Side 1/4

6XL600-4

’

ENGLISH | ESPAÑOL

MANUAL DE USUARIO

OWNER'S MANUAL

6.5" MID-RANGE LOUDSPEAKER

ALTAVOZ DE RANGO MEDIO DE 6.5"

6XL600-4

SPECIFICATIONS / ESPECIFICACIONES:

Nominal Diameter / ............................................................................................ 6.5" / 165 mmDiámetro Nominal

Nominal Impedance / .................................................................................................4 OHMSImpedancia Nominal

RMS Power Handling / .................................................................................. 300 WattsManejo de Potencia RMS

MAX Power Handling / .................................................................................. 600 WattsManejo de Potencia MAX

Sensitivity (1w/1m) / ..................................................................................................97 dBSensibilidad (1w /1m)

Frequency Response / ............................................................................60Hz-12.5KHzRespuesta de Frecuencia

Recommended Hi Pass Crossover / ..........................................................100 HzCorte Paso Alto Recomendado

Sold as Pair or Single / ........................................................................... Single / Vendido en Par o Unidad Unidad

MOTOR / MOTOR:

Voice Coil Diameter / ..........................................................................2" / 50.8 mmDiámetro de la Bobina de Voz

VC Former Material / ............................................................................ KaptonMaterial Interior de Bobina de Voz

Winding Material / ................................................................................................. CCAWMaterial del Embobinado

Cone Material / ....................................................... Non-pressed Paper / Material del Cono Papel No Prensado

Dust Cap Material / ............................................................................ Paper / Material de la Tapa Antipolvo Papel

Surround Material / .....................................................................................Cloth / Material de la Suspensión Tela

Basket Material / ...............................................................................Aluminum / Material de la Canasta Aluminio

Basket Color/Finish / ....................................................Satin Black / Color/Acabado de la Canasta Satén Negro

Magnet Material / ...............................................................................................Ferrite / Material del Imán Ferrita

Magnet Weight / ........................................................................................................................34 OzPeso del Imán

Displacement Volume / ................................................................0.45L / 0.015ft3Volumen de Desplazamiento

THIELE & SMALL PARAMETERS / PARÁMETROS T/S:

Equivalent Volume / ..........................Vas..................................................5.71L / 0.201ft3Volumen Equivalente

Excursion / ..............................................................Xmax ..............................................................3.7 mmExcursión

Free Air Resonance / 100 HzResonancia al Aire Libre.....................Fs ....................................................................

Mechanical Factor / ...................................Qms..................................................................... 4.93Factor Mecánico

Electrical Factor / .........................................Qes .........................................................................0.5Factor Eléctrico

Total Factor / ......................................................Qts .....................................................................0.454Factor Total

Mechanical Mass / .......................................Mms ................................................................11.917Masa Mecánica

Mechanical Compliance / .............Cms ...................................................... 0.214 mm/NCumplimiento Mecánico

BL Factor / ...............................................................Bl........................................................................6.906Factor Bl

Voice Coil Inductance / ........Le .............................................................. 0.1647mHInductancia de Bobina de Voz

Cone Area / ......................................................Sd............................................................. 136.85 cm²Área del Cono

DC Resistance / .............................................Re...................................................................3.2 ohmResistencia DC

Mechanical Mass w/o air / .........Mmd............................................................ 10.996 gMechanical Mass w/o air

MEASUREMENT / MEDIDAS:

Overall Diameter / .................................................................................................... 6.7" / 170 mmDiámetro Total

Overall Depth / ........................................................................................................3.5" / 89 mmProfundidad Total

Front Mount Baffle Cutout

Corte del Orificio de Montaje............................................................ 5.9" / 150 mm

Mounting Depth / ..................................................................................... 3.14" / 80 mmProfundidad de Montaje

Motor Diameter / ............................................................................................4.96" / 126 mmDiámetro del Motor
