to connect to the internet and
other networks using the following wired and wireless network
connections.
Wired Network Connections
This Notebook PC supports wired network connections using
Fast/Gigabit Ethernet (1000 BASE-TX) and Twisted Pair Ethernet
technologies.
When using Fast (1000 BASE-TX) or Gigabit Ethernet, your network
cable must be category 5 or better with twisted-pair wiring. If
you plan on running the interface at 100/1000Mbps, it must be
connected to a 100 BASE-TX/1000 BASE-T hub.
When using Twisted Pair Ethernet (10Base-T), use category 3, 4, or 5
twisted-pair wiring. 10/100 Mbps Full-Duplex is supported on this
Notebook PC but requires connection to a network switching hub
with “duplex” enabled. The software default uses the fastest setting
so no user-intervention is required.
70
Notebook PC User Manual
Using a twisted-pair cable
The cable used to connect the Notebook PC to a host (generally a
Hub or Switch) is called a straight-through Twisted Pair Ethernet
(TPE). The end connectors are called RJ-45 connectors, which are
not compatible with RJ-11 telephone connectors. If connecting two
computers together without a hub in between, a crossover LAN
cable is required (Fast-Ethernet model).
The following illustration shows you how to connect the Notebook
PC to a local area network (LAN).
Network cable with
RJ-45 connectors
Network hub
LAN
Notebook PC
Notebook PC User Manual
71
Wireless Network Connections
Wireless LAN (WLAN)
This Notebook PC’s built-in WLAN is a compact and easy-to-use
wireless Ethernet adapter that implements the IEEE 802.11 standard.
It is capable of fast data transmission rates using Direct Sequence
Spread Spectrum (DSSS) and Orthogonal Frequency Division
Multiplexing (OFDM) technologies on 2.4GHz/5GHz frequencies.
The built-in WLAN is backward compatible with earlier IEEE
802.11 standards. To provide efficient security to your wireless
communication, the optional built-in wireless LAN comes with a
64-bit/128-bit Wired Equivalent Privacy (WEP) encryption and Wi-Fi
Protected Access (WPA) features.
For security concerns, DO NOT connect to an unsecured network;
otherwise, the information transmission without encryption might
be visible to others.
Using the WLAN network connection
1. Turn the Wireless function
ON, if necessary, using either
of the following options:
a. Press + until
the wireless LAN icon
and bluetooth icon (on
selected models) are
shown. Click on the WLAN
icon to activate the WLAN
function.
b. Double click the Wireless
Console icon on the
Windows® notification
area and select the WLAN
icon.
Bluetooth icon
WLAN icon
72
Notebook PC User Manual
3. Select the wireless access
point you want to connect
to from the list then click
Connect.
If you cannot find the
desired access point, click
the icon on Refresh
the upper right corner to
refresh and search in the
list again.
4. When connecting, you may have to enter a password.
5. After a connection has been established, the connection is
shown on the list and you can see the wireless network icon
on the Windows® Notification area.
2. Click the no wireless network
connection icon on the
Windows® Notification area.
Notebook PC User Manual
73
Using Ad-hoc mode and Infrastructure mode
The built-in WLAN in this Notebook PC is also a client adapter that
allows you to use the and modes when Ad-hoc Infrastructure
connecting to a network.
All devices must install optional 802.11 wireless LAN adapters to
use these modes.
Turn ON the WLAN function of your Notebook PC before using
the ad-hoc or infrastructure mode
Ad-hoc mode
The ad-hoc mode allows the Notebook PC to connect to
another Notebook PC or desktop PC without the need to setup
an access point. This mode allows you to share files and internet
connection within 30 feet.
To use the ad-hoc mode:
1. Click the wireless network icon on the Windows®
Notification area then click Open Network Sharing Center.
2. In the Network and Sharing Center dialog box, click Setup
a new connection or network.
3. Select Setup a wireless ad hoc (computer-to-computer)
network Next. then click
4. Follow the onscreen instructions to complete the setup
process.
74
Notebook PC User Manual
Infrastructure mode
The Infrastructure mode allows the Notebook PC and other
wireless devices to join a wireless network created by an access
point (sold separately) that provides a central link for wireless
clients to communicate with each other or with a wired network.
To use the infrastructure mode:
1. Click the wireless network icon on the Windows®
Notification area.then click Open Network Sharing Center.
2. In the Network and Sharing Center dialog box, click Setup
a new connection or network.
3. Select then click Set Up a Network Next.
4. Follow the onscreen instructions to complete the setup
process.
Notebook PC User Manual
75
Bluetooth allows you to access other devices such as Notebook PCs,
desktop PCs, tablets, and mobile phones that are also Bluetooth-
enabled. You can facilitate file transfers, use mobile phones as a
hotspot for internet connection, and share internet or network
connections with other devices using a Bluetooth connection.
If your Notebook PC did not come with a built-in Bluetooth, you
need to connect a USB or ExpressCard Bluetooth module to
create a Bluetooth connection.
Using your Bluetooth connection
The following steps can be used to add most Bluetooth devices and
establish a paired connection for data transfers:
Bluetooth Wireless Connection
(on selected models)
1. Turn the Wireless function
ON, if necessary, using either
of the following options:
a. Press + until
the wireless LAN icon
and bluetooth icon
(on selected models)
are shown. Click on the
Bluetooth icon to activate
the Bluetooth function.
b. Double click the Wireless
Console icon on the
Windows® Notification
area then click the
Bluetooth icon.
Bluetooth icon
WLAN icon
76
Notebook PC User Manual
2. Right-click on the Bluetooth
icon on the Windows®
Notification area then select
Add a device.
3. Select a Bluetooth-enabled
device from the list then click
Next.
4. Enter the Bluetooth security
code into your device to start
pairing.
5. Click to finish adding Close
the device.
Notebook PC User Manual
77
If your connected device overheats, remove it immediately.
USB Charger+ is available in your USB 3.0 charge port.
USB Charger+
USB Charger+ allows you to quick charge mobile devices via your
ASUS Notebook PC’s USB charge port.
Instant On
Instant On is a default-enabled feature in your ASUS Notebook PC
that allows you to save battery power while your Notebook PC is on
deep sleep mode (Deep S3). It also shows how long your Notebook
PC can run on standby using these two battery saving modes:
Performance mode Battery saving mode. and
Deep S3 is a technology that lets you save more battery power
while your ASUS Notebook PC is on sleep mode.
The standby time varies according to your Notebook PC's
remaining battery capacity, computer model, configuration, and
operating conditions.
Performance mode
The performance mode is default-
enabled in your Notebook PC. It
allows the system to return to its
last working state in two seconds,
even after your Notebook PC has
entered into deep sleep mode.
78
Notebook PC User Manual
Battery saving mode
The battery saving mode enables
longer standby times, allowing the
battery to last for up to thirty (30)
days or more. When you enable
this function, the system can
return to its last working state in
twelve seconds, four hours after
your Notebook PC has entered
into deep sleep mode.
Using Smart Logon in Instant On
Smart Logon allows you to use face
detection to quickly log in without
entering your username and
password.
