Side 1/40

INSTALLER MANUAL

Pellet Stove

LORD 7/7.0 - SWEET

7/7.0 - PERLA

7/7.0, - CRISTAL

7/7.0 -

ONE AIRTIGHT - BEAM AIRTIGHT - ACCENT AIRTIGHT

SHARP AIRTIGHT - LEE AIRTIGHT - SOUND

5/7 UP

CHROME 5/7 AIRTIGHT - ROUND 5/7 AIRTIGHT - FLOYD 5.0/7.0

new

Stufe a pellet

SUMMARY

1 MANUAL SIMBOLOGY ....................................3

2 PACKAGING AND HANDLING ..........................3

2.1 PACKAGING .............................................................3

2.2 REMOVING THE STOVE FROM THE PALLET ..............3

2.3 STOVE HANDLING....................................................4

3 CHIMNEY FLUE .............................................4

3.1 PREPARING THE SMOKE EXPULSION SYSTEM .........4

3.2 CHIMNEY COMPONENTS .........................................4

3.3 SMOKE DUCT (SMOKE FITTING) ..............................5

3.4 FLUE (CHIMNEY OR PIPED DUCT) ...........................5

3.5 CHIMNEY POT ..........................................................6

3.6 MAINTENANCE ........................................................7

4 COMBUSTION AIR .........................................7

4.1 AIR INLET ................................................................7

4.2 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER

INSTALLATION ...................................................................8

5 EXAMPLES OF INSTALLATION (DIAMETERS AND

LENGTHS TO BE SIZED) ........................................9

6 INSTALLATION ............................................10

6.1 INTRODUCTION .....................................................10

6.2 MINIMUM DISTANCES ........................................... 11

6.3 OVERALL DIMENSIONS .........................................12

6.4 STOVE DOOR REMOVAL/INSTALLATION ................18

6.5 REMOVAL/ASSEMBLY OF THE FRAME (SWEET

7.0 -

ONE AT - BEAM AT - ACCENT AT - ACCENT K AT) ..............18

6.6 REMOVAL/ASSEMBLY OF SIDE PANELS (SWEET

7.0 -

ONE AT - BEAM AT - ACCENT AT - ACCENT K AT) ..............18

6.7 REMOVAL/ASSEMBLY OF SIDE PANELS (CRISTAL

7.0

- LORD 7.0) .......................................................................19

6.8 REMOVAL/ASSEMBLY OF SIDE PANELS (SHARP AT -

LEE AT) .............................................................................19

6.9 REMOVAL/ASSEMBLY OF BACK PANELS (PERLA

7.0)

..............................................................................20

6.10 TILES ASSEMBLY (PERLA

7.0) ..............................20

6.11 REMOVAL/ASSEMBLY OF METAL/TILE PROFILES

(PERLA

7.0).....................................................................20

6.12 MOUNTING THE STAND (ACCENT AT) ....................21

6.13 REMOVAL/ASSEMBLY OF CURVED SIDE PANELS

(CHROME - SOUND - ROUND - FLOYD) ............................21

6.14 INSTALLATION OF TEE FITTING (EXCLUDING SOUND

UP - CHROME AT - FLOYD MODELS) ................................22

6.15 INSTALLATION OF SHARP AIRTIGHT REAR EXHAUST

..............................................................................22

6.16 INSTALLATION OF THE FUMES OUTLET CONCENTRIC

PIPE SHARP/LEE/CRISTAL/ONE/BEAM/ACCENT/PERLA/

SWEET/LORD ...................................................................22

6.17 INSTALLATION OF CONCENTRIC SMOKE OUTLET WITH

COMBUSTION AIR DECOUPLED (ONLY MODELS CHROME/

ROUND/FLOYD/SOUND) ..................................................23

6.18 ELECTRIC CONNECTION .........................................24

6.19 CONNECTION TO THE EXTERNAL THERMOSTAT .....24

6.20 CONNECTION TO THE EXTERNAL THERMOSTAT .....25

6.21 STOVE CALIBRATION AND DEPRESSION

MEASUREMENT ...............................................................25

7 SPECIAL MAINTENANCE ..............................26

7.1 INTRODUCTION .....................................................26

7.2 FUME CONDUIT CLEANING .................................... 26

7.3 FUME CONDUIT CLEANING ROUND STOVES ..........27

7.4 FUME PASSAGES CLEANING ..................................28

7.5 ROOM FAN CLEANING ...........................................29

7.6 FUME PIPES ANNUAL CLEANING ..........................29

7.7 GASKET REPLACEMENT ......................................... 29

8 IN CASE OF ANOMALY ..................................29

8.1 PROBLEM SOLVING ...............................................29

9 TECHNICAL DATAS ......................................32

9.1 REPAIR INFORMATION ..........................................32

10 FEATURES ..................................................33

Produkt Specifikationer

Mærke:	Cadel
Kategori:	Komfur
Model:	Sound 5 Up
Antal effektniveauer:	3
Velegnet til rumvolumen på op til:	157 m³
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	498 mm
Dybde:	597 mm
Højde:	949 mm
Vægt:	76000 g
Produktfarve:	Anthracit
Kontroltype:	Knapper
Strøm:	- W
Pakkevægt:	86000 g
Placering af apparat:	Fritstående
Velegnet til værelsesareal på op til:	58 m²
Strømkilde:	Vekselstrøm
Strømforbrug (maks.):	49 W
Fjernbetjent:	Ja
Brændstof, type:	Træpiller
Udsugningsforbindelse, diameter:	80 mm
Termostat:	Ja
Effektivitet:	86 %
Placering af udsugning:	Top
Ovn inkluderet:	Ingen
Programmeringsfunktion:	Ja
Tragt kapacitet:	11 kg
Effektivitet (nominel):	90 %
Effektivitet (reduceret):	91 %
Træpille forbrug (min.):	0.6 kg/t
Træpille forbrug (maks.):	1.3 kg/t
Gennemsnitligt støvindhold:	20 mg/Nm³
Kulilte (CO) niveau (nominel):	0.011 %
Røggas temperatur:	149 °C
Røggas (maks.):	10 Pa
Kulilte (CO) niveau (reduceret):	0.019 %
Strømforbrug (antænding):	345 W
Varmetilførsel (nominel):	5.5 kW
Varmetilførsel (reduceret):	2.5 kW
Træpille diameter understøttet (maks.):	6 mm
Ekstern termostat:	Ja
