Intrusion Alarm Systems | B208 Octo-input Module

B208 Octo-input Module

www.boschsecurity.com

uProgrammable input point functions

uEasy to read switch addressing

u2 interconnect wiring connectors

uProvides eight points

The B208 Octo-input Module is an 8 point expansion

device that connects to the control panel through the

SDI2 bus. This module is fully supervised and

communicates back to the control panel all point

status changes. The module expansion points operate

the same as the points on the control panel.

Industrial, commercial, and institutional facilities are

typical installations for the B208 module. The B208

connects to the SDI2 bus on the control panel using

SDI2 terminals, or using the interconnect cable. You

can connect multiple B208 modules to a single control

panel. The B208 address switches allow for ease of

use in device addressing.

System overview

The B208 Octo-input Module connects to a control

panel through the SDI2 bus. This module is supervised

and communicates back to the control panel all point

status changes. The module’s expansion points

operate the same as the points on the control panel.

Functions

Loop inputs

The B208 uses up to eight inputs which may be

Normally Open (NO), or Normally Closed (NC) with 1k

Ω EOL resistor(s) for supervision.

Certifications and approvals

The following table lists regulatory approvals by

region.

Region

US UL 365 - Police Station Connected Burglar Alarm Units

and Systems

UL 609 - Local Burglar Alarm Units and Systems

UL 636 - Holdup Alarm Units and Systems

UL 864 - Control Units and Accessories for Fire Alarm

Systems (Commercial Fire)

UL 985 - Household Fire Warning System Units

UL 1023 - Household Burglar Alarm System Units

UL 1076 - Proprietary Burglar Alarm Units and Systems

UL 1610 - Central Station Burglar Alarm Units

CSFM - California Office of The State Fire Marshall

FCC Part 15 Class B

FDNY - Fire Department of New York

FM 3010 - Fire Alarm Signaling Systems

Canada CAN/ULC S303 - Local Burglar Alarm Units and Systems

CAN/ULC S304 - Signal Receiving Centre and Premise

ICES-003 - Information Technology Equipment (ITE)

ULC-ORD C1023 - Household Burglar Alarm System Units

ULC-ORD C1076 - Proprietary Burglar Alarm Units and

System

The following table lists the certificates available for

download from the Product Page at

www.boschsecurity.com.

Region Certification

USA UL 20130109-S5579; UL 864 - Control

Units and Accessories for Fire Alarm

Systems; UL 636 - Holdup Alarm Units

and Systems; UL 1076 - Propietary Bur-

glar Alarm Units and Systems; UL 1610 -

Central Station Burglar Alarm Units; UL

365 - Police Station Connected Burglar

Alarm Units and Systems; UL 609 - Local

Burglar Alarm Units and Systems;

UL985 - Residential Fire Warning Sys-

tem Control Units; UL 1023 - Household

Burglar-Alarm System Units; ULC/ORD

C1076 - Proprietary Burglar Alarm Units

and Systems; ULC-S304-06 - Signal Re-

ceiving Centre and Premise Burglar

Alarm Control Units; ULC-S303-M91 -

Local Burglar alarm Units and Systems;

ULC-ORD C1023 - Household Burglar-

Alarm System Units

CSFM see our website

FDNY-

CoA

#6174 UL 864 9th Edition

Installation/configuration notes

Wiring considerations

The module to the control panel using the PWR, A, B,

COM terminals on the control panel using the screw

terminal strip or the interconnect wiring connector.

Use 12 AWG to 22 AWG (1.5 mm to 0.6 mm) wires

from the module to the control panel.

Parts included

Quantity

QuantityQuantity Component

Component

ComponentComponent

1 Octo-input module

1 Hardware pack

1 interconnect cable

1 Literature pack

Technical specifications

Properties

Dimensions 2.5 in x 3.8 in x 0.60 in

(6.37 cm x 9.6 cm x 1.5 cm)

Environmental considerations

Relative humidity 5% to 93% at +32°C (+90°F)

Temperature (operating) 0°C to +49°C (+32°F to +120°F)

Power requirements

Current 35 mA

Voltage 12 VDC nominal

Wiring

SDI2 wiring Maximum distance – Wire size

(unshielded wire only): 12 in (30.48

cm)

Wiring Maximum distance – Wire size

(unshielded wire only): 1000 ft (305

m) – 22 AWG (0.65 mm)

1000 ft (305 m) – 18 AWG (2 mm)

Unshielded wire only

Loop inputs

Loop Inputs Up to eight inputs. Input contacts may

be Normally Open (NO) or Normally

Closed (NC) with 1kΩ EOL resistor(s)

for supervision. Note: Normally Closed

(NC) is not permitted in Fire

installations.

Compatibility

For UL 864 compliance, use a UL commercial fire

approved control panel.

Control panels B9512G/B9512G-E (Up to 59

modules)

B8512G/B8512G-E (Up to 9 modules)

B5512/B5512E (Up to 4 modules)

B4512/B4512E (Up to 2 modules)

D9412GV4 (Up to 24 modules)

D7412GV4 (Up to 7 modules)

D7212GV4 (Up to 3 modules)

Ordering information

B208 Octo-input Module

Provides 8 programmable inputs.

Order number B208

2 | B208 Octo-input Module

Produkt Specifikationer

Mærke:	Bosch
Kategori:	Ikke kategoriseret
Model:	B208
Bredde:	73.5 mm
Dybde:	127 mm
Højde:	15.25 mm
Vægt:	300 g
Forbindelsesteknologi:	Ledningsført
Strømkilde type:	DC
Husets farve:	Sort