To activate this feature, click Smart
Logon then follow the onscreen
instructions.
A
Appendix
A-2
Notebook PC User Manual
Optional Accessories
These items, if desired, come as optional items to complement your
Notebook PC.
USB Hub (Optional)
Attaching an optional USB hub will increase your USB ports and
allow you to quickly connect or disconnect many USB peripherals
through a single cable.
USB Flash Memory Disk
A USB flash memory disk is an optional item that can provide
storage up to several hundred megabytes, higher transfer speeds,
and greater durability. When used in current operating systems, no
drivers are necessary.
USB Floppy Disk Drive
An optional USB-interface floppy disk drive can accept a standard
1.44MB (or 720KB) 3.5-inch floppy diskette.
To prevent system failures, use Windows “Safely Remove
Hardware” on the taskbar before disconnecting the USB
floppy disk drive. Eject the floppy disk before transporting the
Notebook PC to prevent damage from shock.
Optional Connections
These items, if desired, may be purchased from third-parties.
USB Keyboard and Mouse
Attaching an external USB keyboard will allow data entry to be more
comfortable. Attaching an external USB mouse will allow Windows
navigation to be more comfortable. Both the external USB keyboard
and mouse will work simultaneously with the Notebook PC’s built-in
keyboard and touchpad.
Printer Connection
One or more USB printers can be simultaneously used on any USB
port or USB hub.
Notebook PC User Manual
A-3
Operating System and Software
This Notebook PC may offer (depending on territory) its customers
the choice of a pre-installed Microsoft Windows operating system.
The choices and languages will depend on the territory. The levels
of hardware and software support may vary depending on the
installed operating system. The stability and compatibility of other
operating systems cannot be guaranteed.
Support Software
This Notebook PC comes with a support disc that provides BIOS,
drivers and applications to enable hardware features, extend
functionality, help manage your Notebook PC, or add functionality
not provided by the native operating system. If updates or
replacement of the support disc is necessary, contact your dealer for
web sites to download individual software drivers and utilities.
The support disc contains all drivers, utilities and software for all
popular operating systems including those that have been pre-
installed. The support disc does not include the operating system
itself. The support disc is necessary even if your Notebook PC came
pre-configured in order to provide additional software not included
as part of the factory pre-install.
A recovery disc is optional and includes an image of the original
operating system installed on the hard drive at the factory. The
recovery disc provides a comprehensive recovery solution that
quickly restores the Notebook PC’s operating system to its original
working state provided that your hard disk drive is in good working
order. Contact your retailer if you require such a solution.
Some of the Notebook PC’s components and features may not
work until the device drivers and utilities are installed.
A-4
Notebook PC User Manual
System BIOS Settings
Boot Device
1. On the screen, select .Boot Boot Option #1
→← : Se lect S cr een
↑↓ : Se le ct It e m
Ente r : Sel ect
+/— : Ch an ge Opt .
F1 : Ge nera l H e lp
F9 : Op tim i zed Def a ults
F10 : Sa ve
ESC : Ex it
Vers i on 2. 1 4 .121 9 . C opyrigh t (C) 201 1 A m eric an M egat ren d s, I nc.
Apt i o Setup U t ilit y - Co py ri g h t (C ) 2 0 11 A m eri can Mega tren ds, Inc.
M a in Ad vanc ed C h ipse tMain Ad va nced Chip set S ecur it y Save & Ex itB oot
Boot Conf igur atio n
U EFI Boot [Dis able d]
PX E R OM [Dis able d]
B oot Opt ion P rior iti e s
B oot Opt ion # 1 [Win dows Boo t M anag. . .]
B oot Opt ion # 2 [P2: M A T SHIT AD VD -RA...]
C D/D VD RO M Dr i ve BB S Pr i o ri ti es
A dd N ew B oot Opti on
Del ete Bo o t Opt i o n
Sets t h e sys tem boo t order
2. Press [Enter] and select a device as the . Boot Option #1
Vers i on 2. 1 4 .121 9 . C opyrigh t (C) 201 1 A m eric an M egat ren d s, I nc.
Apt i o Setup U t ilit y - Co py ri g h t (C ) 2 0 11 A m eri can Mega tren ds, Inc.
M a in Ad vanc ed C h ipse tMain Ad va nced Chip set S ecur it y Save & Ex itB oot
Boot Conf igur atio n
U EFI Boot [Dis able d]
PX E R OM [Dis able d]
B oot Opt ion P rior iti e s
B oot Opt ion # 1 [P0: Hi tach i HT S5 4 5 ...]
B oot Opt ion # 2 [P2: M A T SHIT AD VD -RA...]
C D/D VD RO M Dr i ve BB S Pr i o ri ti es
A dd N ew B oot Opti on
Del ete Bo o t Opt i o n
Sets t h e sys tem boo t order
Boot Opt ion #1
The BIOS screens in this section are for reference only. The actual
screens may differ by models and territories.
→← : Se lect S cr een
↑↓ : Se le ct It e m
Ente r : Sel ect
+/— : Ch an ge Opt .
F1 : Ge nera l H e lp
F9 : Op tim i zed Def a ults
F10 : Sa ve
ESC : Ex it
Windows B o ot M a n ag er (PO: Hitachi HT S72757 5A9E364)
P2: M A T SHITA DVD- RAM UJ8C 2 S
Disa bled
Notebook PC User Manual
A-5
Security Setting
To set the password:
1. On the screen, select Security Administrator Password User or
Password.
2. Type in a password and press [Enter].
3. Re-type to confirm the password and press [Enter].
4. Password is then set.
To clear the password:
1. On the screen, select Security Administrator Password User or
Password.
2. Enter the current password and press [Enter].
3. Leave the Create New Password field blank and press [Enter].
4. Leave the Confirm New Password field blank and press [Enter].
5. Password is then cleared.
Vers i on 2 .1 4 .1 21 9 . C opyrigh t (C ) 20 1 1 Am er i can M eg a tr e nd s, I n c.
Ap t io Set u p U ti li ty - C o pyr i gh t (C ) 20 1 1 Am er i ca n M eg a tr e nds, In c .
Ma in Advan c e d B oo tMain A dvan ce d Bo o t S a v e & E x it Securi t y
Pas s wo r d D es cri p t ion
If ON LY t he Adm in istrat o r’s pas s w or d is s e t,
t h en t h is on l y l im its acce s s t o Se t up an d i s
on ly a s ked f or wh en ent e ri n g S et up.
If ON LY t he use r ’ s p a s sw ord i s se t , t hen t his
i s a p ow e r o n p ass w ord an d m us t b e e n tered t o
boo t o r e n ter Set up. In Se t up , t he U se r w il l
h ave A dm in istrat o r r i gh ts .
A d m inis t rat or P as s w or d St at u s NOT IN S TA LLE D
U se r P a ss w ord S ta t us NOT IN S TALLED
Adm in is tr at o r P a s sw o rd
U se r P a ss w ord
HD D Pa s sw o rd S t at us : NOT IN S TA LLE D
S e t Ma s te r P ass w or d
S e t User Pas s wo r d
I/O In terface S ecu r i ty
Set A dm in istrat o r P a s sw ord.
