Side 1/12

GB 1

DEFINITION OF USE

This washing machine is exclusively destined to

wash and spin machine washable laundry in

quantities which are usual for private households.

•Observe the instructions given in these Instructions

for Use, the Installation Guide and the Programme

Chart when using the washing machine.

•Keep these Instructions for Use, the Programme

Chart and the Installation Guide; if you pass on the

washing machine to another person, also give him/

her Instructions for Use, Programme Chart and

Installation Guide.

BEFORE USING THE WASHING MACHINE

1.Removing the packaging and inspection

•After unpacking, make sure that the washing

machine is undamaged. If in doubt, do not use the

washing machine. Contact After-Sales Service or

your local retailer.

•Keep the packaging materials (plastic bags,

polystyrene parts, etc.) out of reach of children,

as they are potentially dangerous.

•If the appliance was exposed to the cold prior to

delivery, keep it at room temperature for a few

hours before operating.

2.Remove the transport bolts

•The washing machine is fitted with transport

bolts to avoid any possible damage to the interior

during transport. Before using the machine, it is

imperative that the transport bolts are removed.

•After their removal, cover the openings with the

4 enclosed plastic caps.

3.Install the washing machine

•Remove the protective film from the control panel

(if available on your model).

•Move the appliance without lifting it by the worktop.

•Install the appliance on a solid and level floor

surface, preferably in a corner of the room.

•Make sure that all four feet are stable and resting

on the floor and then check that the washing

machine is perfectly level (use a spirit level).

•In case of wooden or so-called “floating floors”

(for instance certain parquet or laminate floors),

place the appliance on a 60 x 60 cm sheet of

plywood at least 3 cm in thickness which is

secured to the floor.

•Make sure that the ventilation openings in the

base of your washing machine (if available on

your model) are not obstructed by a carpet or

other material.

4.Water inlet

•Connect the water inlet hose(s) to the drinking

water supply in accordance with the regulations

of your local water company.

•For models with one inlet valve: cold water

•For models with two inlet valves: cold AND hot

water, or cold water only (see separate

Installation Guide).

•Water tap: 3/4” threaded hose

connector

•Water pressure

(flow pressure): 100-1000 kPa (1-10 bar).

•Use only new hoses to connect the washing

machine to the water supply. Used hoses must

not be used and should be discarded.

•For models with hot fill: the hot water inlet

temperature must not exceed 60°C.

5.Drain

•Connect the drain hose to the siphon or hook it

over the edge of a sink by means of the “U” bend

supplied.

•If the washing machine is connected to an

integrated drainage system, ensure the latter is

equipped with a vent to avoid simultaneous

loading and draining of water (siphoning effect).

6.Electrical connection

•Electrical connections must be carried out by a

qualified technician in compliance with the

manufacturer’s instructions and current standard

safety regulations.

•Data regarding voltage, power consumption and

protection requirements is given on the inside of

the door.

•The appliance must be connected to the mains by

means of a socket with an earth connection in

accordance with current regulations. The

washing machine must be earthed by law. The

manufacturer declines all liability for damage to

property or injury to persons or animals due to

non-compliance with the directions given above.

•Do not use extension leads or multiple sockets.

•Before any maintenance on the washing machine

disconnect it from the mains supply.

•After installation, access to the mains plug or to

disconnection from mains supply must be

ensured at all times via a double-pole switch.

•Do not operate the washing machine if it has

been damaged during transport. Inform the

After-Sales Service.

•Mains cable replacement is only to be carried out

by After-Sales Service.

•The appliance must only be used in the

household for the prescribed uses.

Minimum housing dimensions:

Width: 600 mm

Height: 850 mm

Depth: 600 mm

30106370GB.fm Page 1 Thursday, January 20, 2011 4:52 PM

Black process 45.0° 130.0 LPI

GB 2

PRECAUTIONS AND RECOMMENDATIONS

1.Safety instructions

•The washing machine is appropriate for indoor

use only.

•Do not store flammable fluids near the appliance.

•Children must be supervised to ensure that they

do not play with the appliance.

•This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

•Do not operate the washing machine at

temperatures below 5°C.

•If you want to place a dryer on top of your

washing machine, first contact our After-Sales

Service or your specialist dealer to verify if this is

possible. This is only admitted if the dryer is fixed

on the washing machine by using an appropriate

stacking kit available through our After-Sales

Service or your specialist dealer.

•Do not leave the appliance plugged in when not

in use.

