Side 1/4
LTC 9215/00, LTC 9215/00S, LTC 9219/01
Instruction Booklet
EN Indoor/Outdoor
Feed-through Mounts
SAFETY PRECAUTIONS
The exclamation point within an equilateral
triangle is intended to alert the user to
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
SECURITE
Le point d'exclamation à l'intérieur d'un triangle
équilatéral avertit l'utilisateur de la présence
d'instructions importantes d'utilisation et de
maintenance dans la documentation
accompagnant l'appareil.
SICHERHEITSVORKENHRUNGEN
Das Ausrufezeichen in dem gleichseitigen
Dreieck ist dazu da, den Benutzer auf wich-tige
Inbetriebnahme- und Instandhaltungs-vorschriften
hinzuweisen, die dem Gerät in Form einer
Broschüre beigelegt sind.
PRECAUCIONES DE SEGURIDAD
El símbolo de exclamación dentro de un
triángulo equilátero, se muestra con el objetivo
de alertar al ususario de que instrucciones de
operación y mantenimiento importantes
acompañan al equipo.
1 UNPACKING
This equipment should be unpacked carefully and handled
with care.
Check for the following items:
• Model number of unit.
• Instructions for Use.
If an item appears to have been damaged in shipment, replace
it properly in its carton and notify the shipper. If any items
are missing, notify Bosch Security Systems.
The shipping carton is the safest container in which the unit
may be transported. Save it for possible future use.
2 SERVICE
If the unit ever needs repair service, the customer should
contact the nearest Bosch Security Systems, Inc. Service
Center for authorization to return and shipping instructions.
Service Centers
U.S.A.: 800-366-2283 or 717-735-6638
Fax: 800-366-1329 or 717-735-6639
Email: BoschCCTVParts@ca.slr.com
Canada: 514-738-2434
Europe, Middle East & Asia Pacific Regions
32-1-440-0711
For additional information, see www.boschsecurity.com
2
3 DESCRIPTION
LTC 9215/00 30-cm (12-in), LTC 9215/00S 18-cm (7-
in), and LTC 9219/01 40-cm (15-in) Feed-through
Mounts.
This indoor/outdoor mounting equipment is designed for
fixed camera or camera housing installations up to kg (5 11
lb) rated load. These models are made of lightweight
aluminum and feature welded construction, providing an
extremely rigid camera mount. The LTC 9215/00S has been
designed specifically for the LTC 9480 series housings, while
the LTC 9215/00 and LTC 9219/01 can be used with the
LTC 9480, LTC 9483, and LTC 9488 series camera housings.
All mounts come fully assembled.
4 INSTALLATION
1. Determine a secure wall mounting location.
WARNING: All mounts are designed to
support a load only in a vertical direction. Mounts
MUST be positioned as shown under
SPECIFICATIONS.
Warning:
a. For a secure installation, use four 8-mm (5/16-in)
diameter fasteners (not included). Use stainless steel
or zinc plated fasteners.
b. If bolts are used, they should extend through the
mounting surface and be secured with flat washers,
lock washers, and nuts on the opposite side. Each
bolt must have a minimum pull-out strength of 200 kg
(450 lb).
c. If studs are used, they should be anchored in concrete
or welded to a steel backer plate. Each stud must
have a minimum pull out strength of 200 kg (450 lb).
d. If the wall mount is attached to wood or to a blind
structure (with no access to the rear), each fastener
must have a minimum pull-out strength of at least 200
kg (450 lb).
2. Locate the four holes or stud locations using the flange as
a template (four holes equally spaced on a 69.9-mm (2-
3/4-in bolt circle).
3. Feed wires through the large hole in the flange or
through the slot on the surface where the camera
housing mounts.
4. Install the mount using bolts or studs at least 8-mm
(5/16-in) in diameter.
5. To mount the camera housing:
a. Mount housings with two 1/4-20 bolts and lock
washers (not included).
b. Lock mount head in position by using the supplied
1/8-inch long-arm hex wrench to tighten screws.
