Specications
Wingspan: 65 in (1653mm)
Length: 57 in (1448mm)
Wing Area: 743 sq in (47.9 sq dm)
Weight: 9.25–10.0 lb (4.2–4.5 kg)
Wing Loading: 29–31 oz per sq ft
Radio: 6-channel w/6–7 standard servos, 2 retract servos
Engine: .60–1.20 2-stroke; .91–1.25 4-stroke; E-Power 60–90
P-51 Mustang 60 ARF
Assembly Manual
2Hangar 9 P-51 Mustang 60 ARF Assembly Manual
Table of Contents
Contents of Kit and Parts Layout ...........................................2
Included Parts Listing ............................................................3
Using the Manual ...................................................................4
Before Starting Assembly ......................................................4
Important Information Regarding Warranty Information .......4
Transmitter Requirements......................................................4
Radio Equipment Requirements - 7-Channel Receiver ..........4
Radio Equipment Requirements - 9-Channel Receiver ..........4
Optional Accessories .............................................................4
Recommended Setup–2-Stroke Glow ....................................5
Recommended Setup–4-Stroke Glow ....................................5
Recommended Setup–4-Stroke Gas ......................................5
Recommended Setup–Power 60 (EP) ...................................5
Recommended Setup–Power 90 (EP) ...................................5
Field Equipment Required ......................................................5
Optional Field Equipment .......................................................5
Additional Required Tools ......................................................5
Additional Required Adhesives ..............................................5
FS One ...................................................................................5
Hinging the Control Surfaces .................................................6
Aileron Servo Installation .....................................................10
Retract Installation ...............................................................17
Flap Servo Installation .........................................................22
Receiver, Rudder Servo and Tail Wheel Installation .............27
Elevator/Stabilizer Installation ..............................................35
Engine Installation: 4-Stroke ................................................40
Saito FG-20 Ignition Component Installation .......................45
Engine Installation: 2-Stroke ................................................46
Fuel Tank Installation ...........................................................51
Electric Motor Installation ....................................................51
Cowling and Spinner Installation - Electric Version .............53
Cowling and Spinner Installation - Glow Version .................55
Scale Accessory Installation ................................................57
Wing and Belly Pan Installation ...........................................59
Cockpit Details and Installation ............................................62
Center of Gravity ..................................................................64
Control Throws ....................................................................64
Flight Preparations ...............................................................65
Flying Your P-51 Mustang ...................................................65
Maintaining Your Model .......................................................66
Safety Do’s and Don’ts for Pilots .........................................66
Daily Flight Checks ...............................................................67
Age Requirements ...............................................................67
Safety, Precautions and Warnings .......................................67
Warranty Information ...........................................................67
CE Compliance Information for the European Union ...........69
2009 Official Academy of Model Aeronautics Safety Code ..69
Engine Mounting Template ..................................................71
Replacement Parts
1. HAN24201 Fuselage with Hatch
2. HAN24203 Left Wing Panel
3. HAN24204 Right Wing Panel
4. HAN24205 Stabilizer with Tubes
5. HAN24206 Rudder
6. HAN24207 Canopy
7. HAN24208 Cowl
8. HAN24209 Spinner, 41/4-inch (107mm)
9. HAN242010 Wing Tube
10. HAN242011 Retract Landing Gear with Axle (2)
11. HAN242013 Tailwheel Assembly
12. HAN242014 Molded Plastic Parts Bag
13. HAN242015 Printed Instrument Panel
14. HAN242017 Pushrods
15. HAN242019 45mm EP Motor Mount Set
16. HAN242020 Wing Bolt Set
17. HAN242022 31/2-inch Wheel Set
18. HAN242023 Belly Scoop and EP Air Exit
19. HAN242024 Metal Engine Mount
20. HAN242025 Fuel Tank, 420cc (14 oz)
21. HAN242026 Decal Sheet, Cripes A’Mighty
22. HAN242027 Decal Sheet, Petie 2nd (not included,
available separately)
23. HAN242028 Decal Sheet, Excalibur (not included,
available separately)
Not Shown:
HAN242012 Retract Strut Assembly (2)
HAN242016 Metal Parts Bag
HAN242018 Small Plastic Parts Bag
HAN242021 Hatch and Cowl Screws
HAN242029 P-51 Mustang Covering Set
HAN242030 20mm EP spacers for Power 90
Contents of Kit and Parts Layout
Included Pa
1
2
3
4
4
5
6
7
8
10
17
18
12
19
20
21
22
23
11
13
14
12
15 16
9