•Turn off the tap when not in use.

•Before any cleaning and maintenance switch off

the machine or disconnect it from the mains.

•Never open the door forcibly or use it as a step.

•If necessary, the power cable may be replaced

with an identical one obtained from our After-

Sales Service. The power cable must only be

replaced by a qualified technician.

2.Packaging

•The packaging material is entirely recyclable, and

marked with the recycling symbol . Adhere

to current local regulations when disposing of

packaging material.

3.Disposing of packaging and scrapping

old washing machines

•The washing machine is built from reusable

materials. It must be disposed of in compliance

with current local waste disposal regulations.

•Before scrapping, remove all detergent residues

and cut off the power cable so that the washing

machine is made unusable.

•This appliance is marked according to the

European directive 2002/96/EC on Waste

Electrical and Electronic Equipment (WEEE).

By ensuring this product is disposed of correctly,

you will help prevent potential negative

consequences for the environment and human

health, which could otherwise be caused by

inappropriate waste handling of this product.

The symbol on the product, or on the

documents accompanying the product, indicates

that this appliance may not be treated as

household waste. Instead it shall be handed over

to the applicable collection point for the recycling

of electrical and electronic equipment.

Disposal must be carried out in accordance with local

environmental regulations for waste disposal.

For more detailed information about treatment,

recovery and recycling of this product, please contact

your local city office, your household waste disposal

service or the shop where you purchased the product.

4.Frost

Do not place the washing machine in a room prone

to frost. If you must, make sure that the washing

machine is completely drained after each wash:

•Remove inlet hose(s) from water tap and let the

water flow out completely.

•Remove drain hose from siphon or handwash

basin and let the water flow out completely.

•Empty residual water inside the machine by

following the instructions in the chapter

“Draining Residual Water”; tilt the appliance

forward with two persons to let the rest water

flow out completely.

5.Saving tips

The water consumption of your washing machine is

optimized; in some programmes you therefore

cannot see the water through the door glass when

the machine is in operation.

•Achieve the best use of energy, water, detergent

and time by using the recommended maximum

load size.

•Do not exceed the detergent dosages indicated

in the manufacturer’s instructions.

•The Eco-Ball - a special system in the outlet - will

prevent detergent loss from the drum to avoid

detergent loss into the environment.

•Use “Prewash” (if available on your model) for

heavily soiled laundry only! Save detergent, time,

water and energy consumption by not selecting

“Prewash” for slightly to normally soiled laundry.

•Pretreat stains with stain remover or soak dried-

in stains in water before washing to reduce the

necessity of a hot wash programme.

•Save energy by using a 60° C instead of a 95° C

wash programme or a 40° C instead of a 60° C

wash programme.

•Save energy and time by selecting a high spin

speed to reduce the water content in laundry

before using a tumble dryer.

6.EC Declaration of Conformity

•The appliance conforms to the following

European Standards:

2006/95/EC Low Voltage Directive

2004/108/EC Electromagnetic Compatibility

Directive

The Manufacturer is not liable for any damage to

laundry resulting from inadequate or incorrect

fabric care instructions which have been provided

with the garment or article.

30106370GB.fm Page 2 Thursday, January 20, 2011 4:52 PM

Black process 45.0° 130.0 LPI

Produkt Specifikationer

Mærke:	Bauknecht
Kategori:	Vaskemaskine
Model:	WAK Eco 4590
Bredde:	595 mm
Dybde:	600 mm
Højde:	850 mm
Vægt:	80000 g
Produktfarve:	Black, White
Indbygget skærm:	Ja
Strøm:	10 A
Pakkevægt:	81000 g
Pakkedybde:	640 mm
Pakkebredde:	640 mm
Pakkehøjde:	900 mm
Energieffektivitetsklasse (gammel):	A+++
Strømforbrug (typisk):	2300 W
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	9 kg
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	14
Støjniveau (centrifugering):	76 dB
Støjniveau (vask):	52 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Hygiene/anti-allergy, Black
Energiforbrug ved vask:	0.74 kWh
Årligt energiforbrug vask:	173 kWh
Tromle volumen:	64 L
Dør farve:	Sort
Spin-tørre klasse:	A
Cyklustid (maks.):	240 min.
Vaskeklasse:	A
Årligt vandforbrug vask:	10400 L
Vandforbrug pr. cyklus:	- L
Forsinket start (maks.):	23 t
Cyklustid (hurtigt vaskeprogram):	15 min.