Th e p a s sw ord l en gt h mus t b e i n
th e f ol l ow in g r an g e:
Min im um l en gt h 3
Max i mum l e ngth 2 0
You will be asked to enter the User Password whenever
you power on the Notebook PC (enter BIOS or OS). The
Administrator Password is only asked when you would like to
enter and configure the BIOS settings.
→← : Sel e ct Scr e en
↑↓ : Sele c t I t em
Ent er : S e le c t
+/— : C h an ge O p t.
F1 : Gene r a l H el p
F9 : Opti m iz ed De f au l ts
F10 : S a v e
ESC : E xi t
A-6
Notebook PC User Manual
I/O Interface Security
To lock the I/O interface:
1. On the screen, select .Security I/O Interface Security
2. Select an interface you would like to lock and click Lock.
The settings can only be altered when I/O Interface Security
you log in with Administrator privilege.
Versi on 2 . 14.12 19. C opyri ght ( C) 20 11 A merica n M eg at ren ds, In c .
Aptio Setu p U ti lity - C op yri gh t (C) 2 0 1 1 Amer ican Megat rends , In c.
Se cu ri t y
I/O In terfa ce Se curit y
L A N an d C ar d Rea der I nterf ace [U n Lo ck]
W irele ss Ne t work Int e rface [UnLo ck]
H D A U D IO In terfa ce [UnLo ck]
S A TA O DD In terfa ce [UnLo ck]
USB Int e r face S e cur ity
If Locked, LAN an d C ard R eade r
Inter face wi ll be d i sable d .
LAN a n d C a rd Re ad e r In te r face
Loc k
U nLo c k
→← : Sel e c t S creen
↑↓ : Sel ect I te m
Enter : S e l e c t
+/— : Cha nge O pt .
F1 : Gen eral Help
F9 : Opt im iz ed Def aul ts
F10 : S av e
ESC : Exi t
Notebook PC User Manual
A-7
USB Interface Security
To lock the USB interface:
1. On the screen, select Security I/O Interface Security > USB
Interface Security.
2. Select an interface you would like to lock and click Lock.
The settings can only be altered when USB Interface Security
you log in with Administrator privilege.
If you set to [Lock], USB Interface External Ports CMOS and
Camera will be locked and hidden simultaneously.
Versi on 2 . 14.12 19. C opyri ght ( C) 20 11 A merica n M eg at ren ds, In c .
Aptio Setu p U ti lity - C op yri gh t (C) 2 0 1 1 Amer ican Megat rends , In c.
Se cu ri t y
U SB In terfa ce Se curit y
U SB In terfa ce [UnLo ck]
E xt e r n al Po rts [UnLo ck]
B l ueto ot h [UnLo ck]
C MO S C amera [UnLo ck]
If Locked, all USB d e vi ce will
be di sable d
USB I nt e rf ace
Loc k
U nLo c k
→← : Sel e c t S creen
↑↓ : Sel ect It e m
Enter : S e l e c t
+/— : Cha nge O pt .
F1 : Gen eral Help
F9 : Opt im iz ed Def aul ts
F10 : S av e
ESC : Exi t
A-8
Notebook PC User Manual
HDD Password
To set the HDD password:
1. On the screen, click Security Set Master Password, type in a
password and press [Enter].
2. Re-type to confirm the password and press [Enter].
3. Click Set User Password and repeat the previous steps to set
up the user password.
4. Password is then set.
• The HDD Password can only be altered when you log in with
Administrator privilege.
• You have to set Master Password User before setting the
Password.
You will be asked to enter user password first (if there is one),
then HDD user password when you power on the Notebook PC
and cannot enter the operating system if you fail to enter the
correct passwords.
Vers i on 2 .1 4 .1 21 9 . C opyrigh t (C ) 20 1 1 Am er i can M eg a tr e nd s, I n c.
Ap t io Set u p U ti li ty - C o pyr i gh t (C ) 20 1 1 Am er i ca n M eg a tr e nds, In c .
Ma in A dvan ce d Bo o t S ave & E xi t Securit y
Pas s wo r d D es cri p t ion
If ON LY t he Adm in istrat o r’s pas s w or d is s e t,
t h en t h is on l y l im its acce s s t o Se t up an d i s
on ly a s ked f or wh en ent e ri n g S et up.
If ON LY t he use r ’ s p a s sw ord i s se t , t hen t his
i s a p ow e r o n p ass w ord an d m us t b e e n tered t o
boo t o r e n ter Set up. In Se t up , t he U se r w il l
h ave A dm in istrat o r r i gh ts .
A d m inis t rat or P as s w or d St at u s NOT IN S TA LLE D
U se r P a ss w ord S ta t us NOT IN S TALLED
Adm i nistrat or P as s w or d
U se r P a ss w ord
HD D Pa s sw o rd S t at us : NOT IN S TA LLE D
Set M as te r P a s sw o rd
S e t User Pas s wo r d
I/O In terface S ecu r i ty
Set H DD M ast er P as s wo r d .
*** A dvi s abl e t o P ow e r C yc l e
Syst e m aft e r S e tt in g Ha r d D is k
Passw o r ds * **
→← : Sel e ct Scr e en
↑↓ : Sele c t I t em
Ent er : S e le c t
+/— : C h an ge O p t.
F1 : G e ne ral H e lp
F9 : O p ti mized De faults
F10 : S a v e
ESC : E xi t
Notebook PC User Manual
A-9
Save Changes
If you want to keep your configuration settings, you must save
changes before exiting the BIOS setup utility.
Vers i on 2 .1 4 .1 21 9 . C opyrigh t (C ) 20 1 1 Am er i can M eg a tr e nd s, I n c.
Ap t io Set u p U ti li ty - C o pyr i gh t (C ) 20 1 1 Am er i ca n M eg a tr e nds, In c .
Ma in Advan c e d C hipse t BootMain Ad v a n ce d C hipse t B o ot Se c u r it y Save & Ex it
Save C hange s an d E xit
Di s card C hange s a n d E xit
Sa v e O p t ions
Save C hanges
D is card C hange s
Rest o re Defaul t s
Bo o t O ve r r i de
W i ndows B o ot Ma na ger ( PO : H it ach i HT S7 27 57 5 A9 E3 64 )
P2 : M ATSH I T ADV D -R A M UJ8C 2 S
Laun ch E FI Sh el l from f il es y st em d e vi c e
Exi t sy s te m se t up af te r s a vin g
th e ch an ge s .
→← : Sel e ct Scr e en
↑↓ : S el ect It e m
Ent er : S e le c t
+/— : C h an ge O p t.
F1 : Gene r a l H el p
F9 : Opti m iz ed De f au l ts
F10 : S a v e
ESC : E xi t
A-10
Notebook PC User Manual
Troubleshooting
This section presents some common problems and possible
solutions for your Notebook PC.
The optical disc drive is not able to read or write discs.
• Update the BIOS to the latest version and try again.
• If updating the BIOS does not help, try better quality discs and
try again.
• If the problem still exist, contact your local service center and
ask an engineer for assistance.
