AC-5000W Quick Start Guide

Camera Diagram:

LCD Display Diagram:

Turn on the Wi-Fi camera, the LCD will display the following status

and settings:

1. Camera mode

2. Video recording mode (default)

3. Wi-Fi icon (display when enabled)

4. Micro SD card icon (display when loaded)

5. Resolution icon:

In camera mode, HI stands for 8 Mega Pixels (interpolated)

(3264x2448), and in video recording mode, it stands for FHD

(1920x1080, 30fps);

In camera mode, LO stands for 5 Mega Pixels (2592x1920), and in

video recording mode, it stands for 720P (1280x720, 30fps);

HILO only displays in video recording mode, standing for 720P

(1280x720,60fps).

6. Mute mode, displays when enabled, and disabled by default.

7. Counter, displays up to 999.

8. Timer, displays hours and minutes.

9. Battery icon: current battery level of the camera.

Note: The above icons may vary according to the status of the

camera.

Using your camera:

1)When you use the camera for the first time, please:

Insert a micro SD or micro SDHC card (not included), as shown in

the following picture.

A Class 10 Micro SD Card is required for this camera.

Turn off the camera before inserting or removing the card.

2)Turn on/off

1, Turn on: press and hold the button for about 3 seconds, LCD

displays “ON” and a beep can be heard from buzzer.

2,Turn off: press and hold the button for about 3 seconds, LCD

displays “OFF” and a beep can be heard from buzzer.

3)Start to Use

1.Default setting: After turn on the DV, the default setting is as

below:

Video

recording

mode

icon

The DV is in video recording mode.

HI Video

resolution FHD: 1080p@30fps

Recordin

g time Stands for 0 hour and 00 minute.

Micro SD

card icon

Display when a Micro SD card is

inserted, otherwise no display.

Battery

level Battery is full

Mute icon

The DV is in Mute mode, no Beep will

be heard when pressing the buttons. It

displays only when Mute mode is

activated.

Wi-Fi

icon Display when activated.

2,Shooting modes. The DV provides different shooting modes.

Press the button repeatedly, the following first two modes

will show on the DV screen , and other models display on the APP

operation.

Video

HI stands for FHD (1920x1080,30 fps)

video

Lo stands for 720P (1280x720,30 fps)

video

HILO stands for 720P (1280x720,60

fps) video


HI stands for 8M (3264 x 2448)

resolution

Lo stands for 5M (2592 x 1920)

resolution

Continuou

s shot

The DV supports taking 3 photos

continuously (only via App)

Self-timer

In self-timer mode , you can set 0s, 2s

or 10s (only via App)

3, Video

( With maximum 29 minutes video recording per sequence)

To record a video, please check whether the DV is under Video

mode. If the icon is not displayed on the screen, press

the button repeatedly until it appears.

Start recording: Press and release the button, the

icon and [:] displayed in LCD will flash. At the same time the

red indicator will flash too, meaning the recording is in process.

Stop recording: Press and release the button, the

icon and [:] displayed in LCD will stop flashing. At the same

time the red indicator will stop flashing either, meaning the

recording is stopped.

Shutter button

Microphone

LCD display

10)

Lens

11)

Wi-Fi switch and status indicator (red)

12)

Power / Mode button

13)

Infrared signal reception light

Micro B USB port

Mini C HDMI port

Micro SD card slot

External microphone port

Battery cover push

LED light

AC-5000W Quick Start Guide

When the Micro SD card is full, or the battery runs out, the

recording will stop automatically, and the recorded video will be

saved before the DV turns off.

4. Photo

To take a photo, please check whether the DV is under Camera

mode. If the icon is not displayed on the screen, press

the button repeatedly until it appears.

