In-Wall Accessory Boxes

I N S T A LLA T I O N I N S T R U C T I O N S

PAC525/526

PAC525

PAC526

Installation Instructions

PAC525/526

DISCLAIMER

Milestone AV Technologies and its affiliated corporations and

subsidiaries (collectively “Milestone”), intend to make this

manual accurate and complete. However, Milestone makes no

claim that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Milestone

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Milestone assumes

no responsibility for accuracy, completeness or sufficiency of

the information contained in this document.

Chief® is a registered trademark of Milestone AV Technologies.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING: Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all components are

properly assembled and installed using the instructions

provided.

WARNING: Failure to provide adequate structural strength

for this accessory can result in serious personal injury or

damage to equipment! It is the installer’s responsibility to

make sure the structure to which this accessory is attached

can support five times the combined weight of all equipment.

WARNING: Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components located in the accessory does not exceed

10 lbs (4.5 kg).

WARNING: Use this mounting system only for its intended

use as described in these instructions. Do not use

attachments not recommended by the manufacturer.

WARNING: For indoor use only.

IMPORTANT ! : The PAC525/526 mounts are designed to

be mounted to a 2” x 4” wood stud wall 16” on center, a 2” x 4”

-25ga (minimum) steel studs wall, or to a 1/2” minimum

thickness drywall surface.

NOTE: Spacings - Minimum spacings between the 120 Vac

power components and the A/V components shall be main-

tained for safe operation of the equipment when installed in

accordance with the National Electric Code, ANSI/NFPA 70.

NOTE: When selecting a Listed 120 Vac Receptacle for use as

the main power source for the PAC Series boxes (to power the

A/V equipment), make sure that AC Receptacle is rated at least

15A and it is used in the building's AC branch circuit that is

connected to a circuit breaker rated at least 15A. Do not

connect more than 12A from the Receptacle.

In the U.S., the equipment shall be installed per the applicable

requirements of the National Electrical Code, ANSI/NFPA 70.

In Canada, the equipment shall be installed per the applicable

requirements of the Canadian Electrical Code, CSA C22.1.

NOTE: It is the installer’s responsibility to ensure that the

enclosure is bonded to the ground in the switch box, in

accordance with the National Electric Code, ANSI/NFPA 70

or Canadian Electrical Code, CSA C22.1. A green grounding

screw is provided in the enclosure for the purpose, if required.

--SAVE THESE INSTRUCTIONS--