The system cannot wake up from sleep or hibernate mode.
• Remove upgraded parts such as RAM, hard disk drive (HDD),
WLAN/Bluetooth module if they were installed after purchase.
• Run System Restore to restore the system to its factory default
setting.
• If the problem still persists, try restoring your system using the
system recovery partition function or the recovery DVD.
You must back up all your data to another location before
starting any recovery process.
• If the problem still exists, contact your local ASUS Service Center
for assistance.
The Hotkey function is disabled.
Reinstall the “ATK0100” driver from the driver CD or download it from
the ASUS website.
The built-in camera does not work properly.
• Check “Device Manager”.
• Try reinstalling the webcam driver.
Notebook PC User Manual
A-11
• If the problem is not solved, update the BIOS to the latest
version and try again.
• If the problem still exists, contact your local ASUS service center
for assistance.
Using the battery pack
• Register the Notebook PC for a one-year-warranty via this
website:
http://vip.asus.com/login.aspx
• Do NOT remove the battery pack while using the Notebook
PC with the AC adapter to prevent damage caused by the
accidental power loss. The ASUS battery pack has protection
circuitry to prevent over-charging so it will not damage the
battery pack if it is left in the Notebook PC.
I cannot power ON the Notebook PC.
• Check the power cord connections.
• Check if the battery pack is properly aligned at the notches and
fitted completely into the battery slot.
• If your Notebook PC is connected to the power adapter but does
not load the BIOS (appears as the ASUS logo) or the operating
system, the problem might be in the Notebook PC’s hard disk
drive. Contact your local ASUS Service Center for assistance.
• If your Notebook PC is connected to the power adapter and
shows the BIOS (appears as the ASUS logo) but does not load
the operating system, the problem might be in the Notebook
PC’s hard disk drive. Contact your local ASUS Service Center for
assistance.
Why is the cooling fan always ON and the temperature
high?
• Ensure that the FAN works when the CPU temperature is high
and check whether there is air flow from the main air vent.
A-12
Notebook PC User Manual
• Close some running applications to decrease the system load.
• Check your system for viruses.
•
Try restoring your system using the system recovery partition or the
recovery DVD.
You must back up all your data to another location before doing
the recovery process.
Install an anti-virus software to protect the system from viruses.
When I turn the power ON, my Notebook PC displays this
message: “Open policy file error”.
Reinstall the latest “Power4 Gear” utility which you can download
from the ASUS website.
A blue screen with white text appears after system bootup.
• Remove the additional memory. If an additional memory was
installed after purchase, power OFF, remove the additional
memory, and power ON to see if the problem is due to
incompatible memory.
• Remove software applications. If you have installed software
applications recently, they may not be compatible with your
system. Try to delete them in Windows Safe Mode.
• Check your system for viruses.
• Update the BIOS to the latest version with Easy Flash in
Windows or AFLASH in DOS mode. These utilities and BIOS files
can be downloaded from the ASUS website.
Ensure your Notebook PC does not lose power during the BIOS
flashing process.
•
Try restoring your system using the system recovery partition or the
recovery DVD.
Notebook PC User Manual
A-13
You must back up all your data to another location before doing
the recovery process.
Install an anti-virus software to protect the system from viruses.
Ensure that you install the “Intel INF Update” and “ATKACPI”
drivers first so that hardware devices can be recognized.
• If the problem still exists, contact your local ASUS Service Center
for assistance.
A-14
Notebook PC User Manual
Updating the BIOS.
1. Please verify the Notebook PC’s exact model and download the
latest BIOS file for your model from the ASUS website and save
it in your flash disk drive.
2. Connect your flash disk drive to the Notebook PC and power on
the Notebook PC.
3. From the BIOS Setup program, click Advanced > Start Easy
Flash, then press [Enter].
4. Locate the latest BIOS file and start updating the BIOS.
ASU STe k E asy Fl ash U tili ty
[ ]: Swi tch [ ] : Ch oos e [q ] : Ex it [En ter ]: Ent er/ E x e cut e
0 E FI <DI R>
FLA SH T YP E: Win bon d 2 5X / Q S eri es
C urrent BI OS
Pl a tfo rm: K56 CA
Versio n: 10 0
Bui ld Dat e: May 11 2 0 12
Bui ld Tim e: 09: 53: 29
Ne w BIOS
Pl a tfo rm: Unkn ow n
Versio n: U nkno wn
Bui ld Dat e: Unknow n
Bui ld Tim e: Un k now n
5. After the BIOS update process, click to Exit > Restore Defaults
restore the system to its default settings.
Versio n 2 .12 .12 19. Co pyr igh t ( C) 2 01 1 A mer ica n M ega tre nds , I nc.
Apt io Set up Uti lit y - C o pyr igh t ( C ) 201 1 A mer ica n M ega tre nds , I nc.
Mai nMai n C hipset Bo ot Sec uri ty Sav e & Ex itA d va n ce d
POS T L ogo Ty pe [St ati c]
St a rt Eas y F las h
Pla y P OST So un d [No ]
Spe ake r V olu me [4]
In t ern al Poi nti n g Device [En abl ed]
Wak e O n Lid Ope n [En abl ed]
ASU S U SB Ch a rge r+ in bat tery m ode [Di sab led ]
In t el V ir tua liz ati on T ec hno l og y [En abl ed]
In t el A ES -NI [En abl ed]
VT- d [En abl ed]
SA TA Con figura t i o n
Gr aph ics C o nfi gur ati on
In tel (R ) A nti -Th eft Te chn ol o gy Con fig ura t i o n
US B C on f igu rat ion
Ne two rk Sta ck
Pre ss ENT ER t o run t h e u t il ity
to sel ect an d u pda te BIO S.
FS0
FS1
→← : S el e ct Scr een
↑↓ : S ele ct Ite m
Ent er : Sel ect
+/— : C han ge Opt .
F1 : G ene ral He lp
F9 : O pti miz ed Def aul ts
F10 : S ave
ESC : E xit
Notebook PC User Manual
A-15
Using the Recovery Partition DVD Recoveryor the (for selected
models) allows you to reformat your hard drive and restore your
ASUS Notebook PC to its original factory settings. These recovery
options also enable you to reuse the default settings of your
Notebook PC to make new changes as needed.
Back up all your data before performing system recovery in your
Notebook PC.
You may need to reinstall some software applications after the
recovery process is completed. You may also be required to buy
a new license to reactivate the software.
Do not restart or turn off your Notebook PC during the recovery
process.
Using Recovery Partition
The Recovery Partition is a reserved space in your Notebook PC's
hard disk drive where you can restore the operating system, drivers,
and utilities to their original factory settings. To use this option:
1. Press [F9] during bootup.
2. In the Windows Boot Manager, the system automatically loads
the files for recovery. You can also use the up/down arrow keys
to select Windows 7 Windows Setup [EMS Enabled], or then
press [Enter].
3. Read the ASUS Preload Wizard messages then click .Next
4. Select from the following partition options:
Recover Windows to first partition only.
This option deletes only the first partition and allows you to keep other
partitions, and to create a new system partition as drive “C”.
