Side 1/4

ACG-8050W Quick Start Guide

ENG 1

PC software:

http://www.denver-electronics.com/pc-software-for-denver-

acg- - -action-cam/8050w gps

1. Charge the built-in lithium battery

Connect the camera to the computer for charging, at this time, the

charging indicator will be in blue , and it will be oﬀ after charging.

Generally, it takes 2-4 hours to charge the battery.

2. Use the storage card

2.1. Push the Micro SD card into the slot till it is in place as per the

instruction in concavely engraved words by the storage card slot.

2.2. To take out the Micro SD card, press the tail of the storage card

inwardly softly and it will be popped out.

Please notice: UHS (ultra highspeed) cards doesn’t work, as they are not

100% backward compatible

Note: There’s no built-in memory unit in the camera, so make sure to

insert a storage card into it prior to use (it is recommended that a Micro

SD card of better quality be used).

3. Power on/oﬀ

3.1 Power on: Press Power key for 3 seconds, the screen will be on and

the camera will be started.

3.2. Power oﬀ: Hold on Power key for 3 seconds when the camera is in

the idle state to turn it oﬀ.

3.3. Auto screen oﬀ: The screen will be turned off automatically when

the time that the camera is in the idle state for automatic screen oﬀ to

save power. After that, the lamp for screen oﬀ will be on.

3.4. Power oﬀ when the camera is lack of electricity. When electrical

quantity of the battery is very low, an icon of will be displayed

on the LCD screen, prompting you to charge it in time. When the icon

turns red and ﬂickers, the camera will be turned oﬀ automatically.

4. Shift among functional modes

The camera has modes, namely video recording mode, shooting mode 3

and replay mode. After power is on, press Power key to shift among

them.

Video recording mode Shooting mode

5. Indicator

Busy indicator (red): When the camera is busy such as recording

videos, shooting photos and turning oﬀ screen automatically, the work

indicator will ﬂicker.

Charging indicator (blue): When it is on, the user is prompted that the

camera is being charged and it will be oﬀ after charging is completed.

6. Video recording mode

After power is on, the video camera will enter video recording mode

directly and in preview mode, press Shutter key to start video recording;

Press it again to stop shooting. If the memory card is full or electrical

quantity is low, it will also stop shooting:

Taking a photo while recording: press the Power button during recording

to take a photo. When a photo is taken, the texts “CAPTURE DONE”

will display on the screen.

1. Icon of mode, indicating video recording mode;

2. Indicate quality of video;

3. Indicate size of video, and FHD 1080P (60FPS)

/ FHD 1080P (30FPS) / HD 720P (120FPS)

/ HD 720P (60FPS) / HD 720P (30FPS) is optional;

4. Recording time, indicating recordable length of time;

5. Icon of battery, indicating current electrical quantity;

( With maximum 29 minutes video recording and then stop.Must be

started manually on the camera again.)

7. Shooting mode

After power is on, press Power key twice to enter shooting mode, and

in preview state, press Shutter key to take a photo:

1. Icon of mode, indicating the current is shooting mode;

2. Size of video, and 5M/8M//12M/16MP is optional;

3. Icon of quality of pictures;

4. Counter, indicating number of photos to be taken;

5. Icon of electrical quantity of battery.

8.GPS Mode



 



 use introductions:

PC software:

http://www.denver-electronics.com/pc-software-for-denver-

acg- - -action-cam/8050w gps

Microphone

2.0 HD LCD ’’

Lens

Infrared remote

control lamp

Charging /Busy indicator

Wiﬁ/Down key

HDMI port

Battery door

Micro SD Card

Shutter/OK key

USB cable

Micro USB port

Busy indicator

Display/Menu

key

ACG-8050W Quick Start Guide

ENG 2

en start GPS function,all the video will include GPS Wh

information:Shooting time and date, move distance, local altitude

information, calorie data, active speed, you can see all these

informations by player on You can also see PC. location in the

GPS PC Player including Google Maps.This function works only

for video.

8.1 Enter GPS mode

When you power on camera it will automatically start searcing for GPS

signal. .  

GPS signal searching Finish GPS signal search

If the camera not ﬁnd GPS signal, please press shutter can

button,you can see the screen show GPS OFF . ” ”

8.2 Recording and view

When GPS OK, press shutter button start recording. Now you to

can see the timer will start work in the top right screen(As below

picture).If you need to stop recording please press shutter again.

After ﬁnishing recording, all the GPS information will saved be

into your SD card, You can view this by GPS Player . PC

If GPS OFF, your recording files will not include GPS

information.

