INSTALLATION INSTRUCTIONS

XL Fusion Pull-Out Accessory

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

FCAXV1U

FCAXV1U Installation Instructions

DISCLAIMER

Legrand | AV and its affiliated corporations and subsidiaries

(collectively “Legrand | AV”), intend to make this manual

accurate and complete. However, Legrand | AV makes no claim

that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Legrand | AV

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Legrand | AV

assumes no responsibility for accuracy, completeness or

sufficiency of the information contained in this document.

Chief® is a registered trademark of Legrand AV Inc.

DEFINITIONS

MOUNTING SYSTEM: A MOUNTING SYSTEM is the

primary Chief product to which an accessory and/or component

is attached.

ACCESSORY: AN ACCESSORY is the secondary Chief

product which is attached to a primary Chief product, and may

have a component attached or setting on it.

COMPONENT: A COMPONENT is an audiovisual item

designed to be attached or resting on an accessory or mounting

system such as a video camera, CPU, screen, display,

projector, etc.

WARNING: A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all accessories are

properly assembled and installed using the instructions

provided.

WARNING: Failure to provide adequate structural strength

for this accessory can result in serious personal injury or

damage to equipment! It is the installer’s responsibility to

make sure the structure to which this accessory is attached

can support five times the combined weight of all equipment.

Reinforce the structure as required before installing the

accessory.

WARNING:

Exceeding the weight capacity can result in

serious personal injury or damage to equipment! Adding the

FCAXV1U accessory may change the weight capacity listed

for the mounting system, and is dependent upon the mounting

substrate. Consult (Table 1) for the XTM1U and XSM1U

mounting systems’ weight capacities when attached to the

FCAXV1U and mounted to various mounting substrates.

Table 1:

Weight Capacity When Attached to FCAXV1U

WARNING: Use this accessory only for its intended use as

described in these instructions. Do not use attachments not

recommended by the manufacturer.

WARNING: Never operate this accessory if it is damaged.

Return the accessory to a service center for examination and

repair.

WARNING: Do not use this accessory outdoors.

NOTE: Accessory is intended to be used with the following

Chief mounting systems (not included):

•XTM1U

• XSM1U

--SAVE THESE INSTRUCTIONS--

Mounting

Substrate

XTM1U Max

Weight Allowed

XSM1U Max

Weight Allowed

Triple 16" on-

center 2" x 4"-

25ga minimum

steel studs wall

200 lbs (90.7 kg) 200 lbs (90.7 kg)

Triple 16" on-

center 2" x 4"

wood studs wall

250 lbs (113.4 kg) 200 lbs (90.7 kg)

3/4" Plywood-

backed steel

stud wall

covered with

maximum

drywall

thickness of 5/8"

250 lbs (113.4 kg) 200 lbs (90.7 kg)

Bare 8"

Concrete Wall

250 lbs (113.4 kg) 200 lbs (90.7 kg)

Bare 8"x8"x16"

Concrete Block

Wall

250 lbs (113.4 kg) 200 lbs (90.7 kg)
