I N S T A L L A T I O N I N S T R U C T I O N S
PAC527
PAC527F
PAC527FC
PAC527FxP4
PAC527FxP6
PAC527F-KIT
PAC527CVR-KIT
PACPL1
In-Wall Box and Accessories
PAC527 Series
PAC527 Series Installation Instructions
2
DISCLAIMER
Milestone AV Technologies and its affiliated corporations and
subsidiaries (collectively “Milestone”), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
DEFINITIONS
MOUNTING SYSTEM: A MOUNTING SYSTEM is the
primary Chief product to which an accessory and/or component
is attached.
ACCESSORY: AN ACCESSORY is the secondary Chief
product which is attached to a primary Chief product, and may
have a component attached or setting on it.
COMPONENT: A COMPONENT is an audiovisual item
designed to be attached or resting on an accessory or mounting
system such as a video camera, CPU, screen, display,
projector, etc.
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all accessories are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this accessory can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this accessory is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
accessory.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components located in the accessory does not exceed
40 lbs (18.1 kg).
• Each PAC527 may hold up to 4 individual backplanes
(2 complete) and each individual backplane may hold a
maximum weight of 10 lbs (4.5 kg)
• A half backplane (after separation) may hold a
maximum weight of 5 lbs (2.3 kg).
WARNING: Use this accessory only for its intended use as
described in these instructions. Do not use attachments not
recommended by the manufacturer.
WARNING:
Never operate this accessory if it is damaged.
Return the accessory to a service center for examination and
repair.
WARNING: For indoor use only.
IMPORTANT ! : The PAC527 accessory is designed to be
mounted to either a 2" x 3" or 2" x 4" wood stud wall 16" on
center, or a 2" x 3"-25ga (minimum) or 2" x 4"-25ga (minimum)
steel studs wall.
NOTE: Spacings - Minimum spacings between the 120 Vac
power components and the A/V components shall be
maintained for safe operation of the equipment when
installed in accordance with the National Electric Code,
ANSI/NFPA 70.
NOTE: When selecting a Listed 120 Vac Receptacle for use as
the main power source for the PAC series boxes (to
power the A/V equipment), make sure that AC
Receptacle is rated at least 15A and it is used in the
building’s AC branch circuit that is connected to a
circuit breaker rated at least 15A. Do not connect more
than 12A from the Receptacle.
In the U.S., the equipment shall be installed per the applicable
requirements of the National Electrical Code, CSA C22.1.
In Canada, the equipment shall be installed per the applicable
requirements of the National Electrical Code, ANS/NFPA 70.
NOTE:
It is the installer’s responsibility to ensure that the
enclosure is bonded to the ground in the switch box, in
accordance with the National Electric Code, ANSI/NFPA
70 or Canadian Electrical Code, CSA C22.1. A green
grounding screw is provided in the enclosure for the
purpose, if required.
IMPORTANT ! : The PAC527 mounts are designed to
accommodate the following Chief power kits ONLY:
• PAC527P4-KIT
• PAC527P6-KIT
--SAVE THESE INSTRUCTIONS--
DIMENSION DRAWINGS are located at the end of these
Installation Instructions.
