10" MID-RANGE LOUDSPEAKER

ALTAVOZ DE RANGO MEDIO DE 10"

OWNER’S MANUAL

MANUAL DEL USUARIO

10XL1400-4

SPECIFICATIONS / ESPECIFICACIONES:

Nominal Diameter / Diámetro Nominal.............................................................................................. 10" / 254mm

Nominal Impedance / Impedancia Nominal .................................................................................................. 4 ohms

RMS Power Handling / Manejo de Potencia RMS...................................................................................700 watts

MAX Power Handling / Manejo de Potencia MAX.................................................................................1400 watts

Sensitivity (1w/1m) / Sensibilidad (1w /1m) ...................................................................................................98dB

Frequency Response / Respuesta de Frecuencia..................................................................................60Hz-6KHz

Recommended Hi Pass Crossover / Corte Paso Alto Recomendado.............................................................80Hz

Sold as Pair or Single / Vendido en Par o Unidad ........................................................................... Single / Unidad

MOTOR / MOTOR:

Voice Coil Diameter / Diámetro de la Bobina de Voz...........................................................................3.5" / 89mm

VC Former Material / Material Interior de Bobina de Voz............................................................................ Kapton

Winding Material / Material del Embobinado..............

CCAW (2 Layers IN/OUT)

/ (2 Capas ADENTRO/AFUERA)

Cone Material / Material del Cono ........................................................ Non-pressed Paper / Papel no prensado

Dust Cap Material / Material de la Tapa Antipolvo............................................................................ Paper / Papel

Surround Material / Material de la Suspensión .....................................................................................Cloth / Tela

Basket Material / Material de la Canasta...............................................................................Aluminum / Aluminio

Basket Color/Finish / Color/Acabado de la Canasta ...............................................Satin Black / Negro Satinado

Magnet Material / Material del Imán .............................................................................................. Ferrite / Ferrita

Magnet Weight / Peso del Imán ........................................................................................................................ 93 Oz

Displacement Volume / Volumen de Desplazamiento ................................................................1.44L / 0.051ft3

THIELE & SMALL PARAMETERS / PARÁMETROS T/S:

Equivalent Volume / Volumen Equivalente..........................Vas..................................................... 21L / 0.741ft3

Excursion / Excursión ..............................................................Xmax ..................................................................4mm

Free Air Resonance / Resonancia al Aire Libre.....................Fs .......................................................................70Hz

Mechanical Factor / Factor Mecánico ...................................Qms...................................................................3.796

Electrical Factor / Factor Eléctrico.........................................Qes ...................................................................... 0.39

Total Factor / Factor Total ......................................................Qts .....................................................................0.354

Mechanical Mass / Masa Mecánica.......................................Mms ..................................................................43.4g

Mechanical Compliance / Cumplimiento Mecánico.............Cms ..........................................................0.11mm/N

BL Factor / Factor Bl ...............................................................Bl........................................................................13.52

Voice Coil Inductance / Inductancia de Bobina de Voz........Le ...................................................................0.12mH

Cone Area / Área del Cono ......................................................Sd....................................................................363cm²

DC Resistance / Resistencia DC .............................................Re...................................................................3.6 ohm

Mechanical Mass w/o air / Mechanical Mass w/o air.........Mmd..................................................................... 50g

MEASUREMENT / MEDIDAS:

Overall Diameter / Diámetro Total ................................................................................................10.3" / 261.5mm

Overall Depth / Profundidad Total....................................................................................................4.93" / 125mm

Front Mount Baffle Cutout

Corte del Orificio de Montaje............................................................. 9.2" / 233mm

Mounting Depth / Profundidad de Montaje ...................................................................................... 4.4" / 114mm

Motor Diameter / Diámetro del Motor.............................................................................................7.48" / 190mm

10XL1400-4
