Revision D
P/N E561347
www.EloTouch.com
Quick Installation Guide
I-Series 3 with Intel®
© 2024 Elo Touch Solutions, Inc. All rights reserved.
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Affiliates (collectively “Elo”) makes no
representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a
particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation
of Elo to notify any person of such revisions or changes.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior
written permission of Elo Touch Solutions, Inc.
Elo and the Elo logo are either trademarks or registered trademarks of Elo Touch Solutions, Inc.
Americas
Tel +1 408 597 8000
EloSales.NA@elotouch.com
Europe (EMEA)
Tel +32 16 930 136
EMEA.sales@elotouch.com
Asia Pacific
Tel +86 (21) 3329 1385
EloAsia@elotouch.com
Learn more about Elo at EloTouch.com
Kit Contents
I-Series Touchcomputer
DC Power Supply
1.8m US Power Cable
1.8m EU Power Cable
0.9m RJ50 to DB9 Serial Cable
2x Cable Tie
CFD Mounting Plate and 4x M4x20 Screw (for mounting
customer-facing display- see user manual for details)
VESA cover and 2x M3x10 Screw (for changing to other
VESA mount)
4x M4x12 Screw (VESA mount screw)
1x 100mm VESA adaptor(15.6"/15"only)
4x M4x18 Screw (VESA adaptor screw,15.6"/15"only)
EU Battery Regulation
This symbol on the battery(ies) or on the packaging indicates that the battery(ies) provided with this
product should not be treated as household waste. Instead, please separate the battery(ies) from
other types of waste and recycle them through your local recycling system to protect the environment
and health. The chemical symbol for lead (Pb) is added under this symbol if the battery(ies) contains
more than 0.004% lead. Additionally, the chemical symbol for cadmium (Cd) is added under this
symbol if the battery(ies) contains more than 0.002% cadmium.
For more detailed information about the recycling of these batteries, please contact your local
authority or the shop where you purchased the product or batteries.