Recovery options for your
Notebook PC
A-16
Notebook PC User Manual
Recover Windows to entire HD.
This option deletes all partitions from your hard disk drive and
creates a new system partition as drive “C”.
Recover Windows to entire HD with two partitions.
This option deletes all partitions from your hard drive and creates two
new partitions “C” (40%) and “D” (60%).
5. Follow the onscreen instructions to complete the recovery
process.
The Recovery Partition is created at the factory and cannot be
restored if deleted. Take your Notebook PC to an authorized
ASUS service center if you have problems with the recovery
process.
Visit the ASUS website at www.asus.com for updated drivers and
utilities.
Using DVD Recovery (on selected models)
AI Recovery
The AI Recovery is a DVD Recovery process that allows you to back
up les and automatically create your own recovery discs from your
Notebook PC.
Do not restart or turn off your Notebook PC during the recovery
process.
To use the AI Recovery:
1. Click the icon on your desktop then select ASUS Backup and
Restore > AI Recovery Burner.
2. Choose from the following AI Recovery options:
• Backup to DVD/BD.
If you choose this option, insert a blank writable DVD/BD
into the optical drive then click Backup.
Notebook PC User Manual
A-17
Using the Recovery DVD:DVD::
Do not restart or turn off your Notebook PC during the recovery
process. Do not remove the Recovery disc, unless instructed to
do so, during the recovery process or else your partitions will be
unusable.
Ensure to connect the power adapter to your Notebook PC when
performing system recovery. Unstable power supply may cause
recovery failure.
Visit the ASUS website at www.asus.com for updated drivers and
utilities.
Restoring will overwrite your hard drive. Ensure to back up all
your important data before the system recovery.
1. Insert the Recovery DVD into the optical drive. Your Notebook PC
needs to be powered ON.
2. Restart the Notebook PC and press [Esc] on bootup and select the
optical drive (may be labeled as “CD/DVD”) and press [Enter] to
boot from the Recovery DVD.
3. Select to restore the image.OK
4. Select to conrm the system recovery.OK
5. Follow the onscreen instructions to complete the recovery
process.
• Create ISO backup files for DVD.
• Create ISO backup files for Blu-Ray disc.
If you choose to create ISO backup les, select the path
where you want to save the ISO les then click Backup.
3. Follow the onscreen instructions to complete creating the
recovery DVD/BD or the ISO backup les.
Ensure to burn your ISO les to a DVD or Blu-ray disc so you can
use them to recover your Notebook PC.
A-18
Notebook PC User Manual
DVD-ROM Drive Information
(on selected models)
The DVD-ROM drive allows you to view and create your own CDs
and DVDs. You can purchase an optional DVD viewer software to
view DVD titles.
Regional Playback Information
Playback of DVD movie titles involves decoding MPEG2 video, digital
AC3 audio and decryption of CSS protected content. CSS (sometimes
called copy guard) is the name given to the content protection
scheme adopted by the motion picture industry to satisfy a need to
protect against unlawful content duplication.
Although the design rules imposed on CSS licensors are many, one rule
that is most relevant is playback restrictions on regionalized content. In
order to facilitate geographically staggered movie releases, DVD video
titles are released for specific geographic regions as defined in “Region
Definitions” below. Copyright laws require that all DVD movies be
limited to a particular region (usually coded to the region at which it is
sold). While DVD movie content may be released for multiple regions,
CSS design rules require that any system capable of playing CSS
encrypted content must only be capable of playing one region.
The region setting may be changed up to five times using the
viewer software, then it can only play DVD movies for the last
region setting. Changing the region code after that will require
factory resetting which is not covered by warranty. If resetting
is desired, shipping and resetting costs will be at the expense of
the user.
Notebook PC User Manual
A-19
Region Definitions
Region 1
Canada, US, US Territories
Region 2
Czech, Egypt, Finland, France, Germany, Gulf States, Hungary, Iceland,
Iran, Iraq, Ireland, Italy, Japan, Netherlands, Norway, Poland, Portugal,
Saudi Arabia, Scotland, South Africa, Spain, Sweden, Switzerland,
Syria, Turkey, UK, Greece, Former Yugoslav Republics, Slovakia
Region 3
Burma, Indonesia, South Korea, Malaysia, Philippines, Singapore,
Taiwan, Thailand, Vietnam
Region 4
Australia, Caribbean (Except US Territories), Central America, New
Zealand, Pacic Islands, South America
Region 5
CIS, India, Pakistan, Rest of Africa, Russia, North Korea
Region 6
China
A-20
Notebook PC User Manual
Blu-ray ROM Drive Information
(on selected models)
The Blu-ray ROM Drive allows you to view high denition (HD) videos
and other disc le formats such as DVDs and CDs.
Region Denitions
Region A
North, Central and South American countries, and their territories;
Taiwan, Hong Kong, Macao, Japan, Korea (South and North), South
East Asian countries and their territories.
Region B
European, African, and South West Asian countries and their
territories; Australia and New Zealand.
Region C
Central, South Asian, Eastern European countries and their territories;
China and Mongolia.
Refer to Blu-ray Disc website at www.blu-raydisc.com/en/
Technical/FAQs/Blu-rayDsicforVideo.html for more details.
Notebook PC User Manual
A-21
Internal Modem Compliancy
The Notebook PC with internal modem model complies with
JATE (Japan), FCC (US, Canada, Korea, Taiwan), and CTR21. The
internal modem has been approved in accordance with Council
Decision 98/482/EC for pan-European single terminal connection
to the public switched telephone network (PSTN). However due
to differences between the individual PSTNs provided in different
countries, the approval does not, of itself, give an unconditional
assurance of successful operation on every PSTN network
termination point. In the event of problems you should contact your
equipment supplier in the rst instance.
Overview
On 4th August 1998 the European Council Decision regarding the
CTR 21 has been published in the Ofcial Journal of the EC. The CTR
21 applies to all non voice terminal equipment with DTMF-dialling
which is intended to be connected to the analogue PSTN (Public
Switched Telephone Network).
CTR 21 (Common Technical Regulation) for the attachment
requirements for connection to the analogue public switched
telephone networks of terminal equipment (excluding terminal
equipment supporting the voice telephony justied case service)
in which network addressing, if provided, is by means of dual tone
multifrequency signalling.
Network Compatibility Declaration
Statement to be made by the manufacturer to the Notied Body and
the vendor: “This declaration will indicate the networks with which
the equipment is designed to work and any notied networks with
which the equipment may have inter-working difculties”
A-22
Notebook PC User Manual
Network Compatibility Declaration
Statement to be made by the manufacturer to the user: “This
declaration will indicate the networks with which the equipment
is designed to work and any notied networks with which the
equipment may have inter-working difculties. The manufacturer
shall also associate a statement to make it clear where network
compatibility is dependent on physical and software switch settings.
It will also advise the user to contact the vendor if it is desired to use
the equipment on another network.”
Up to now the Notied Body of CETECOM issued several pan-
European approvals using CTR 21. The results are Europe’s rst
modems which do not require regulatory approvals in each
individual European country.
