12XL1000N-8

’

ENGLISH | ESPAÑOL

MANUAL DE USUARIO

OWNER'S MANUAL

12" MID-RANGE LOUDSPEAKER

WITH NEODYMIUM MAGNET

ALTAVOZ DE RANGO MEDIO DE 12"

CON MAGNETO DE NEODINIUM

12XL1000N-8

SPECIFICATIONS / ESPECIFICACIONES:

Nominal Diameter / .............................................................................................. 12" / 305mmDiámetro Nominal

Nominal Impedance / .................................................................................................. 8 ohmsImpedancia Nominal

RMS Power Handling / .................................................................................. 500 WattsManejo de Potencia RMS

MAX Power Handling / ................................................................................ 1000 WattsManejo de Potencia MAX

Sensitivity (1w/1m) / 100dBSensibilidad (1w /1m) ................................................................................................

Frequency Response / ..................................................................................80Hz-5KHzRespuesta de Frecuencia

Recommended Hi Pass Crossover / ..........................................................100 HzCorte Paso Alto Recomendado

Sold as Pair or Single / ........................................................................... Single / Vendido en Par o Unidad Unidad

FEATURES

Demodulating Rings / .............................................................................................Yes / Anillos Demoduladores Si

Improved Heat Dissipation / ....................................................................... Yes / Disipación Térmica Mejorada Si

Cone Shape / .............................................................................................. Curvilinear / Forma Del Cono Curvilíneo

Speaker Terminals / .................................................................Push 12ga / Terminales De Altavoz Oprimir 12ga

MOTOR / MOTOR:

Voice Coil Diameter / ...........................................................................3" / 76.2mmDiámetro de la Bobina de Voz

VC Former Material / ............................................................................ KaptonMaterial Interior de Bobina de Voz

Winding Material / ................................................................................................. CCAWMaterial del Embobinado

Cone Material / ....................................................... Non-pressed Paper / Material del Cono Papel No Prensado

Dust Cap Material / ............................................................................ Paper / Material de la Tapa Antipolvo Papel

Surround Material / .....................................................................................Cloth / TelaMaterial de la Suspensión

Spider Diameter / Diámetro de la araña................................................................................................5" / 127mm

Leads Type / ................................................................................. Direct to Cone / Tipo De Rienda Directo al cono

Magnet Material / ................................................................................Neodymium / Material del Imán Neodimio

Magnet Weight / ........................................................................................................................ 11 OzPeso del Imán

Displacement Volume / ........................................................... 0.07L / 0.00247ft3Volumen de Desplazamiento

Basket Material / ...............................................................................Aluminum / Material de la Canasta Aluminio

Basket Color / .................................................................................. Satin Black /Color de la Canasta Negro Satén

THIELE & SMALL PARAMETERS / PARÁMETROS T/S:

Equivalent Volume / ..........................Vas.................................................. 75.12L / 2.65ft3Volumen Equivalente

Excursion / ..............................................................Xmax ................................................................. 7 mmExcursión

Free Air Resonance / .....................Fs ......................................................................60 HzResonancia al Aire Libre

Mechanical Factor / ...................................Qms ........................................................................5.8Factor Mecánico

Electrical Factor / .........................................Qes ...................................................................... 0.35Factor Eléctrico

Total Factor / ......................................................Qts....................................................................... 0.33Factor Total

Mechanical Mass / .......................................Mms ..................................................................44.6gMasa Mecánica

Mechanical Compliance / .............Cms ..........................................................0.19mm/NCumplimiento Mecánico

BL Factor / ..............................................................BL......................................................................... 18.7Factor BL

Voice Coil Inductance / ........Le ...................................................................0.25mHInductancia de Bobina de Voz

Cone Area / ......................................................Sd..............................................................526.85cm²Área del Cono

DC Resistance / .............................................Re...................................................................5.6 ohmResistencia DC

Mechanical Mass w/o air / ...........Mmd.................................................................... 37 gMasa Mecánica Sin Aire

MEASUREMENT / MEDIDAS:

Overall Diameter / ...................................................................................................12.3" / 312mmDiámetro Total

Overall Depth / ...................................................................................................... 5.8" / 148mmProfundidad Total

Front Mount Baffle Cutout

Corte del Orificio de Montaje...........................................................10.9" / 278mm

Mounting Depth / ...................................................................................... 5.3" / 135mmProfundidad de Montaje

Motor Diameter / .............................................................................................5.16" / 131mmDiámetro del Motor
