Intrusion Alarm Systems | B942 Touch Screen Keypad

B942 Touch Screen Keypad

www.boschsecurity.com

uColor graphic touch screen display uses a

combination of simple icons and text for easy

operation

uBuilt-in presence detector lights the display when

user approaches keypad

uBuilt-in proximity reader allows use of a token or

card as replacement for a passcode, or for use with

dual authentication for high security areas

uFour inputs and one output provide cost effective

expansion

uSlim, modern design blends with any decor

The keypad is an SDI2 bus compatible device. The

keypad features an illuminated touch screen and

graphical interface. With an elegant design and low

profile, the keypad fits with any modern decor. Each

keypad has user adjustable options such as volume

and brightness. They have four inputs and one output.

The keypad shows system messages for all areas.

Keypad languages

The following languages are available:

• English

• Chinese

• Dutch

• French

• German

• Greek

• Italian

• Hungarian

• Polish

• Portuguese

• Spanish

• Swedish

System overview

• For commercial use, install the keypad in building

entrances and areas with unrestricted access.

Mounting a keypad near exterior doors in hotel or

business lobbies allows people to identify the type

and location of the emergency.

• For residential use, install the keypad near the front

and rear entrances to the home. Install additional

keypads in a kitchen or in a bedroom.

• Use multiple keypads in a large building with many

separate areas of security. Program multiple keypads

to control multiple areas.

• Audible tones from the keypad sounder alert

personnel to fire events and assist fire fighters in

locating the keypad.

Functions

Display

The touch screen display uses icons, words, numbers,

and symbols to show the status of the security system

and for interacting with the security system. When

several events occur, the keypad shows each event in

order of priority. The keypad detects when a user

approaches and automatically activates the display.

User icons and keys

The keypad greets the user with a home screen that

shows the system status at one glance using a large

icon. The user can change the system status by simply

touching this home screen icon. The touch screen

display also offers icons on the ribbon bar. These

visually pleasing graphical icons are easy to use for

accessing menus and other options. The keypad has a

variety of keyboards for entering alphanumeric

characters. The keypad screen has numeric keys and

one function [CMD] key. When pressed, keys emit a

muted beep. Use the keyboards for entering

passcodes, activating commands, and entering

alphanumeric characters.

Audible tones

The keypad has a built-in speaker that produces

several distinct warning tones. The tones are

differentiated so that the user can recognize an event

simply by hearing its associated tone. The keypad

backlight illuminates when it emits an audible tone.

Users can use a passcode or credential to silence the

tone.

Status indicators

The status indicators on the keypad provide a quick

visual reference for system status.

The indicator lights when the system is ready to turn on (arm).

The indicator lights when the system is on (armed).

The indicator lights when there is a trouble condition.

The indicator lights when dangerous gases are present including

carbon monoxide (NFPA 720).

The indicator lights when the system has power.

Proximity reader

The proximity reader allows users to use a token or

card in place of a passcode to turn on or off the

security system. The proximity reader supports

EM4102 (125 kHz) credentials. The Bosch ACA-ATR13-

RFID tag and Bosch ACD-ATR11ISO-RFID card are

examples.

Certifications and approvals

Region Regulatory compliance/quality marks

Australia RCM ACMA

Europe CE RED, EMC, LVD, RoHS [B942 B942W]

USA UL UL 365 - Police Station Connected Bur-

glar Alarm Units

UL UL 609 - Standard for Local Burglar

Alarm Units and Systems

UL UL 636 - Holdup Alarm Units and Sys-

tems

UL UL 1023 - Household Burglar Alarm Sys-

tem Units

Region Regulatory compliance/quality marks

UL UL 1076 - Proprietary Burglar Alarm

Units and Systems

UL UL 1610 - Central Station Burglar Alarm

Units

UL UL 985 - Household Fire Warning Sys-

tem Units (6th edition)

CSFM California State Fire Marshal

FCC Part 15 Class B

Canada ULC CAN/ULC S303 - Local Burglar Alarm

Units and Systems

ULC CAN/ULC S304 - Standard for Signal Re-

ceiving Center and Premise Burglar

Alarm

ULC CAN/ULC S545 - Residential Fire Warn-

ing System Control Units

ULC ULC-ORD C1023 - Household Burglar

Alarm System Units

ULC ULC-ORD C1076 - Proprietary Burglar

Alarm Units and Systems

ULC Underwriters Laboratories of Canada

S1871-20121210

IC ICES-003 - Information Technology

Equipment (ITE)

Installation/configuration notes

Power supply

A compatible control panel supplies the power and

data requirements to the keypad through a four-wire

connection.

Mounting and wiring

Mount in dry indoor locations.

Includes a slim mounting plate for recessing wiring,

and a surface mounting plate for surface mounting and

wiring.

Compatible control panels

B9512G/B9512G-E

B8512G/B8512G-E

B6512

B5512/B5512E firmware v2.03 and higher

B4512/B4512E firmware v2.03 and higher

B3512/B3512E firmware v2.03 and higher

D9412GV4/D7412GV4 v2.03 and higher

Technical specifications

Properties

Dimensions 158 mm x 120 mm x 16.5 mm (6.2 in x

4.7 in x 0.65 in)

Weight 0.32 kg (11.3 oz)

Material Acrylonitrile butadiene styrene (ABS)

Poly(methyl methacrylate) (PMMA)

2 | B942 Touch Screen Keypad

Produkt Specifikationer

Mærke:	Bosch
Kategori:	Ikke kategoriseret
Model:	B942W
Bredde:	158 mm
Dybde:	120 mm
Højde:	16.5 mm
Vægt:	320 g
Produktfarve:	Hvid
Skærm diagonal:	- "
Skærmopløsning:	- pixel
Wi-Fi:	Ingen
Relativ luftfugtighed ved drift (H-H):	5 - 93 %
Driftstemperatur (T-T):	0 - 50 °C
Monteringstype:	Væg/bordplade
