Side 1/19

A6698 / Rev.2 www.entes.com.tr

MCB-200 MULTIFUNCTION DIGITAL TIME RELAY

With 1 CO contact

Operating Manual

Dudullu OSB; 1. Cadde; No: 23 34776 Umraniye - ISTANBUL / TURKEY

Tel : Fax : +90 216 313 01 10 +90 216 314 16 15

Precautions for Installation and Safe Use

If below precautions are not properly observed and carried out, it may result in cases with injury or

death.

· Disconnect power before working on the device.

· When device is connected to the network, do not remove the front panel.

· Do not clean the device with solvent or similar items. Only clean with dry cloth.

· Verify correct terminal connections before energizing the device.

· Install the device on the electrical panel.

· Contact your authorized reseller in case problems occur with your device.

·No responsibility is assured by the manufacturer or any of its subsidiaries for any

consequences rising out of not following above precautions.

1. INTRODUCTION

MCB-200 is a multifunction digital timer with 1 CO contact. It offers wide time adjustment range

between 0.2-9999 seconds and 0.1-9999 minutes.

MCB-200 has 15 different functions with wide adjustable time ranges. The main application area is

the industrial and automation control systems. Wide supply voltage range and one output relay with

C/O contacts offer the highest flexibility for many applications.

MCB-200 has two dry contacts for START and STOP inputs

1.1 Product Features

MCB-200 has the following features:

· Lithium battery

· 15 different functions

· 0.2-9999 seconds/0.1-9999 minutes time range

· 1 relay output

· Start-Stop dry contact inputs

· Custom design LCD with green backlight

· SET, ESC, UP, DOWN buttons are located on front panel for easy programming

· Degree of protection for enclosure IP 40, for terminals IP 20

· PK25 DIN Rail mounting

1.2 Hardware Features

To operate functions with external triggering, MCB-200 has the necessary START and STOP dry contacts.

LCD

UP BUTTON

SET BUTTON

ESC BUTTON

DOWN BUTTON

Stop

Start

4 5 6

C NCNO