Non-Voice Equipment
Answering machines and loud-speaking telephones can be eligible
as well as modems, fax machines, auto-dialers and alarm systems.
Equipment in which the end-to-end quality of speech is controlled
by regulations (e.g. handset telephones and in some countries also
cordless telephones) is excluded.
Notebook PC User Manual
A-23
This table shows the countries currently under the CTR21
standard.
Country Applied More Testing
Austria
1
Yes No
Belgium Yes No
Czech Republic No Not Applicable
Denmark
1
Yes Yes
Finland Yes No
France Yes No
Germany Yes No
Greece Yes No
Hungary No Not Applicable
Iceland Yes No
Ireland Yes No
Italy Still Pending Still Pending
Israel No No
Lichtenstein Yes No
Luxemburg Yes No
The Netherlands
1
Yes Yes
Norway Yes No
Poland No Not Applicable
Portugal No Not Applicable
Spain No Not Applicable
Sweden Yes No
Switzerland Yes No
United Kingdom Yes No
A-24
Notebook PC User Manual
This information was copied from CETECOM and is supplied without
liability. For updates to this table, you may visit http://www.cetecom.
de/technologies/ctr_21.html
1 National requirements will apply only if the equipment may use
pulse dialling (manufacturers may state in the user guide that the
equipment is only intended to support DTMF signalling, which
would make any additional testing superuous).
In The Netherlands additional testing is required for series
connection and caller ID facilities.
Notebook PC User Manual
A-25
Declarations and Safety Statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to
the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a class B digital device, pursuant to Part 15 of the Federal
Communications Commission (FCC) rules. These limits are designed
to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
The use of a shielded-type power cord is required in order to
meet FCC emission limits and to prevent interference to the
nearby radio and television reception. It is essential that only
the supplied power cord be used. Use only shielded cables to
connect I/O devices to this equipment. You are cautioned that
changes or modications not expressly approved by the party
responsible for compliance could void your authority to operate
the equipment.
A-26
Notebook PC User Manual
(Reprinted from the Code of Federal Regulations #47, part 15.193, 1993.
Washington DC: Office of the Federal Register, National Archives and
Records Administration, U.S. Government Printing Office.)
FCC Radio Frequency (RF) Exposure Caution
Statement
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate this equipment. “The manufacture declares that
this device is limited to Channels 1 through 11 in the 2.4GHz
frequency by specified firmware controlled in the USA.”
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. To maintain compliance with FCC
RF exposure compliance requirements, please avoid direct contact
to the transmitting antenna during transmitting. End users must
follow the specific operating instructions for satisfying RF exposure
compliance.
Declaration of Conformity
(R&TTE directive 1999/5/EC)
The following items were completed and are considered relevant
and sufficient:
• Essential requirements as in [Article 3]
• Protection requirements for health and safety as in [Article 3.1a]
• Testing for electric safety according to [EN 60950]
• Protection requirements for electromagnetic compatibility in
[Article 3.1b]
• Testing for electromagnetic compatibility in [EN 301 489-1] & [EN
301 489-17]
• Effective use of the radio spectrum as in [Article 3.2]
Notebook PC User Manual
A-27
CE Marking
CE marking for devices without wireless LAN/Bluetooth
The shipped version of this device complies with the requirements
of the EEC directives 2004/108/EC “Electromagnetic compatibility”
and 2006/95/EC “Low voltage directive”.
CE marking for devices with wireless LAN/ Bluetooth
This equipment complies with the requirements of Directive 1999/5/
EC of the European Parliament and Commission from 9 March, 1999
governing Radio and Telecommunications Equipment and mutual
recognition of conformity.
IC Radiation Exposure Statement for Canada
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. To maintain compliance with IC
RF exposure compliance requirements, please avoid direct contact
to the transmitting antenna during transmitting. End users must
follow the specic operating instructions for satisfying RF exposure
compliance.
Operation is subject to the following two conditions:
• This device may not cause interference and
• This device must accept any interference, including interference
that may cause undesired operation of the device.
To prevent radio interference to the licensed service (i.e. co-channel
Mobile Satellite systems) this device is intended to be operated
indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is
subject to licensing.
A-28
Notebook PC User Manual
Wireless Operation Channel for Different Domains
N. America 2.412-2.462 GHz Ch01 through CH11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
France Restricted Wireless Frequency Bands
Some areas of France have a restricted frequency band. The worst
case maximum authorized power indoors are:
• 10mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
• 100mW for frequencies between 2446.5 MHz and 2483.5 MHz
Channels 10 through 13 inclusive operate in the band 2446.6 MHz to
2483.5 MHz.
There are few possibilities for outdoor use: On private property or on
the private property of public persons, use is subject to a preliminary
authorization procedure by the Ministry of Defense, with maximum
authorized power of 100mW in the 2446.5–2483.5 MHz band. Use
outdoors on public property is not permitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximum authorized power indoors is 100mW
• Maximum authorized power outdoors is 10mW
Departments in which the use of the 2400–2483.5 MHz band is
permitted with an EIRP of less than 100mW indoors and less than
10mW outdoors:
01 Ain 02 Aisne 03 Allier
05 Hautes Alpes 08 Ardennes 09 Ariège
11 Aude 12 Aveyron 16 Charente
24 Dordogne 25 Doubs 26 Drôme
32 Gers 36 Indre 37 Indre et Loire
41 Loir et Cher 45 Loiret 50 Manche
55 Meuse 58 Nièvre 59 Nord
Notebook PC User Manual
A-29
60 Oise 61 Orne
63 Puy du Dôme 64 Pyrénées Atlantique
66 Pyrénées Orientales 67 Bas Rhin
68 Haut Rhin 70 Haute Saône
71 Saône et Loire 75 Paris
82 Tarn et Garonne 84 Vaucluse
88 Vosges 89 Yonne
90 Territoire de Belfort 94 Val de Marne
This requirement is likely to change over time, allowing you to use
your wireless LAN card in more areas within France. Please check
with ART for the latest information (www.arcep.fr)
Your WLAN Card transmits less than 100mW, but more than
10mW.
A-30
Notebook PC User Manual
UL Safety Notices
Required for UL 1459 covering telecommunications (telephone)
equipment intended to be electrically connected to a
telecommunication network that has an operating voltage to
ground that does not exceed 200V peak, 300V peak-to-peak, and
105V rms, and installed or used in accordance with the National
Electrical Code (NFPA 70).
When using the Notebook PC modem, basic safety precautions
should always be followed to reduce the risk of fire, electric shock,
and injury to persons, including the following:
• DO NOT use the Notebook PC near water, for example, near
a bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
• DO NOT use the Notebook PC during an electrical storm. There
may be a remote risk of electric shock from lightning.
• DO NOT use the Notebook PC in the vicinity of a gas leak.
Required for UL 1642 covering primary (nonrechargeable) and
secondary (rechargeable) lithium batteries for use as power sources
in products. These batteries contain metallic lithium, or a lithium
alloy, or a lithium ion, and may consist of a single electrochemical
cell or two or more cells connected in series, parallel, or both, that
convert chemical energy into electrical energy by an irreversible or
reversible chemical reaction.
