AT-LP120-USB Direct-Drive Professional USB and Analog Turntable System

Installation and Operation Pages 2-10

AT-LP120-USB

Platine vinyle USB professionnelle

à entraînement direct

Installation et utilisation Pages 11-20

AT-LP120-USB

Sistema tocadiscos USB profesional

con accionamiento directo

Instalación y funcionamiento Páginas 21-30

AT-LP120-USB

Professioneller Plattenspieler

mit Direktantrieb (USB und Analog)

Installation und Betrieb Seite 31-40

AT-LP120-USB

Giradischi professionale con uscite USB

e analogica a trazione diretta

Installazione e uso Pagine 41-50

AT-LP120-USB

Профессиональные проигрыватели с прямым

приводом (USB и аналоговый)

Руководство по установке и эксплуатации 51-60

Direct-Drive Professional USB and Analog Turntable System

Introduction

Thank you for purchasing the AT-LP120-USB Direct-Drive Professional

USB and Analog Turntable System. Audio-Technica brings its legendary

quality and audio fidelity to the digital realm with this LP-to-digital

recording system. In the box, you’ll find everything you need to transfer

your classic LP collection to digital files: Audio-Technica’s AT-LP120-

USB stereo turntable, complete with USB output that allows direct

connection to your computer; Audacity recording software for MAC

or PC; an integral dual-magnet Audio-Technica phono cartridge; a USB

cable and adapter cables. The turntable also offers a built-in switchable

phono/line preamp that allows connection to a stereo system equipped

with either a phono or line-level input.

The AT-LP120-USB Direct-Drive Professional USB and Analog Turntable

System features the following:

• USB output—no special drivers required for direct connection to

your computer

• Direct drive high-torque motor

• Selectable 33/45/78 RPM speeds

• Selectable internal stereo phono pre-amplifier

• S-shaped tone arm assembly with:

• Adjustable counterweight

• Anti-skate adjustment

• Tone arm height adjustment and lock

• Tone arm lift with hydraulic action and lift lever

• Tone arm rest with locking mechanism

• AT95E Dual Magnet™ phono cartridge with replaceable stylus

• Exclusive AT-HS10 Lightweight Headshell

• Selectable high-accuracy quartz-controlled pitch lock

• Selectable +/–10% or +/– 20% pitch adjustment ranges

• Stroboscopic platter speed indicator

• Forward and reverse play

• Cast aluminum record platter with slip mat

• Start/stop button

• Pop-up stylus target light

• 45-RPM adapter with storage receptacle

• Receptacle for extra headshell

• Adjustable feet for leveling

• Removable hinged dust cover

To assure maximum satisfaction from this product, please read the

information and follow the instructions presented in this manual. Please

keep the manual in an accessible location for future reference. We

suggest that you save all the packaging materials for possible future

storage, moving, or shipping.

Caution: To avoid stylus damage, make certain the included stylus

guard is in place whenever the turntable is being installed, moved,

or cleaned.

Warning: Important information if you intend to play 78 RPM/SP

records on this turntable

The cartridge stylus that is supplied with your LP120 turntable,

Audio-Technica’s AT95E, while ideally matched for both 33 and 45

RPM material, is NOT suitable for playback of 78 RPM/SP material.

Using a cartridge stylus matched for 33 and 45 RPM records will

quickly damage a 78 RPM/SP record.

If you intend to playback 78 RPM/SP material on this turntable, we

recommend that you contact your regional Audio-Technica Customer

Services Dept. (or Authorised Importer’s Customer Service Dept.)

for advice on selecting alternative Audio-Technica cartridges that are

optimised for the playback of 78 RPM/SP records and which can be

easily fitted to this turntable.

Safety instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in accordance

with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding

plug. A polarized plug has two blades with one wider than the other.

A grounding plug has two blades and a third grounding prong. The

wide blade or the third prong is provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly

at plugs, convenience receptacles, and the point where they exit

from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for

long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

15. Where a mains plug is used as the disconnect device, the

disconnect device shall remain readily operable.

16. Please keep the unit in a good ventilation environment.

17. Apparatus shall not be exposed to dripping or splashing and

no objects filled with liquids, such as vases, shall be placed

on apparatus.

Caution: To reduce the risk of fire or electric shock, do not expose

this apparatus to rain or moisture. The apparatus shall not be

exposed to dripping or splashing, and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

Warning: To reduce the risk of fire or electric shock, do not

expose this apparatus to rain or moisture. The apparatus shall not

be exposed to dripping or splashing and that no objects filled with

liquids, such as vases, shall be placed on the apparatus.

Caution: To prevent electric shock, do not use this polarized plug

with an extension cord, receptacle or other outlet unless the blades

can be fully inserted to prevent blade exposure.

The lightning flash with arrowhead symbol within the

equilateral triangle is intended to alert the use to the

presence of uninsulated “dangerous voltage” within

the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock.

The exclamation point within the equilateral triangle is

intended to alert the user to the presence of important

operation and maintenance (servicing) instructions in

the literature accompanying this appliance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Produkt Specifikationer

Mærke:	Audio-Technica
Kategori:	Pladespiller
Model:	AT-LP120-USBHC
Type:	Bæltedrevet pladespiller
Bredde:	450 mm
Dybde:	352 mm
Højde:	157 mm
Produktfarve:	Grey, Platinum, Black
Strømforbrug (typisk):	11 W
Drift:	Vejledning
Nominel hastighed:	33 1/3, 45, 78 rpm
Strømforsyningstype:	Vekselstrøm
Indgangsspænding for vekselstrømsadapter:	115/230 V
Frekvens for vekselstrømsadapter:	50/60 Hz
Kabler inkluderet:	AC, Audio (3.5mm), RCA, USB
Udgangsspænding:	150 mV
Mac kompabilitet:	Ja
USB version:	2.0
Antal USB-porte:	1
Kompatible operativsystemer:	Windows XP/Vista, MAC OSX
Grænseflade:	USB
Plug and play:	Ja
Signal/støjforhold:	50 dB
Wow & flimmer:	0.2 %
Pitch kontrol:	Ja
