Side 1/146

Dell™OptiPlex™960ServiceManual



Mini Tower Computer

Desktop Computer

Small Form Factor Computer

Back to Contents Page

 Battery

Dell™Optiplex™960MiniTower/Desktop/SmallFormFactorServiceManual

Replacing the Battery

Replacing the Battery



A coin-cell battery maintains computer configuration, date, and time information. The battery can last several years.

The battery may need replacing if an incorrect time or date is displayed during the boot routine along with a message such as:

Time- - - of day not set please run SETUP program

Invalid configuration information -

please run SETUP program

Strike the F1 key to continue,

F2 to run the setup utility

To determine whether you need to replace the battery, reenter the time and date in system setup and exit the program to save the information. Turn off your

computer and disconnect it from the electrical outlet for a few hours; then reconnect the computer, turn it on, and enter system setup (see the Dell

™

Technology Guide). If the date and time are not correct in system setup, replace the battery.

You can operate your computer without a battery; however, without a battery, the configuration information is erased if the computer is turned off or

unplugged from the electrical outlet. In this case, you must enter system setup (see the Dell™ Technology Guide) and reset the configuration options.



To remove the battery:



1. If you have not already done so, make a copy of your configuration information, found in system setup.



2. Perform the procedure Before Working on Your Computer.



3. Remove the computer cover.



4. Locate the battery socket.



5. Remove the system battery.

a. Support the battery connector by pressing down firmly on the positive side of the connector.

b. While supporting the battery connector, press the battery tab away from the positive side of the connector and pry the battery it up out of the

securing tabs at the negative side of the connector.

CAUTION: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional

safety best practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

NOTICE: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of your

computer's electronic components. You can do so by touching an unpainted metal surface on the computer chassis.

CAUTION: A new battery can explode if it is incorrectly installed. Replace the battery only with the same or equivalent type recommended by the

manufacturer. Discard used batteries according to the manufacturer's instructions.

NOTICE: If you pry the battery out of its socket with a blunt object, be careful not to touch the system board with the object. Ensure that the

object is inserted between the battery and the socket before you attempt to pry out the battery. Otherwise, you may damage the system board by

prying off the socket or by breaking circuit traces on the system board.

NOTICE: To avoid damage to the battery connector, you must firmly support the connector while removing the battery.

Produkt Specifikationer

Mærke:	Dell
Kategori:	Skrivebord
Model:	OptiPlex 960
Bredde:	85 mm
Dybde:	323 mm
Højde:	289 mm
Vægt:	5900 g
Produktfarve:	Sort
Produkttype:	PC
Wi-Fi:	Ingen
DVI-port:	Ingen
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	10
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Processorkerner:	2
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Intern hukommelse:	4 GB
Operativsystem installeret:	Windows 7 Professional
Fjernbetjening inkluderet:	Ingen
Indbygget kortlæser:	Ingen
Intel® Wireless Display (Intel® WiDi):	Ingen
Processorfrekvens:	3 GHz
Processorserie:	Intel® Core™2 Duo
Processortråde:	2
Processor-cache:	6 MB
Processor cache type:	L2
Intern hukommelsestype:	DDR2-SDRAM
Hukommelsesur hastighed:	800 Mhz
Maksimal intern hukommelse:	16 GB
Samlet lagringskapacitet:	250 GB
On-board grafikkort, model:	Ikke tilgængelig
Diskret grafikadaptermodel:	AMD Radeon HD 3470
On-board grafikkort:	Ingen
Mikrofonindgang:	Ja
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ingen
Intel® Turbo Boost Teknologi:	Ingen
Processorproducent:	Intel
Processormodel:	E8400
Antal DisplayPorts:	1
Antal VGA-porte (D-sub):	1
TV-tuner, integreret:	Ingen
Mus inkluderet:	Ingen
Optisk drevtype:	DVD-RW
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
Intel® VT-x with Extended Page Tables (EPT):	Ingen
Indlejret tilgængelige muligheder:	Ja
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Skærm inkluderet:	Ingen
Linie ud:	Ja
Line-in:	Ja
HDD-grænseflade:	SATA
Overholdelse af branchestandarder:	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Netværksfunktioner:	Gigabit Ethernet
Antal serielle porte:	1
Antal installerede processorer:	1
Bus type:	FSB
Kabinettype:	SFF
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD hastighed:	7200 rpm
Antal PS/2-porte:	2
Processor sokkel:	LGA 775 (Socket T)
Processor litografi:	45 nm
Stepping:	E0
Thermal Design Power (TDP):	65 W
Fejlkorrigerende kode understøttet af processor:	Ingen
Processor front side bus:	1333 Mhz
Systembus-hastighed:	- GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Wolfdale
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ingen
Intel® Demand Based Switching:	Ingen
Termiske overvågningsteknologier:	Ja
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	37.5 x 37.5 mm
Processor kode:	SLB9J
Grafisk og IMC litografi:	45 nm
Processor ARK ID:	33910
Hukommelseslayout (slots x størrelse):	2 x 2 GB
CPU-multiplikator (bus/kerneforhold):	9
PCI Express x16 slots:	1
Diskret grafikadapterhukommelse:	256 GB
Maksimal grafikadapterhukommelse:	- GB
Antal eSATA-porte:	1
Antal behandling Die transistorer:	410 M
Behandling Die størrelse:	107 mm²
Tastatur inkluderet:	Ingen
PCI-slots:	2
Tcase:	72.4 °C
Grafikadapter familie:	AMD
Floppy drive installed:	Ingen
