Please note the following installation instructions. Because there are large differences between the
PC’s, we can give you only a general installation instructions for the EX-11081-2. Please refer your
computer’s reference manual whenever in doubt.
1. Turn off the power to your computer and any other connected peripherals.
2. Remove the mounting screws located at the rear and/or sides panels of your Computer and
gently slide the cover off.
3. Locate an available PCI-Express expansion slot and insert the card. Make sure that the card
is plugged in correctly.
4. Now install the power supply via the 4 pol molex connector. (see at Connectors at JP4)
5. Then attach the card with a screw to the rear panel of the computer.
6. Gently replace your computer’s cover and the mounting screws.
HARDWARE INSTALLATION
6 5
EX
EX
EX
-
-
-
11081
11081
11081
-
-
-
2
2
2
English
English
English
EX
EX
EX
-
-
-
11081
11081
11081
-
-
-
2
2
2
English
English
English
1
Die EX-11081-2 ist eine USB 3.0 PCI-Express Karte. Sie ist mit 1 externem und 1 internem
Port ausgestattet, die jeweils 900mA Strom zu Verfügung stellen. Sie unterstützt alle PCI-
Express Slots von p1-x1 bis x16. Der serielle PCI-Express Bus unterstützt optimal die Leistung des
schnellen Renesas Chipsatz. Die EX-11081-2 gewährleistet so eine sichere Datenübertragung
und exzellente Performance von bis zu 5Gbit/s! Es ist nicht möglich die I/O Adressen und
Interrupts manuell einzustellen, da die Einstellungen der Karte vom System (BIOS) und beim
installieren des Betriebssystems automatisch vorgenommen werden. Sie unterstützt alle USB
Anschlüsse von 1.1 bis 3.0. Die EX-11081-2 benötigt zusätzlichen Strom vom PC-Netzteil, um
die volle Leistung von 900mA an dem externen, sowie dem internen Port zu gewährleisten.
BESCHREIBUNG & TECHNISCHE DATEN
AUFBAU
Bedienungsanleitung
Bedienungsanleitung
Vers. 1.0 / 07.01.14
ANSCHLÜSSE
Renesas Chip-Set
J1:
1 x externe
USB 3.0 A-Buchse
JP4:
Anschluss für Stecker
vom PC-Netzteil
J2:
1 x interne
USB 3.0 A-Buchse
JP4:
Um die EX-11081-2 zu betreiben, muss die Karte mit dem
Stromanschluss vom PC-Netzteil verbunden werden!
Bitte auf die richtige Polarität achten!
Achtung! Stecker nie bei eingeschaltetem PC ein oder
ausstecken!
1 +12V 2 GND 3 GND 4 +5V
J1-J2:
USB 2.0 Pin‘s
Pin Signal
1 VCC
2 DATA-
3 DATA+
4 GND
USB 3.0 Pin‘s
Pin Signal
5 SSTX+
6 SSTX-
7 GND
8 SSRX+
9 SSRX-
Kompatibilität: PCI-Express p1-x1 bis p1-x16
Betriebssysteme: Windows XP/ Vista/ 7/ 8/ Server 2008 R2 & Server 2012
Anschlüsse: 1x USB A-Buchse extern, 1x USB A-Buchse intern, 1x 4 pol Molex
Lieferumfang: EX-11081-2, Treiber CD, Anleitung, LowProfile Bügel
Zertifikate:
CE
CECE
CE / FCC / RoHS / WEEE DE97424562 / WHQL
DRIVER INSTALLATION
Windows XP/ Vista/ 7/ Server 2008 R2
After starting Windows is recognizes a new “USB (Universal Serial Bus)-Controller“. Start
the „SETUP“ file which is in the “uPD720201_202” folder (see picture):
Follow the installation instructions and complete the installation.
Windows will now install automatically you right driver for your particular operating system. After
the installation the operating system detects the card and automatically install them.
CHECK INSTALLED DRIVER
Open the >Device manager<. Now you should see at „USB-Controller the following new
entry's:
If you see this or a similar information the device is installed correctly.
Windows 8 & Server 2012
After the hardware installation, the operating system will recognize the device automatically and
install the drivers.
CHECK INSTALLED DRIVER
Open the >Device manager<. Now you should see at „USB-Controllerthe following new entry's:
If you see this or a similar information the device is installed correctly.
DRIVER INSTALLATION


Produkt Specifikationer

Mærke: EXSYS
Kategori: Netværkskort/adapter
Model: EX-11081-2
Bredde: 65 mm
Dybde: 52 mm
Vægt: 120 g
Brugervejledning: Ja
Opbevaringstemperatur (T-T): -20 - 85 °C
Relativ luftfugtighed ved drift (H-H): 5 - 95 %
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: 2
Driftstemperatur (T-T): 0 - 55 °C
Understøttede Windows-operativsystemer: Ja
Understøttede Mac-operativsystemer: Ja
Understøttede Linux-operativsystemer: Ja
Værtsgrænseflade: PCIe
Intern: Ja
Drivere inkluderet: Ja
Plug and play: Ja
Output-grænseflade: USB 3.2 Gen 1 (3.1 Gen 1)
Hot-swap: Ja
Udvidelseskort standard: PCIe 2.0
Udvidelseskort formfaktor: Lavprofil
Dataoverførselshastighed (maks.): 5 Gbit/sek.