• Do not dispose the Notebook PC battery pack in a fire, as
they may explode. Check with local codes for possible special
disposal instructions to reduce the risk of injury to persons due
to fire or explosion.
• Do not use power adapters or batteries from other devices to
reduce the risk of injury to persons due to fire or explosion. Use
only UL certified power adapters or batteries supplied by the
manufacturer or authorized retailers.
Notebook PC User Manual
A-31
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more
than 3Kg must use approved power cords greater than or equal to:
H05VV-F, 3G, 0.75mm
2
or H05VV-F, 2G, 0.75mm
2
.
REACH
Complying with the REACH (Registration, Evaluation, Authorization,
and Restriction of Chemicals) regulatory framework, we publish
the chemical substances in our products at ASUS REACH website at
http://csr.asus.com/english/REACH.htm.
TV Tuner Notices
Note to CATV System Installer—Cable distribution system should be
grounded (earthed) in accordance with ANSI/NFPA 70, the National
Electrical Code (NEC), in particular Section 820.93, Grounding of
Outer Conductive Shield of a Coaxial Cable – installation should
include bonding the screen of the coaxial cable to the earth at the
building entrance.
A-32
Notebook PC User Manual
Nordic Lithium Cautions (for lithium-ion batteries)
CAUTION! Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions. (English)
ATTENZIONE! Rischio di esplosione della batteria se sostituita in
modo errato. Sostituire la batteria con un una di tipo uguale o
equivalente consigliata dalla fabbrica. Non disperdere le batterie
nell’ambiente. (Italian)
VORSICHT! Explosionsgefahr bei unsachgemäßen Austausch der
Batterie. Ersatz nur durch denselben oder einem vom Hersteller
empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien
nach Angaben des Herstellers. (German)
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kun ske med batteri af samme fabrikat og type. Levér
det brugte batteri tilbage til leverandøren. (Danish)
VARNING! Explosionsfara vid felaktigt batteribyte. Använd
samma batterityp eller en ekvivalent typ som rekommenderas
av apparattillverkaren. Kassera använt batteri enligt fabrikantens
instruktion. (Swedish)
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda
paristo ainoastaan laitevalmistajan sousittelemaan tyyppiin. Hävitä
käytetty paristo valmistagan ohjeiden mukaisesti. (Finnish)
ATTENTION! Il y a danger d’explosion s’il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie du mêre
type ou d’un type équivalent recommandé par le constructeur.
Mettre au rebut les batteries usagées conformément aux instructions
du fabricant. (French)
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt
av apparatfabrikanten. Brukte batterier kasseres i henhold til
fabrikantens instruksjoner. (Norwegian)
(Japanese)
ВНИМАНИЕ! При замене аккумулятора на аккумулятор иного
типа возможно его возгорание. Утилизируйте аккумулятор в
соответствии с инструкциями производителя. (Russian)
Notebook PC User Manual
A-33
Optical Drive Safety Information
Laser Safety Information
Internal or external optical drives sold with this Notebook PC
contains a CLASS 1 LASER PRODUCT.
Making adjustments or performing procedures other than those
specified in the user’s manual may result in hazardous laser
exposure. Do not attempt to disassemble the optical drive. For
your safety, have the optical drive serviced only by an authorized
service provider.
Service warning label
INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO
BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the
U.S. Food and Drug Administration implemented regulations
for laser products on August 2, 1976. These regulations apply to
laser products manufactured from August 1, 1976. Compliance is
mandatory for products marketed in the United States.
Use of controls or adjustments or performance of procedures
other than those specified herein or in the laser product
installation guide may result in hazardous radiation exposure.
A-34
Notebook PC User Manual
Macrovision Corporation Product Notice
This product incorporates copyright protection technology that
is protected by method claims of certain U.S.A. patents and other
intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only
unless otherwise
authorized by Macrovision Corporation
. Reverse engineering or
disassembly is prohibited.
Notebook PC User Manual
A-35
CTR 21 Approval
(for Notebook PC with built-in Modem)
Danish
Dutch
English
Finnish
French
German
Greek
Italian
Portuguese
Notebook PC User Manual
A-37
European Union Eco-label
This Notebook PC has been awarded the EU Flower label, which
means that this product has the following characteristics:
1. Decreased energy consumption during use and stand-by
modes.
2. Limited use of toxic heavy metals.
3. Limited use of substances harmful to the environment and
health.
4. Reduction of the use of natural resources by encouraging
recycling.
5. Designed for easy upgrades and longer lifetime through
providing compatible spare parts such as batteries, power
supplies, the keyboard, the memory, and if available the CD drive
or DVD drive.
6. Reduced solid waste through takeback policy.
For more information on the EU Flower label, please visit the
European Union Eco-label website at http://www.ecolabel.eu.
ENERGY STAR complied product
ENERGY STAR is a joint program of the U.S.
Environmental Protection Agency and the U.S.
Department of Energy helping us all save money
and protect the environment through energy
efficient products and practices.
All ASUS products with the ENERGY STAR logo
comply with the ENERGY STAR standard, and the power management
feature is enabled by default. The monitor and computer are
automatically set to sleep after 15 and 30 minutes of user inactivity.
To wake your computer, click the mouse or press any key on the
keyboard. Please visit http://www.energy.gov/powermanagement
for detail information on power management and its benefits to the
environment. In addition, please visit http://www.energystar.gov for
detail information on the ENERGY STAR joint program.
Energy Star is NOT supported on Freedos and Linux-based
products.
