Premium Locking Floor Stand Kiosk
w/ Universal Security Enclosure, Keyboard Tray
and Storage Compartment (Black)
PAD-PARAFK
INSTRUCTION - MANUAL
CONTENTS:
INSTALLATION:
888-733-4448
A
x4
M4 x12
H
O
x1
M5 Allen Key
3. Attaching enclosure to VESA plate : 4. Inserting tablet into enclosure :
1A. Allign the holes on the sntad (A) with holes on the base (B) and turn in
screws (L) with provided allen tool (P) until securely tightened. Shown above.
2B. When the cable reaches the
bottom of the stand, pull through the
hole at the stand back and remove
the weighted pendant as shown.
2A. To route a charge cable through
the stand, attach the weighted
pendant to your charge cable, then
pass through the cutout at the top of
the stand.
3A. Align enclosure (C) VESA holes to VESA plate holes in stand (A) and from the
front of enclosure turn in screws (J) into the threaded VESA holes with provided
allen tool (O) until securely thigtened. Shown above.
4A. Find the appropiate size foam padding (B) for the tablet you wish to use.
Make sure device is compatible for the enclosure. if having power/data cord
attached to tablet, slide it through the back of the foam as shown and out the
opening in the back.
**Tablet for illustration only,
NOT INCLUDED
C
x1
x1
F
M5 x12
x4
K
x4
M5 Nut
x1
D
E
x1
M5 x 10
J
x4
M5 x 10
x4
B
x1
x4
M5 x12
Washer
G
x4
M4 x12
Washer
I
x1
N
P
x1
M6 Allen Key
L
x4
M
M6 p1-x4
M6
2. Cable routing :
M
M
C
C
A
O
A
B
L
P
J
8. Setting up keyboard tray to floor stand :
10. Mounting magnetic brochure holder :
9. Expanding or Stowing Tray Extension
9A. If not extended, find the tray extension on the underneath of the main tray
body. Firmly adjust and fold out tray extension. Insert metal rod component into
hole as shown to securely lock extension piece in place. When stowing away,
you need to remove rod first, then fold up by rotating around the joint.
8A. Place keyboard tray (D) on the side holes of stand at desired height and turn in
Screws and washers(F,G or H,I) with the provided allen tool (O) until securely
tightened. Shown above.
11A. Enclosure can be mounted in vertical and horizontal positions as
needed. Shown above.
10A. Locate magnetic brochure
holder (E) and snap it onto
stand body (A) as needed.
**Tablet for illustration only,
NOT INCLUDED
**Tablet for illustration only,
NOT INCLUDED
**There are two versions
of the floor stand so both
set of hardware have been
included. One of the sets
will be left unused.
M
5. Optional - Placing blank sheet insert into enclosure :
M
C
M
5B. Close and lock enclosure afterwards and you`re set
5A. Lay-in correct masking insert from bundle (M) as needed the correct
fitted look for your device.
888-733-4448
D
O
M5 x12
Screw
F
G
M5 x12
Washer
OR
H
I
M4 x12
Screw
M4 x12
Washer
6A. When installing device into enclosure (C), identify where the camera is.
Then simply remove and pop out the cover prior to mounting or setting up tablet
to properly expose camera.
**Tablet for illustration only,
NOT INCLUDED
**Tablet for illustration only,
NOT INCLUDED
C
6. Removing back covers : 7. Setting up security :
C
N
7A. Once the tablet device is set up,
close the front lid of the enclosure (A).
7B. Insert the key (N) in the keyhole on top
of enclosure, and turn clockwise to lock the
enclosure in place.
11. Portrait & Landscape modes :
snap**
E
A
