Side 1/3

Intrusion Alarm Systems | B442 Conettix Plug-in GPRS Cellular Communicator

B442 Conettix Plug-in GPRS Cellular

Communicator

www.boschsecurity.com

uSecure Conettix IP alarm communication for Latin

America

uRemote programming and monitoring of compatible

Bosch control panels

uPersonal SMS message and e-mail notification

options

uConfigured directly from Bosch Remote

Programming Software eliminating the need for

separate configuration

The B442 provides IP communication over a GSM

(GPRS) cellular network by plugging into a B Series

control panel or B450 Conettix Plug-in Communicator

Interface. Typical applications are:

• Alarm reporting to a central station

• Remote control panel programming through Remote

Programming Software

• Remote monitoring and control through a mobile

application

• Personal notification using SMS

The B442 is built for a wide variety of secure

commercial and industrial applications. Flexible end-

to-end path supervision, 128-bit to 256-bit AES

encryption, and anti-substitution features make B442

desirable for high security and fire monitoring

applications.

Notice

Cellular capability requires an appropriate SIM

card and data plan.

System overview

Callout

Callout Callout Callout

Callout

Callout Callout

ᅳ

ᅳᅳ Description

Description

Description Description ᅳ

ᅳ

ᅳᅳ Description

Description

Description Description

1 B442 Conettix Plug-in GPRSᅳ

Cellular Communicator

7 Remote PC’s networkᅳ

connection

2 Compatible control panel 8 Remote PC running RPSᅳ ᅳ

3 Antenna cable 9 Personal SMS notificationᅳ ᅳ

4 Magnetic base antenna 10 Ethernet connectionᅳ ᅳ

5 Base station on wirelessᅳ

carrier’s network

11 Central montoring stationᅳ

6 IP network cloud ᅳ

Functions

Conettix IP communication via Cellular

In addition to the security provided by the network

operator, the B442 uses our Conettix IP protocol that

supports:

• Flexible polling intervals

• Resistance to Denial of Service attacks

• Anti-replay/anti-substitution keys

Easy Installation, troubleshooting, and maintenance

• No networking expertise required at field site (no

firewall or router settings)

• No computer or special tools required for installation

and troubleshooting

• Manage service plans and settings through RPS

(Bosch Cellular service only)

• Diagnostic LEDs for on-site troubleshooting

LED Function

Blue (STATUS) System status Indicator

Red Unacceptable signal strength

Yellow Marginal signal strength

1 Green Good signal strength

2 Green Very good signal strength

Remote programming of Bosch control panels

The B442 supports secure, remote programming of

compatible Bosch control panels.

Personal notification and control

The B442 supports the Bosch Remote Security Control

mobile application and can be configured for SMS

personal notification reports to mobile phones.

Certifications and approvals

Region

RegionRegion Agency

Agency

AgencyAgency Certification

Certification

CertificationCertification

US FCC FCC, Part 15 Class B Radiated/Conducted

Emissions

UL UL 365 - Police Station Connected Burglar

Alarm Units and Systems

UL 636 - Holdup Alarm Units and Systems

UL 864 – Control Units and Accessories for

Fire Alarm Systems

UL 985 - Household Fire Warning System

Units

UL 1023 - Household Burglar-Alarm System

Units

UL 1076 - Proprietary Burglar Alarm Units

and Systems

UL 1610 – Central Station Burglar Alarm

Units

Canada ULC ULC C1023 - Household Burglar-Alarm

System Units

ULC C1076 - Proprietary Burglar Alarm

Units and Systems

ULC S303 – Local Burglar Alarm Units and

Systems

ULC S304 – Central and Monitoring Station

Burglar Alarm Units

ULC S545 – Residential Fire Warning

System Control Units

IC ICES-003

Europe CE Certified

Region Certification

Europe CE 2014/30/EU EMC Directive (EMC);

2014/35/EU Low-Voltage Directive

(LVD); 1999/5/EC Radio equipment and

Telecommunications Terminal Equip-

ment (R&TTE); 2011/65/EU Restriction

of the use of certain hazardous substan-

ces in electrical and electronic equip-

ment(RoHS)

Brazil ANATEL 1338-14-1855

Installation/configuration notes

Mounting considerations

The cellular communicator plugs directly into any B

Series control panel via the on-board plug-in

connection, or other compatible control panels via a

B450 Conettix Plug-in Communicator Interface.

Wiring considerations

The cellular communicator connects to the B Series

control panel without tools or physical wiring for

power.

When used with the B450 Conettix Plug-in

Communicator Interface, the B450 is wired to the

SDI2, SDI, or option bus control panel.

The antenna is attached to the module via the

threaded SMA connector.

Cellular Service Considerations

The B442 requires an active cellular service on a GSM

supported cellular network.

Parts included

Quantity

QuantityQuantity Component

Component

ComponentComponent

1 B442 Conettix Plug-in GPRS

Cellular Communicator

1 Antenna

1 Literature pack

Technical specifications

Electrical

ElectricalElectrical

2 | B442 Conettix Plug-in GPRS Cellular Communicator

Produkt Specifikationer

Mærke:	Bosch
Kategori:	Ikke kategoriseret
Model:	B442
Bredde:	50 mm
Dybde:	93.5 mm
Højde:	15.25 mm
Produktfarve:	Sort
Datanetværk:	3G, 4G
Relativ luftfugtighed ved drift (H-H):	5 - 93 %
Driftstemperatur (T-T):	-10 - 55 °C
Strømkilde type:	DC
Enhedstype:	Cellulær netværksdeler
Understøttelse af 3G-bånd:	850,900,1800,1900 Mhz
Understøttelse af 4G-bånd:	850,900,1800,1900 Mhz
Antal SIM kort:	1