Produkt Specifikationer
| Mærke: | Asus |
| Kategori: | Bærbare computer |
| Model: | S46CA-WX158H |
| Bredde: | 348 mm |
| Dybde: | 248 mm |
| Højde: | 21 mm |
| Vægt: | 2000 g |
| Produktfarve: | Sort, sølv |
| Batterikapacitet: | 2950 mAh |
| Produkttype: | Notebook |
| Skærm diagonal: | 14 " |
| Skærmopløsning: | 1366 x 768 pixel |
| Berøringsskærm: | Ingen |
| Kompatible hukommelseskort: | SD |
| Front kamera: | Ja |
| Wi-Fi: | Ja |
| Bluetooth: | Ingen |
| Formfaktor: | Muslingeskal |
| HD-type: | HD |
| Naturligt aspektforhold: | 16:9 |
| Antal HDMI-porte: | 1 |
| DVI-port: | Ingen |
| Ethernet LAN-porte (RJ-45): | 1 |
| Antal USB 2.0-porte: | 2 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 1 |
| Ethernet LAN: | Ja |
| Wi-Fi-standarder: | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Processorkerner: | 2 |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Intern hukommelse: | 8 GB |
| Indgangsspænding for vekselstrømsadapter: | 100 - 240 V |
| Frekvens for vekselstrømsadapter: | 50 - 60 Hz |
| Udgangsspænding for vekselstrømsadapter: | 19 V |
| Operativsystem installeret: | Windows 8 |
| Indbygget kortlæser: | Ja |
| HDD kapacitet: | 500 GB |
| LED-baggrundsbelysning: | Ja |
| Batterilevetid (maks.): | - t |
| Intel® Wireless Display (Intel® WiDi): | Ja |
| Processorfrekvens: | 1.7 GHz |
| Processorserie: | Intel® Core™ i5 |
| Processor boost frekvens: | 2.6 GHz |
| Processortråde: | 4 |
| Processor-cache: | 3 MB |
| Processor cache type: | Smart cache |
| Intern hukommelsestype: | DDR3-SDRAM |
| Hukommelsesur hastighed: | 1600 Mhz |
| Maksimal intern hukommelse: | 8 GB |
| Hukommelse form faktor: | SO-DIMM |
| Samlet lagringskapacitet: | 500 GB |
| Lagermedie: | HDD+SSD |
| On-board grafikkort, model: | Intel® HD Graphics 4000 |
| Diskret grafikadaptermodel: | Ikke tilgængelig |
| On-board grafikkort: | Ja |
| Diskret grafikadapter: | Ingen |
| Indbygget grafikadapterfamilie: | Intel® HD Graphics |
| Indbygget mikrofon: | Ja |
| Mikrofonindgang: | Ingen |
| S/PDIF-udgang: | Ingen |
| Docking-stik: | Ingen |
| ExpressCard-slot: | Ingen |
| Cardbus PCMCIA slot type: | Ingen |
| Smartcard slot: | Ingen |
| Opladningsport type: | DC-in-stik |
| Pegeredskab: | Touchpad |
| Numerisk tastatur: | Ingen |
| Intel® Hyper Threading Teknologi (Intel® HT Technology): | Ja |
| Intel® Turbo Boost Teknologi: | 2.0 |
| Vekselstrømsadapter strøm: | 65 W |
| Slot til kabellås: | Ingen |
| Hukommelsesstik: | 2x SO-DIMM |
| Processorproducent: | Intel |
| Processormodel: | i5-3317U |
| Antal VGA-porte (D-sub): | 1 |
| Antal installerede SSD'er: | 1 |
| SDD-kapacitet: | 24 GB |
| Optisk drevtype: | DVD Super Multi |
| Kombineret hovedtelefon/mikrofon-port: | Ja |
| Antal battericeller: | 4 |
| Vekselstrømsadapterens udgangsstrøm: | 3.42 A |
| Enhanced Intel SpeedStep Teknologi: | Ja |
| Udfør deaktivering af bit: | Ja |
| Idle status: | Ja |
| CPU-konfiguration (maks.): | 1 |
| Intel® VT-x with Extended Page Tables (EPT): | Ja |
| Indlejret tilgængelige muligheder: | Ingen |
| Intel® 64: | Ja |
| Intel® Virtualization Technology for Directed I/O (VT-d): | Ja |
| Intel® Virtualization Technology (VT-x): | Ja |
| HDD-grænseflade: | SATA |
| Windows taster: | Ja |
| Bus type: | DMI |
| Processorgeneration: | 3rd gen Intel® Core™ i5 |
| Intel® Flex Memory Access: | Ja |
| Intel® Trusted Execution Teknologi: | Ingen |
| Intel® Enhanced Halt State: | Ja |
| Intel® klar video teknologi: | Ingen |
| Intel® Identity Protection Technology version: | 1.00 |
| Intel® Secure Key Technology version: | 1.00 |
| Konfliktfri processor: | Ja |
| HDD-størrelse: | 2.5 " |
| HDD hastighed: | 5400 rpm |
| Processor sokkel: | BGA 1023 |
| Processor litografi: | 22 nm |
| Stepping: | L1 |
| Thermal Design Power (TDP): | 17 W |
| Maksimalt antal PCI Express-kanaler: | 16 |
| PCI Express slots version: | 2.0 |
| PCI Express-konfigurationer: | 1x16,2x8,1x8+2x4 |
| Fejlkorrigerende kode understøttet af processor: | Ingen |
| Tjunction: | 105 °C |
| Processor front side bus: | - Mhz |
| Systembus-hastighed: | 5 GT/s |
| Processor driftstilstande: | 64-bit |
| Processor kodenavn: | Ivy Bridge |
| FSB Paritet: | Ingen |
| Integreret 4G WiMAX: | Ja |
| Intel® InTru™ 3D Teknologi: | Ja |
| Intel® Clear Video HD Teknologi (Intel® CVT HD): | Ja |
| Intel® Insider™: | Ja |
| Intel® Sikker Nøgle: | Ja |
| Intel® My WiFi Teknologi (Intel® MWT): | Ja |
| Intel® Anti-Theft Teknologi (Intel® AT): | Ja |
| Intel® Identity Protection Teknologi (Intel® IPT): | Ja |
| Intel® Quick Sync Video Teknologi: | Ja |
| Intel® AES Nye Instruktioner (Intel® AES-NI): | Ja |
| Intel® Demand Based Switching: | Ingen |
| Termiske overvågningsteknologier: | Ja |
| Intel® Dual Display Capable Teknologi: | Ja |
| Intel® FDI Teknologi: | Ja |
| Intel® Rapid Storage Teknologi: | Ingen |
| Intel® Fast Memory Access: | Ja |
| Intel® Clear Video Teknologi til MID (Intel® CVT for MID): | Ingen |
| Processor-pakke størrelse: | 31.0 x 24.0 mm |
| Processor kode: | SR0N8 |
| Grafisk og IMC litografi: | 22 nm |
| Processor ARK ID: | 65707 |
| Antal installerede HDD'er: | 1 |
| Indbygget grafikadapter basefrekvens: | 350 Mhz |
| Indbygget grafikadapter dynamisk frekvens (maks.): | 1050 Mhz |
| CPU-multiplikator (bus/kerneforhold): | 17 |
| Indbygget grafikadapter-ID: | 0x166 |
| Understøttede instruktionssæt: | AVX |
| Intel® Smart Cache: | Ja |
| Bundkort chipsæt: | Intel® HM76 Express |
Har du brug for hjælp?
Hvis du har brug for hjælp til Asus S46CA-WX158H stil et spørgsmål nedenfor, og andre brugere vil svare dig
Bærbare computer Asus Manualer
23 August 2024
10 Juli 2024
27 Maj 2024
25 Maj 2024
19 Maj 2024
15 Maj 2024
13 Maj 2024
12 Maj 2024
12 Maj 2024
11 Maj 2024
Bærbare computer Manualer
- Bærbare computer Razor
- Bærbare computer Xplore
- Bærbare computer Acer
- Bærbare computer Hyundai
- Bærbare computer Huawei
- Bærbare computer Hannspree
- Bærbare computer Fujitsu
- Bærbare computer Schneider
- Bærbare computer Gigabyte
- Bærbare computer BenQ
- Bærbare computer Krüger&Matz
- Bærbare computer Archos
- Bærbare computer Sony
- Bærbare computer Zebra
- Bærbare computer Samsung
Nyeste Bærbare computer Manualer
9 Juni 2025
9 Juni 2025
9 Juni 2025
9 Juni 2025
9 Juni 2025
9 Juni 2025
9 Juni 2025
4 Juni 2025
4 Juni 2025
4 Juni 2025
