Side 1/5

EnglishEnglish 1 2

DFT-506

5 inch (12.7 cm) TFT-LCD Colour TV/Monitor with memories and Remote255

Control.

FUNCTIONS AND CONTROLS

1. REMOTE SENSOR

2. A/V IN JACK

3. POWER INDICATOR

4. DC 12V IN

5. TFT-LCD SCREEN

6. EARPHONE JACK

7. SPEAKER

8. STANDBY POWER BUTTON

9. TV/AV BUTTON

10. MENU SELECTION BUTTON

11. VOLUME +/- BUTTONS

12. CHANNEL +/- SELECTION BUTTONS

13. ROD ANTENNA

14. FIXING HOLE

15. EXTERNAL ANTENNA JACK

REMOTE CONTROL

1. MUTE BUTTON

2. MODE BUTTON

3. NUMERIC KEYS

4. 1~3 DIGIT CHANNEL SELECTION

5. RECALL BUTTON

WARNINGS

The exclamation point within the triangle is a warning sign alert-

ing the user of important instructions accompanying the

product.

The lightening flash with arrowhead symbol within the triangle

is a warning sign alerting the user of “dangerous voltage” inside

the unit.

To reduce the risk of electric shock, do not remove the cover. No

user serviceable parts inside the unit. Refer all servicing to

qualified personnel.

This unit operates on 12V/230V ~ 50Hz. If the unit is not used for

a long period of time, remove the plug from the AC mains.

This unit must not be exposed to moisture or rain. During heavy

rains with lightnings unplug TV from mains.

The power switch in this unit is mounted on the secondary

circuit and does not disconnect the whole unit from the mains in

OFF position.

Ensure all connections are properly made before operating the

unit.

This unit should be positioned so that it is properly ventilated.

Avoid placing it, for example, close to curtains, on the carpet or in

a built-in installation such as a bookcase.

Do not expose this unit to direct sunlight or heat radiating sources.

EnglishEnglish 3 4

6. AUTO-TUNING BUTTON

7 .VIDEO BUTTON

8. CALENDAR BUTTON

9. OSD-LANGUAGE SELECTION BUTTON (E/G)

10. SLEEP TIMER BUTTON

11. DISPLAY BUTTON (CALL)

12. VOLUME and NAVIGATION 3 4/ BUTTONS

13. MENU BUTTON

14. CHANNEL and NAVIGATION 6/5 BUTTONS

15. POWER BUTTON

16. HORIZONTAL

17. VERTICAL

Battery Installation:

1. Open the Battery drawer by pulling it out.

2. Insert a CR2025 Lithium battery in the Battery drawer.

3. Close the Battery drawer.

Operation:

Aim the Remote Control to the Remote Sensor (1) on the unit.

Maximum operation Range: 5 m.

POWER SUPPLY

Mains operation with PowerAdapter

For use with 230V AC house current, plug the AC/DC cable of the Power Adaptor

(supplied) to the 12V IN jack (4) and the Power Adaptor to a 230V AC wall outlet.

Car battery operation

The car cigarette lighter adaptor cable (supplied) is useable with this unit for direct use in

any 12V negative ground vehicle. Simply insert the small plug of the cable into the

matching DC jack (4) on the side of the unit and the other end into the cigarette lighter of

the vehicle. The unit can operate between 11 and 15 V DC.

INSTALLING & OPERATING INSTRUCTION

1. Plug the power cord of the AC/DC adapter (included) one end to the DC 12V IN (4) on

the unit and the other end to the 230V outlet.

2. Move the POWER SWITCH (3) to ON to turn on your TV.

3. Press the POWER button on the unit (8) unit or on the remote control (15).

4. Pull out the ROD ANTENNA (13) easily and adjust the angle / heading to the best

position to receive TV signals.

5. To turn Off the unit, move the POWER SWITCH (3) to OFF or press POWER (15) button.

VOLUME ADJUSTMENT

The Volume can be adjusted directly by pressing the VOL- and VOL+ Buttons (11) on the

unit or VOL 3 4/ Buttons on the remote control (12).

MUTE FUNCTION

The Mute button (1) on the Remote Control allows the muting of the sound. When

pressed, “MUTE” appears on the display. Press Mute again to get sound again.

ON SCREEN DISPLAY LANGUAGE

Press the MENU Button (13) and then repeatedly the E/G Button (9) on the remote

control to select the language of the On Screen Display:

English > German