Press and release the button, a beep will be heard and the red

indicator will flash, meaning a photo is taken.(If you take photos

more than 999 copies, the LCD screen display only 999)

5. Enable/disable Wi-Fi

The Wi-Fi is disabled by default. Press the Wi-Fi button on the side

of the DV to enable it. When starting connecting to Wi-Fi network,

the indicator will flash, and when a Wi-Fi network is connected, the

indicator will remain on, and the Wi-Fi icon will display on LCD

screen.( In order to save power, Wi-Fi will be automatically disabled

if no terminal is connected after 30 seconds)

4) Using the Battery

1. Install the battery.

Please install the lithium battery correctly as shown:

Figure 1 Figure 2 Figure 3 Figure 4

Step 1. Push the battery cover switch to the lock position( ),

and remove the battery cover. As shown in figure 1.

Step 2. Place the lithium battery into the battery slot. Make sure the

polarity of the battery is corresponding to the symbols of the

camera shell( ). As shown in figure 2 and figure 3.

Step 3. Install the battery cover back in place, and lock the switch to

the lock position( )to fix the battery. As shown in figure 4.

2. Charging the battery:

The camera uses removable rechargeable lithium battery. When

the camera is off, connect it to the PC via the USB cable to charge

the battery.

During charging, the status indicator (blue) will be lit up and

the indicator will turnoff when charging completes.

Note: When the camera is on, connecting it to the PC will not

charge.

5) Pair the Camera to Your Smartphone or Pad.

1. Download and install the app “ ” from AppleSYMAGIX

Appstore® or Google Play

2. Press the Wi-Fi button on the side of the camera to initialize the

signal, the LED will be red

3. Search for the wireless signal “DENVER AC-5000W” on your

smartphone or tablet using

the password “ ”.1234567890

4. You can now start using the camera once the wireless signal is

connected and you have opened the app.

ELECTRONICS A/S

Electric and electronic equipment contains materials, components

and substances that can be hazardous to your health and the

environment, if the waste material (discarded electric and

electronic equipment) is not handled correctly.

Electric and electronic equipment is marked with the crossed out

trash can symbol, seen below. This symbol signifies that electric

and electronic equipment should not be disposed of with other

household waste, but should be disposed of separately.

All cities have established collection points, where electric and

electronic equipment can either be submitted free of charge at

recycling stations and other collection sites, or be collected from

the households. Additional information is available at the technical

department of your city.

Fill in the blank with the model number of this player, so you can

find it again later.

Imported by:

DENVER ELECTRONICS A/S

Stavneagervej 22

DK-8250 EGAA

Denmark

www.facebook.com/denverelectronics

Wi-Fi er disabled by

default

When Wi-Fi is enabled, the

Wi-Fi icon will display on LCD

Produkt Specifikationer

Mærke:	Denver
Kategori:	Videokamera
Model:	AC-5000W
Bredde:	60 mm
Dybde:	23 mm
Højde:	38 mm
Vægt:	- g
Produktfarve:	Sølv
Batterikapacitet:	1000 mAh
Indbygget skærm:	Ingen
Vægt (inkl. batteri):	58 g
Kompatible hukommelseskort:	MicroSD (TransFlash)
Wi-Fi:	Ja
Batteriteknologi:	Lithium
HD-type:	Fuld HD
Understøttede videotilstande:	1080p,720p
Antal HDMI-porte:	1
Understøttede videoformater:	H.264,MOV
Vandtæt op til:	55 m
Beskyttelsesfunktioner:	Vandtæt
Kabler inkluderet:	USB
Understøttede billedformater:	JPG
Fjernbetjening inkluderet:	Ja
Batterilevetid (maks.):	- t
GPS (satellit):	Ingen
Lagermedie:	Hukommelseskort
Indbygget mikrofon:	Ja
Mikrofonindgang:	Ja
Billedformat:	16:9
Sensortype:	CMOS
Maksimal billedopløsning:	3264 x 2448 pixel
Opløsning på stillbillede(r):	3264 x 2448, 2582 x 1344
Samlet antal megapixels:	5 MP
Maksimal videoopløsning:	1920 x 720 pixel
Videoopløsninger:	1280 x 720,1920 x 1080 pixel
Maksimal størrelse på hukommelseskort:	32 GB
Maksimum billedhastighed:	60 fps
Synsfelt vinkel (FOV):	120 °
Fototilstand:	Ja
Undervandsbeholder:	Ja
Cykelbeslag:	Ja
