VW 198/VW193/VW171 Series

LCD Monitor

User Guide

Q3031 V4

July 2009

No part of this manual, including the products and software described in it, may be reproduced, transmitted,

transcribed, stored in a retrieval system, or translated into any language in any form or by any means,

except documentation kept by the purchaser for backup purposes, without the express written permission

of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND

SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY

OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Table of contents

Notices ......................................................................................................... iii

Safety information ...................................................................................... iv

Care & Cleaning .......................................................................................... v

Chapter 1: Product introduction

1.1 Welcome! .................................................................................... 1-1

1.2 Package contents ......................................................................... 1-1

1.3 Assembling the monitor base ..................................................... 1-2

1.4 Monitor introduction .................................................................... 1-3

1.4.1 Front of the LCD monitor ................................................ 1-3

1.4.2 Rear of the LCD monitor ................................................ 1-4

Chapter 2: Setup

2.1 Adjusting the monitor .................................................................. 2-1

2.2 Detaching the arm/stand (for VESA wall mount)....................... 2-2

Chapter 3: General Instruction

3.1 OSD (On-Screen Display) menu ................................................ 3-1

3.1.1 How to recongure .......................................................... 3-1

3.1.2 OSD Function Introduction .............................................. 3-1

3.2 .............................................................. 3-4Specications summary

3.3 Troubleshooting (FAQ) ................................................................ 3-5

3.4 Supported operating modes ....................................................... 3-6

Produkt Specifikationer

Mærke:	Asus
Kategori:	Skærm
Model:	VW193TR
Produktfarve:	Sort
Pakkevægt:	5800 g
Pakkedybde:	155 mm
Pakkebredde:	513 mm
Pakkehøjde:	425 mm
Skærm diagonal:	19 "
Skærmopløsning:	1440 x 900 pixel
Berøringsskærm:	Ingen
HD-type:	Ikke understøttet
Naturligt aspektforhold:	16:10
Responstid:	5 ms
Synsvinkel, horisontal:	170 °
Synsvinkel, vertikal:	160 °
3D:	Ingen
Indbyggede højttaler(e):	Ja
Antal højttalere:	2
Udgangseffekt (RMS):	1 W
HDCP:	Ja
VESA montering:	Ja
Panel montering grænseflade:	100 x 100 mm
Strømforbrug (typisk):	42 W
Bredde (uden stativ):	- mm
Dybde (uden stativ):	- mm
Højde (uden stativ):	- mm
Vægt (uden stativ):	- g
Bredde (med stativ):	444 mm
Dybde (med stativ):	210 mm
Højde (med stativ):	364 mm
Vægt (med stativ):	4300 g
Hurtig start guide:	Ja
Kabler inkluderet:	AUX, DVI, VGA
Understøttede grafikopløsninger:	1440 x 900 (WXGA+)
Certificering:	TCO03, UL/cUL, CB, CE, FCC, CCC, BSMI, Gost-R, C-Tick, VCCI, PSB, EK, J-MOSS, PSE, ISO13406-2, RoHS, WHQL
Strømforbrug (strømbesparelse):	1 W
Indbygget kamera:	Ingen
Pc lydindgang:	Ja
Slot til kabellås:	Ja
Billedformat:	16:10
Vis antal farver:	16,78 millioner farver
Skærmens lysstyrke (typisk):	300 cd/m²
Kontrastforhold (dynamisk):	50000:1
Pixel pitch:	0.285 x 0.285 mm
Horisontal scanningsområde:	30 - 82 kHz
Antal VGA-porte (D-sub):	1
AC (strøm) indgang:	Ja
Hældningsvinkelområde:	-5 - 20 °
Kabellåseslids type:	Kensington
TV-tuner, integreret:	Ingen
Vertikalt scanningsområde:	56 - 76 Hz
Antal DVI-D-porte:	1
Tynd klient installeret:	Ingen