To view GPS info on camera, Please press DISP/MENU,then

choose Sport info ,press Shutter key : “ ”

Number:Files quantities ；

Time:Recording time;

Speed:Recording speed

Distance:Acftive distance

Callorie:Active expend energy data.

View video from computer.

After recording,connect camera to PC,it will enter MSDC

mode,then turn on GPS player(Please download and setup this

ﬁrmware to PC from website ﬁrst)as below picture:

Note: GPS satellites is easiest to find under open sky with no tall

trees or buildings around you.

9.Menu operation

There is a diﬀerent menu in each working mode as shown in the

following ﬁgures:

Menu for video recording Menu for shooting mode

Menu for setting mode Menu for replay mode

Operation: Press Menu key, the menu for this mode will be displayed on the LCD. At this time, press

Power key to move the cursor leftward or rightward and select on the menu, and press WIFI key to

move the cursor upward or downward and select on the menu in a circulating way. Press OK key to

conﬁrm and press Menu key to return or exit from menu mode.

Description of “Slow Motion” function

Slow-Motion refers to record at normal FPS and play at lower down FPS. For example, to record a

video at 60fps, and then play the video at 30fps, you will see a slow motion.

Operation: in the menu, select and press to enter the sub-menu, move the cursor to “Slow Motion” OK

select On, then press OK to conform. You will see the following display:

Slowmotion Icon

Press the Shutter to start recording, and press Shutter again to stop;Play the slow-motion video:

Press the Power button to switch to Playback mode; select Video

Press to play the video in a slow-motion eﬀect, as shown in the right picture.OK

10 How to change the language? ,

Please press the “menu” button, and then press the “power” button, you will go into the menu for

settingmode, please press “wifi ” button and then choose the “Language” , click “ok

Description of “timelapse” function

Time Lapse function is mainly used to shoot cityscape, natural scenery, astronomical

phenomena and biological evolution. This function allows the device to take a photo ,

automatically according to the pre-set time interval, then create a video by collecting,

analyzing the processing these taken photos; the playing speed of the video is adjustable

through changing the interval of the frames (photos), thus to ﬁnally create a special video

eﬀect.

Operation:

1 In the menu, select “Timelapse” and press to enter the sub-menu, then move the cursor to select time OK

Choose folder to

ﬁnd your ﬁle

Produkt Specifikationer

Mærke:	Denver
Kategori:	Videokamera
Model:	ACG-8050W
Bredde:	59 mm
Dybde:	24 mm
Højde:	44 mm
Vægt:	- g
Produktfarve:	Sort, sølv
Opladningstid:	4 t
Batterikapacitet:	1200 mAh
Indbygget skærm:	Ja
Vægt (inkl. batteri):	100 g
Skærm diagonal:	2 "
Kompatible hukommelseskort:	MicroSD (TransFlash)
Wi-Fi:	Ja
Bluetooth:	Ingen
Batteriteknologi:	Lithium
HD-type:	Fuld HD
Understøttede videotilstande:	720p,1080p
Antal USB 2.0-porte:	1
Understøttede videoformater:	H.264,MOV
Skærm:	LCD
Kabler inkluderet:	USB
Understøttede billedformater:	JPG
Fjernbetjening inkluderet:	Ja
Near Field Communication (NFC):	Ingen
LED-indikatorer:	Activity,Charging
Batterilevetid (maks.):	1.583 t
Batteritype:	Indbygget
Understøttede mobile operativsystemer:	Android,iOS
GPS (satellit):	Ja
Lagermedie:	Hukommelseskort
Indbygget mikrofon:	Ja
Billedformat:	16:9
Sensortype:	CMOS
Maksimal billedopløsning:	4640 x 3480 pixel
Opløsning på stillbillede(r):	16MP (4640 x 3480)\n8MP (3264 x 2448)\n5MP (2582 x 1344)\n4MP (2304 x 1728)
Samlet antal megapixels:	16 MP
Maksimal videoopløsning:	1920 x 1080 pixel
Videoopløsninger:	1280 x 720,1920 x 1080 pixel
Maksimal størrelse på hukommelseskort:	32 GB
Maksimum billedhastighed:	120 fps
USB-stik type:	Micro-USB
Synsfelt vinkel (FOV):	170 °
Tidsperiode tilstand:	Ja
Flip-ud skærm:	Ingen
Videooptagelsestid:	0.483 t
Fototilstand:	Ja
Antal mini HDMI-porte:	1
Undervandsbeholder:	Ja
Undervandskabinet vandtæt op til:	45 m
Cykelbeslag:	Ja
Hjelmbeslag:	Ja
Sugekopmontering:	Ja
