Specifications subject to change without notice.
Copyright © 2010-2013 FLIR Systems, Inc. All rights reserved including the right of reproduction in whole or in part in any form.
www.extech.com
5/13/13 - R1
High Definition Articulating VideoScope Kit
Ordering Information:
HDV640..................High Definition Articulating VideoScope Kit (6mm diameter/1m Semi-Rigid Cable)
Video Inspector Monitor (order camera head separately from accessories listed below)
HDV600..................High Definition VideoScope (Monitor and hard carrying case only)
HDV-TX1.................6mm Articulating VideoScope Camera Head with Macro lens and 1m Semi-Rigid Cable
HDV-WTX1 .............6mm Wireless Articulating VideoScope Camera Head w/Macro lens & 1m Semi-Rigid Cable
HDV-TX2.................6mm Articulating VideoScope Camera Head w/Macro lens and 2m Semi-Rigid Cable
HDV-WTX2 .............6mm Wireless Articulating VideoScope Camera Head w/Macro lens & 2m Semi-Rigid Cable
HDV-4CAM-1FM.....4mm VideoScope Camera Head with Macro lens and 1m Flexible Cable
HDV-4CAM-5FM.....4mm VideoScope Camera Head with Macro lens and 5m Flexible Cable
HDV-5CAM-1FM.....5.5mm VideoScope Camera Head with Macro lens and 1m Flexible Cable
HDV-5CAM-3F........5.5mm VideoScope Camera Head with long depth of field and 3m Flexible Cable
HDV-5CAM-3FM.....5.5mm VideoScope Camera Head with Macro lens and 3m Flexible Cable
HDV-5CAM-30FM...5.5mm VideoScope Camera Head with Macro lens and 30m Flexible Cable
HDV-5CAM-10F......5.5mm VideoScope Camera Head with long depth of field and 10m Flexible Cable
HDV-5CAM-1R .......5.8mm VideoScope Camera Head with long depth of field and 1m Semi-Rigid Cable
HDV-5CAM-1RM ....5.8mm VideoScope Camera Head with Macro lens and 1m Semi-Rigid Cable
HDV-5CAM-3R .......5.8mm VideoScope Camera Head with long depth of field & 3m Semi-Rigid Cable
HDV-5CAM-3RM ....5.8mm VideoScope Camera Head with Macro lens and 3m Semi-Rigid Cable
HDV-25CAM-10G ...25mm VideoScope Camera Head with long depth of field and 10m Fiberglass Cable
HDV-25CAM-30G ...25mm VideoScope Camera Head with long depth of field and 30m Fiberglass Cable
HDV-WTX ...............Wireless Transmitter
HDV-PC...................Spare Patch Cable for HDV Series
ADPTR-HDV............Replacement AC Adaptor
BRD10 ....................Wireless USB Video Receiver
Specifications
Camera
Minimum Focus distance 2.36" (60mm); macro: 0.59” (15mm)
Field of View 65°
Shaft diameter 0.24" (6mm)
Working length 39" (1m)
Camera Tip bending 240° (120° left, 120° right)
Borescope
*LCD Color TFT Display 5.7" (14.5cm) size;
5.3" (13.5cm) viewable
Pixels 640 x 480 VGA pixel resolution
(320 x 240 for 4mm camera)
Frame Rate 30 fps frame rate (NTSC & PAL)
SD Card 2GB SD memory card included
(supports up to 32GB SD storage)
Operating up to 4 hours AVI video
Features:
Kit includes HDV600 VideoScope and 6mm diameter camera head with 1m
semi-rigid cable retains configured shape and 240° camera probe rotation
5.7" color LCD* TFT with high definition 640 x 480 VGA pixel resolution
Mini, high-resolution water-proof (IP57) camera head
Rugged oil/chemical resistant and water/drop proof housing (IP67/2m)
Non-slip ergonomic handles for ambidextrous use
SD memory card included to store >15,000 images
Video recording (up to 4 hours) with Voice annotation
AV output for viewing images and video directly on a monitor
Video and images can be transferred to a PC via the
SD card or USB output
6mm diameter camera with 240° articulating tip for best viewing angle
Easy one-hand operation of the articulating camera tip facilitates viewing in obstructed areas where standard camera tips cannot
access. Images and videos are viewed on the large high resolution color display and can be stored in SD memory card (included)
A
A. Articulating (6mm diameter) camera tip adjusts up to 240°
viewing angle with four built-in bright LED lights illuminate
dark areas
B. HDV-WTX — Optional Wireless Transmitter transmits
video to the main display from tight or hard to reach
places up to 100ft (30m) away
B
HDV640 kit includes:
VideoScope HDV600, SD memory card, handset with
articulating camera probe and 1m cable (Probe accessories:
magnet, 45° mirror, and anti-snag tip), 3.7V rechargable
Li-Polymer battery, patch cable, Universal AC adapter (110-
240V, four plugs), USB and AV cables, and hard carrying case
Applications:
Industrial Processing &
Manufacturing
Heavy Equipment
HVAC/Boilers
Aerospace
Government & Security
Insurance
Mining and Aggregate
Aviation AOG and FBO
Power Generation
Building Inspection &
Commissioning
PetroChem/Refineries
Infrastructure
Camera probes with cable length
greater than 3m will be coiled on
a spool as shown on the left.
