Intrusion Alarm Systems | B299 Expansion module, SDI2

B299 Expansion module, SDI2

www.boschsecurity.com

uProvides point identification for up to 100

connected addressable initiating devices using

POPITs

uSupervises wiring to devices for circuit integrity

uExpands the number of points in the system

uCompact size

uInterconnect wiring connectors for easy installation

The B299 POPEX Module is an SDI2 compatible

device. The module communicates to the control panel

over the SDI2 bus, and provides support for up to 100

POPIT (Point Of Protection Input Transponder)

devices. This occurs over a single expansion loop using

two pairs of terminals.

System overview

Each module installs in the control panel enclosure or

in an adjacent approved enclosure. Future system

expansion is very economical as the module supports

zone expansion through supporting D9127U/T POPIT

modules and POPIT’ed detectors. The POPIT modules

can be placed anywhere along the two-wire data

expansion loop from the module.

Certifications and approvals

Region Regulatory compliance/quality marks

USA ANSI-

SIA

CP-01-2010-Control Panel Standard -

Features for False Alarm Reduction

UL Underwriters Laboratories

UL UL 1023 - Household Burglar Alarm Sys-

tem Units

UL UL 1076 - Proprietary Burglar Alarm

Units and Systems

Region Regulatory compliance/quality marks

UL UL 1610 - Central Station Burglar Alarm

Units

UL UL 1635 - Standard for Digital Alarm

Communicator System Units

UL UL 294 - Standard for Access Control

Units and Systems

UL UL 365 - Police Station Connected Bur-

glar Alarm Units

UL UL 609 - Standard for Local Burglar

Alarm Units and Systems

UL UL 636 - Holdup Alarm Units and Sys-

tems

UL UL 864 - Standard for Control Units and

Accessories for Fire Alarm Systems

(10th edition)

UL UL 985 - Household Fire Warning Sys-

tem Units (6th edition)

FM Central Station

FM Local Protective Signaling

FM Remote Station

CSFM California Office of The State Fire Mar-

shall

FCC Part 15 Class B

Region Regulatory compliance/quality marks

Canada ULC Underwriters Laboratories of Canada

ULC CAN/ULC S303 - Local Burglar Alarm

Units and Systems

ULC CAN/ULC S304 - Standard for Signal Re-

ceiving Center and Premise Burglar

Alarm

ULC CAN/ULC S545 - Residential Fire Warn-

ing System Control Units

ULC ULC-ORD C1023 - Household Burglar

Alarm System Units

ULC ULC-ORD C1076 - Proprietary Burglar

Alarm Units and Systems

IC ICES-003 - Information Technology

Equipment (ITE)

Installation/configuration notes

Mounting

Mount the module into the enclosure’s 3-hole

mounting pattern using the mounting screws and

mounting bracket.

Wiring

Use the control panel SDI2 terminals labeled R, Y, G, B

(PWR, A, B, COM) when wiring to the module.

Connect the control panel terminals to the module

terminals labeled R, Y, G, B (PWR, A, B, COM). You can

also use the SDI2 interconnect cable.

Compatibility

POPIT devices D9127U/T POPIT module

ZX776Z/ZX794Z PIR motion detector

ZX835 TriTech motion detector

ZX935Z/ZX938Z PIR motion detector

ZX970 TriTech motion detector

D278S 12V smoke base

D298S 24V smoke base

F220-B6PM POPIT smoke (master)

F220-B6PS POPIT smoke base

Parts included

Quan

tity

Component

1 Module

1 Hardware pack

Quan

tity

Component

1 Interconnect cable

1 Installation manual

Technical specifications

Properties

Dimensions 2.9 in x 5.0 in x 0.6 in

(73.5 mm x 127 mm x 15.25 mm)

Weight 11.2 oz (0.30 kg)

Environmental considerations

Relative humidity 5% to 93% at +32°C (+90°F)

Temperature (operating) 0°C to +49°C (+32°F to +120°F)

Power requirements

Current Standby: 35 mA + total device current

Alarm: 35 mA + total device current

Voltage (input) 12 VDC

Wiring

Terminal wire size 12 AWG to 22 AWG (2.0 mm to 0.65

mm)

SDI2 wiring Maximum distance – Wire size

(unshielded wire only): 200 ft (60 m) -

22 AWG (0.65 mm), 500 ft (152 m) -

18 AWG (1.02 mm)

POPIT loop wiring Maximum wire length: 1800 ft (548 m)

- 22 AWG (0.65 mm), 4600 ft (1402

m) - 18 AWG (1.02 mm)

Ordering information

B299 Expansion module, SDI2

Provides system expansion support for up to 100

POPIT devices

Order number B299

2 | B299 Expansion module, SDI2

Represented by:

Europe, Middle East, Africa: Germany: North America: Asia-Pacific:

Bosch Security Systems B.V.

P.O. Box 80002

5600 JB Eindhoven, The Netherlands

Phone: + 31 40 2577 284

emea.securitysystems@bosch.com

emea.boschsecurity.com

Bosch Sicherheitssysteme GmbH

Robert-Bosch-Ring 5

85630 Grasbrunn

Germany

www.boschsecurity.com

Bosch Security Systems, Inc.

130 Perinton Parkway

Fairport, New York, 14450, USA

Phone: +1 800 289 0096

Fax: +1 585 223 9180

onlinehelp@us.bosch.com

www.boschsecurity.us

Robert Bosch (SEA) Pte Ltd, Security Systems

11 Bishan Street 21

Singapore 573943

Phone: +65 6571 2808

Fax: +65 6571 2699

apr.securitysystems@bosch.com

www.boschsecurity.asia

16544648587 | en, V10, 25. Jun 2020
