DHI-IPMECD-302X
Straight Arm/Folding Arm Barrier
· Aracve housing with sheet metal and an aluminum prole design.
· Designed with an-smashing adhesive tape made of polymer polyure
thane material, the arm is safe, stable and has a long service life.
· Supports being connected to an an-smashing radar, loop and IR
device, and has a built-in 12 VDC motherboard that can power the
radar.
· Developed with an LED light belt, the housing and straight arm ap
pear red when the arm falls, and green when it rises.
· Automacally rises when the barrier arm makes contact with an
object.
· Rises automacally during a power failure.
· With rolling code technology, the barrier supports remote control at a
maximum distance of 50 m (164 ) when in an open environment
that does not have interference.
· Motor lifespan: 5 million cycles.
· Spring lifespan: 5 million cycles.
· Operang temperature: –40 °C to +70 °C (–40 °F to +158 °F).
· Operang humidity: 10%–90%.
· IP55 rated.
System Overview
Highly durable, the Straight Arm/Folding Arm Barrier is both stable and
safe to use, coming with a long service life. It is composed of ve parts:
the cover, housing, transmission unit, control unit, and an arm which
can be set on the le or right. Two models of the barrier are available.
One is the straight arm with a light belt included at the boom of the
arm, and the other is a folded arm. Both can be used along with a radar
to help prevent objects from colliding with the barrier.
Scene
It is suitable for use in public places and for access control into the
parking lots of oce buildings, hotels, tourist aracons, government
structures, schools, communies, airports, factories, and more.
Technical Specificaon
Basic
Arm Type
Straight arm, Folding arm
Arm Length
Straight arm: 3 m (9.84 ft); 4 m (13.12 ft); 5 m (16.40 ft);
6 m (19.68 ft)
Folding arm: 3 m (9.84 ft); 4 m (13.12 ft)
Arm Model
IPMECD-032X series
Opening/Closing Time
Straight arm: 3 m (9.84 ): 0.9 s; 4 m (13.12 ): 2 s; 5 m
(16.40 ): 3 s; 6 m (19.68 ): 3 s
Folding arm: 3 m (9.84 ): 0.9 s; 4 m (13.12 ): 2 s
Motor Type AC variable
Spring
3 m (9.84 ): 1 × 5.2 mm red spring
4 m (13.12 ): 1 × 6.3 mm blue spring
5 m (16.40 ): 1 × 5.2 mm red spring, 1 × 6.3 mm blue
spring
6 m (19.68 ): 1 × 5.2 mm red spring, 2 × 6.3 mm blue
spring
Port
Status Output
2 channels. Outputs signals when the arm is in the open
or closed posion.
Function
An-drop
Yes. Loop, IR, and radar an-smashing.
Auto Opening in Power
Failure
Yes
Auto Liing against
Obstrucon
Yes
An-collision
Supports colliding with objects up to 4 m high.
Count Mode
Yes
Access Barrier Series| DHI-IPMECD-302X
