AVerVision U50 is a USB powered document camera. It comes with 2 extra USB Hubs wherein you can connect any

external USB device such as keyboard, mouse, USB ash drive and more. An optional power adaptor can be used in

cases where the connected external USB device requires more power.

(4)

(1)

(6)

(7)

(5)

(8)

(2)

(3)

Parts

(1) Mic

(2) Camera sensor and LED

(3) Camera/LED/AF buttons

 Camera - capture a still image.

 LED - turn the overhead LED light on/o

 - Automatically Adjust the Focus. AF

(4) Camera holder

(5) Flex a rm

(6) USB ports panel

(7) Power port p anel

(8) Holder

Folding and Storing

The ex arm design allows you to freely bend the arm and store the camera head in the camera holder. Once you have properly

secured the camera head to the camera holder, you may now carry the AVerVision U from the built-in holder. 50

Adjust the camera head gently and DO NOT forcibly twist the camera head back and forth or around. It may break

the camera head o from the ex arm .

Connecting the AVerVision U50 to a computer

Connecting the External USB Device to AVerVision U50

Connecting a Power Adapter (Optional)

Connect a power adapter to a standard 100V~240V AC power outlet.

The power from the computer USB is sucient enough to power AVerVision U50. However, if your laptop or desktop

USB port does not supply as much power as the USB specication says it should, then you may encounter problems

and need an external power supply.

The symptoms of insucient power are typically the U50 randomly appearing and disappearing from Device Manager,

and accompanying beeps. If a power supply is required, the specication for the power adapter is 5Vdc, 3A.

Power adapter

Wall outlet

General Specication


Sensor

CMOS

Pixel Count

5 megapixels

Frame Rate

30 FPS (max.)

TV Lines

1000 (center)

Output

resolution

2592x1944, 1920x1200,

1920x1080 1280x720 , ,

1280x960, 1024x768

Optics

Focusing

Auto

Shooting Area

Large than A3 (483 x 362 mm -Max)

*at 4:3, shooting area were 483*362 mm

*at 16:9, shooting area were 483*272 mm

*at 1080P, shooting area were 360*203

Zooming

8X Digital Zoom

Power

Power Source

DC 5V (3A), 100-240V, 50-60Hz from host

equipment or adapter (optional)

Consumption

3.4 Watts (LED on); 2.3 Watts (LED o)

Lighting

Lamp Type

LED light

Input/Output

USB mini

Power and signal connectivity to host

equipment

USB Hub (2x)

USB2.0

DC 5V Input

Power Jack

MIC

Built- in

Dimension

Operating

390 248mm x mm x 447.5mm (+/-2mm

include rubber foot)

Folded

259 163mm x mm x 38.79mm (+/-2mm

include rubber foot)

Weight

1.5KG (about 3.306lbs)

For detailed warranty information, please visit our website and select the country where the unit purchased. http://www.averusa.com is

Produkt Specifikationer

Mærke:	AVer
Kategori:	Dokument kamera
Model:	Vision U50
Bredde:	248 mm
Dybde:	390 mm
Højde:	448 mm
Vægt:	1500 g
Antal pr. pakke:	1 stk
Brugervejledning:	Ja
Produktfarve:	Sort
Lampe type:	LED
Strømforsyningstype:	USB
Understøttede grafikopløsninger:	2592 x 1944
Mac kompabilitet:	Ja
Antal lamper:	1 Lampe( r)
Indbygget mikrofon:	Ja
Understøttede Windows-operativsystemer:	Windows 7, Windows 8
Understøttede Mac-operativsystemer:	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Hvidbalance:	Auto, Manual
Fotoeffekter:	Black&White, Negative film
Sensortype:	CMOS
Digital zoom:	8 x
Lyseksponeringstilstande:	Auto, Manual
Grænseflade:	USB 2.0
Autofokus:	Ja
Maksimum billedhastighed:	30 fps
USB-drevet:	Ja
USB-stik type:	Mini-USB
Optisk sensorstørrelse:	1/4 "
Lyskilde:	LED
Dimensioner foldet sammen (BxDxH):	259 x 163 x 39 mm
Horisontal rotationsvinkel:	0 - 270 °
Effektiv sensor opløsning:	5 MP
Frysning af billede:	Ja
Dokument størrelse (maks):	A3
