Side 1/82
Fig. 1 - A
FSM 1660
1
2
4
5
4
6
7
8
3
4
Instruction ManualGB
1
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been removed.
• Leave to stand for at least 4 hours before switching
on, to allow compressor oil to settle, if transported
horizontally.
• If you are discarding an old appliance with a lock or
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose i.e. the storing and freezing of edible foodstuff.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the insulation
which are flammable. We suggest you contact your local
authority for information on disposal and available
facilities.
• We do not recommend use of this appliance in an
unheated, cold room. (e.g. garage, conservatory, annex,
shed, out-house etc.)
To obtain the best possible performance and trouble free
operation from your appliance it is very important to
read these instructions carefully. Failure to observe these
instructions may invalidate your right to free service
during the guarantee period.
Please keep these instructions in a safe place for easy
reference.
Congratulations on your choice of a Quality
Appliance, designed to give you many years of service.
Technical Features (Table 1)
Specification
Width (cm)
Depth (cm)
Height (cm)
Total Gross Volume (lt. / cu.ft.)
Total Net Volume (lt. / cu.ft.)
Conservation Time From Failure (hours)
Climate Class / Star Rating
Energy Efficiency Class
Voltage
System Cooling Gas
595
600
1535
240 / 8,5
190/6,7
20
SN/T
595
600
1730
260 / 9,2
223/7,87
22
SN-ST
A+
230 V AC, 50 Hz.
R600a
FSM 1660 FSM 1670
Instruction ManualGB
2
Electrical requirements
Before inserting the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating plate inside the appliance
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a
suitably switched and fused socket in a readily
accessible position.
Warning! This appliance must be
earthed.
Repairs to electrical equipment should only be
performed by a qualified technician. Incorrect
repairs carried out by an unqualified person
carry risks that may have critical consequences
for the user of the appliance.
• Do not dispose of the appliance on a fire. At
, the care and protection of our
environment is an ongoing commitment. This
appliance which is among the latest range
introduced is particularly environment friendly.
Your appliance contains non CFC/HFC natural
substances in the cooling system (called R600a)
and the insulation (called cyclopentane) which
are potentially flammable if exposed to fire.
Therefore, take care not to damage, the cooling
circuit/ pipes of the appliance in transportation
and in use. In case of a damage do not expose
the appliance to fire, potential ignition source
and immediately ventilate the room where the
appliance is situated.
• We suggest you contact your local authority
for disposal information and facilities available.
WARNING- Keep ventilation openings, in the
appliance enclosure or in the built-in structure,
clear of obstruction.
WARNING- Do not use mechanical devices
or other means to accelerate the defrosting
process, other than those recommended by the
manufacturer.
WARNING- Do not damage the refrigerant
circuit.
WARNING- Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
Transportation
instructions
1. The appliance should be transported only
in upright position. The packing as supplied
must be intact during transportation.
2. If during the course of transport the appliance,
has been positioned horizontally, it must not
be operated for at least 4 hours, to allow the
system to settle.
3. Failure to comply with the above instructions
could result in damage to the appliance, for
which the manufacturer will not be liable for.
4. The appliance must be protected against
rain, moisture and other atmospheric influences.
Important!
• Care must be taken while cleaning/carrying
the appliance not to touch the bottom of the
condenser metal wires at the back of the
appliance, as this could cause injury to fingers
and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use.
You could injure yourself or damage the
appliance.
• Make sure that the mains cable is not caught
under the appliance during and after moving,
as this could damage the cable.
• Do not allow children to play with the
appliance or tamper with the controls.
Installation instructions
1. Do not place the appliance near cookers
or radiators or in direct sunlight, as this will
cause extra strain on the appliance's functions.
If installed next to a source of heat or freezer,
maintain the following minimum side clearances:
From Cookers 30 mm
From Radiators 300 mm
From Freezers 25 mm
2. Make sure that sufficient room is provided
Instruction ManualGB
6
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outlet and pull out the
mains plug before cleaning.
2. Never use any sharp instruments or abrasive
substances, soap, household cleaner, detergent
or wax polish for cleaning.
3. Use lukewarm water to clean the cabinet of
the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution
of one teaspoon of bicarbonate of soda to one
pint of water to clean the interior and wipe it
dry.
5. Make sure that no water enters the
temperature control box.
6. If the appliance is not going to be used for
a long period of time, switch it off, remove all
food, clean it and leave the door ajar.
7. We recommend that you polish the metal
parts of the product (i.e. door exterior, cabinet
sides) with a silicone wax (car polish) to protect
the high quality paint finish.
8. Any dust that gathers on the condenser,
which is located at the back of the appliance,
should be removed once a year with a vacuum
cleaner.
9. Check door seals regularly to ensure they
are clean and free from food particles.
10. Never:
• Clean the appliance with unsuitable material;
e.g. petroleum based products.
• Subject it to high temperatures in any way,
• Scour, rub etc., with abrasive material.
11. Excess deposit of ice should be removed
regularly with the plastic scraper provided.
Large accumulation of ice will impair the
performance of the freezer.
12. To remove a drawer, pull it as far as
possible, tilt it upwards and then pull it out
completely.
Defrosting
(Fig. 4, 5, 6)
Defrosting is very straightforward and without
mess thanks to a special defrost water collection
facility at the bottom of the freezer.
Defrost twice a year or when a frost layer of
around 7 mm (1/4") has formed. To start the
defrosting procedure, pull out the mains plug.
All food should be wrapped in several layers
of newspaper and stored in a cool place (e.g.
fridge or larder).
Remove all freezer drawers. The special defrost
collection basin collects the defrost water.
Containers of warm water may be placed
carefully in the freezer to speed up the
defrosting.
Do not use pointed or sharp-edged
objects such as knives or
forks to remove the frost.
Never use hair dryers, electrical heaters
or other such electrical
appliances for defrosting.
When defrosting has finished, put the
accessories and food into the appliance, press
the fast freeze switch and leave it on at least
24 hrs.
Produkt Specifikationer
| Mærke: | Blomberg |
| Kategori: | Køleskab |
| Model: | FSM 1670 |
