Side 1/4

Intrusion Alarm Systems | B443 Plug-in Cellular, HSPA+ (3G+)

B443 Plug-in Cellular, HSPA+ (3G+)

www.boschsecurity.com

uRemote programming and monitoring of compatible

Bosch control panels

uConfigured directly from Bosch Remote

Programming Software eliminating the need for

separate configuration

The B443 provides 3G/4G IP communication over a

GPRS/EDGE/UMTS/HSPA+ cellular network by

plugging into any compatible Bosch control panel or

B450 Conettix Plug-in Communicator Interface. Typical

applications are:

• Alarm reporting to a central station

• Remote control panel programming through Remote

Programming Software with supported control panels

• Remote monitoring and control through a mobile

application with supported control panels

• Personal notification using SMS for compatible

control panels

The B443 is built for a wide variety of secure

commercial and industrial applications. Flexible end-

to-end path supervision, 128-bit to 256-bit AES

encryption, and anti-substitution features make B443

desirable for high security and fire monitoring

applications.

Notice

Cellular capability requires an Installer Services

account and appropriate data plan.

System overview

Callout

Callout Callout ᅳ

ᅳ

ᅳᅳ Description

Description

Description Description Callout

Callout

Callout Callout ᅳ

ᅳ

ᅳᅳ Description

Description

Description Description

1 B443 7 Remote PC’s networkᅳ ᅳ

connection

2 Compatible control panel 8 Remote PC running Remoteᅳ ᅳ

Programming Software

3 Antenna cable 9 Personal SMS notificationᅳ ᅳ

4 Magnetic base antenna 10 Ethernet connectionᅳ ᅳ

5 Base station on wirelessᅳ

carrier’s network

11 Central monitoring stationᅳ

6 IP network cloud ᅳ

Functions

IP communication via Cellular

The B443 uses Conettix IP protocol, SIA DC-09 UDP,

and CVS-IP on supported control panels that supports:

• Flexible polling intervals

• Resistance to Denial of Service attacks

• Anti-replay/anti-substitution keys using Conettix

Easy installation, troubleshooting, and

maintenance

• No networking expertise required at field site (no

firewall or router settings)

• No computer or special tools required for installation

and troubleshooting

• Diagnostic LEDs for on-site troubleshooting

LED Function

Blue (STATUS) System status Indicator

Red Unacceptable signal strength

Yellow Marginal signal strength

1 Green Good signal strength

2 Green Very good signal strength

Remote programming of Bosch control panels

The B443 supports secure remote programming of

compatible Bosch control panels.

Personal notification and control

On supported control panels, the B443 supports the

Bosch Remote Security Control mobile application and

can be configured for SMS personal notification

reports to mobile phones.

Certifications and approvals

Region Regulatory compliance/quality marks

Europe CE EMC, LVD, R&TTE, RoHS B443

EN5013

EN-ST-000245 EN-

ST-000245_B450_B450-

M_442_443_2021_04_25

USA UL UL 365 - Police Station Connected Bur-

glar Alarm Units

UL UL 636 - Holdup Alarm Units and Sys-

tems

UL UL 864 - Standard for Control Units and

Accessories for Fire Alarm Systems

UL UL 985 - Household Fire Warning Sys-

tem Units

UL UL 1023 - Household Burglar Alarm Sys-

tem Units

UL UL 1076 - Proprietary Burglar Alarm

Units and Systems

UL UL 1610 - Central Station Burglar Alarm

Units

CSFM see www.boschsecurity.com (the Bosch

website)

Region Regulatory compliance/quality marks

FCC Part 15 Class B

FDNY-

CoA

6307 B465_NYC_CoA_6307

FDNY-

CoA

6173

FDNY-

CoA

6286 D7412GV4 D9412GV4 NYC COA

6286 2018-2021

FDNY-

CoA

6196

Canada ULC CAN/ULC S303 - Local Burglar Alarm

Units and Systems

ULC CAN/ULC S304 - Standard for Signal Re-

ceiving Center and Premise Burglar

Alarm

ULC CAN/ULC S545 - Residential Fire Warn-

ing System Control Units

ULC CAN/ULC S559 - Fire Signal Receiving

Centres and Systems

ULC ULC-ORD C1023 - Household Burglar

Alarm System Units

ULC ULC-ORD C1076 - Proprietary Burglar

Alarm Units and Systems

ULC S1871-20121210

IC ICES-003 - Information Technology

Equipment (ITE)

Singapore iDA

Installation/configuration notes

Mounting considerations

Mounting considerationsMounting considerations

The module plugs into any compatible control panel,

available in a variety of enclosures.

Wiring considerations

Wiring considerationsWiring considerations

The module connects to any compatible control panel

without tools or physical wiring for power. When used

with the B450, the B450 is wired to the control panel

data bus. The cellular module has a screw on SMA

antenna connection.

Cellular service considerations

Cellular service considerationsCellular service considerations

The module is shipped pre-activated for Bosch Cellular

service on the Verizon cellular network. A valid service

contract is required prior to ordering.

GPRS/EDGE/UMTS/HSPA+ required.

Compatibilities

CompatibilitiesCompatibilities

2 | B443 Plug-in Cellular, HSPA+ (3G+)

Produkt Specifikationer

Mærke:	Bosch
Kategori:	Ikke kategoriseret
Model:	B443
Bredde:	50 mm
Dybde:	93.5 mm
Højde:	15.25 mm
Produktfarve:	Sort
Datanetværk:	3G,4G
Relativ luftfugtighed ved drift (H-H):	5 - 93 %
Driftstemperatur (T-T):	-10 - 55 °C
Strømkilde type:	DC
Enhedstype:	Cellulær netværksdeler
Antal SIM kort:	1
