Intrusion Alarm Systems | D9127 Series POPIT Modules

D9127 Series POPIT Modules

www.boschsecurity.com

uProvides point identification of initiating devices

uSupervises wiring to devices for circuit integrity

uExpands the number of points in the system

uCompact size

uTerminal connections for reliability

The D9127 Series POPIT Modules includes the D9127T

(with magnetic tamper switch) and the D9127U

(without tamper). They are used with a D8125 or B299

Addressable Expansion Module when there is a need

to expand a compatible control panel beyond its

standard number of on-board initiating zones or

points. Future system expansion is very economical as

D9127 Series POPITs can be added anywhere along

the two-wire data expansion loop from the D8125 or

B299 modules.

Both modules include proven technology that

combines zone and point supervision with individual

device addressing on one pair of wires. Screw

terminals provide reliable connections for the data

expansion loop and supervised sensor loop wiring.

Install a 33 kΩ end-of-line resistor at the farthest point

on the loop for proper supervision. The units are small

and easily installed in standard outlet boxes, above

false ceilings, closets, or other accessible locations.

Certifications and approvals

Region Regulatory compliance/quality marks

USA UL

UL UL 365 - Police Station Connected Bur-

glar Alarm Units

UL UL 464 - Standard for Audible Signal Ap-

pliances

UL UL 609 - Standard for Local Burglar

Alarm Units and Systems

UL UL 864 - Standard for Control Units and

Accessories for Fire Alarm Systems

(10th edition)

UL UL 985 - Household Fire Warning Sys-

tem Units (6th edition)

UL UL 1023 - Household Burglar Alarm Sys-

tem Units

UL UL 1076 - Proprietary Burglar Alarm

Units and Systems

UL UL 1610 - Central Station Burglar Alarm

Units

UL UL 1635 - Standard for Digital Alarm

Communicator System Units

Region Regulatory compliance/quality marks

CSFM California State Fire Marshal

FDNY-

CoA

6059 [D9412GV3 & D7412GV3]

FDNY-

CoA

6286 D7412GV4 D9412GV4 NYC COA

6286 2018-2021

FDNY-

CoA

6196

Australia CTICK C-Tick

Canada ULC CAN/ULC S304 - Standard for Signal Re-

ceiving Center and Premise Burglar

Alarm

ULC S303 - Local Burglar Alarm Units and

Systems

ULC ULC 365 - Police Station Connected Bur-

glar Alarm Units

ULC APOU7.S1871 Proprietary Alarm Units

Certified for Canada

ULC ULC-ORD C1023 - Household Burglar

Alarm System Units

Installation/configuration notes

Compatibility Information

Control Panels All G Series control panels, D9412, D7412,

D7212, D7212B1, D9112, D9112B1,

D8112G1, D8112G2, and D9124

Modules D8125, B299

The D8125 or B299 POPEX Modules are required. The

D9127 modules are wired in parallel on the D8125 or

B299 data loops.

Number of POPIT Modules per Control Panel

D7212G, D7212GV2, D7212GV3 32 D9127 POPITs

D7212B1 40 D9127 POPITs

D7212, D7412, D7412G, D7412GV2,

D7412GV3, D7412GV4

67 D9127 POPITs

D9124 119 D9127 POPITs

D9112B1 126 D9127 POPITs

D9112, D9412, D9412G, D9412GV2,

D9412GV3, D9412GV4

238 D9127 POPITs

B8512G (D8125) 67 D9127 POPITs

B8512G (B299) 91 D9127 POPITs

B9512G (D8125) 238 D9127 POPITs

B9512G (B299) 591 D9127 POPITs

Wiring Considerations

Wire Size

Wire SizeWire Size Maximum Length of all Data

Maximum Length of all Data

Maximum Length of all DataMaximum Length of all Data

Expansion Loops Combined

Expansion Loops CombinedExpansion Loops Combined

0.8 mm (22 AWG) 549 m (1800 ft)

1.0 mm (20 AWG) 881 m (2890 ft)

1.2 mm (18 AWG) 1402 m (4600 ft)

1.5 mm (16 AWG) 2231 m (7320 ft)

1.8 mm (14 AWG) 3551 m (11650 ft)

D8125 or B299 POPIT Loops

Use one two-wire data expansion loop, or distribute

the POPITs on multiple loops. The maximum lengths

shown in the following table are for all data expansion

loops combined connected to the same D8125 or

B299 module. Setting DIP switches on the POPIT

modules assigns them to point numbers. The switch

setting on each POPIT assigns it a point number,

regardless of its physical location.

POPIT to Sensor Loops

The number of detection devices each sensor loop can

supervise is limited only by the resistance on the loop.

Resistance on each sensor loop must be less than

100 Ω not including the end-of-line (EOL) resistor.

Certain UL and National Fire Protection Association

(NFPA) applications can limit the number of detection

devices. Consult the appropriate UL or NFPA

standards.

Terminate each POPIT sensor loop with the 33 kΩ EOL

resistor included with each POPIT.

Use a twisted-pair wire (six twists per foot) in all

POPIT installations for both the data expansion loop

wiring and the POPIT sensor loops. Run wires away

from AC sources to prevent AC induction.

Technical specifications

Environmental Considerations

Relative humidity Up to 93% non-condensing

Temperature

(operating)

0°C to +60°C (+32°F to +140°F)

For UL Certifcated Installations, 0

C to +50

(+32

F to +122

Properties

Color Off white

Dimensions 8.1 cm x 3.8 cm x 2.4 cm

(3.2 in. x 1.5 in. x 0.9 in.)

Material UL Listed fire-resistant

2 | D9127 Series POPIT Modules
