Quick Start Guide
E3981-10 VHSS Quick Reference Guide
techservice@partstown.com
techservice@partstown.com
Important safety information is presented throughout this document using the following signal words:
DANGER:
Severe injury or death will occur if you ignore the message.
WARNING:
Severe injury or death can occur if you ignore the message.
CAUTION:
Minor injury or damage to your case can occur if you ignore the message.
NOTICE:
This is important installation, operation, or service information. If you ignore the
message, you may damage your case.
This is the safety-alert symbol. When you see this symbol on your case or in the manual, be alert to the potential
for personal injury or damage to your equipment.
NOTICE
Read this manual before installing your case. Keep this manual and refer to it before doing any service on the
equipment. Failure to do so could result in personal injury or damage to the case.
NOTICE
Installation and service of the electrical components in the case must be performed by a licensed electrician. The
portions of this manual covering components contain technical instructions intended only for persons qualified to
perform electrical work.
DANGER
Improper or faulty hookup of electrical components in the case can result in severe injury or death. All electrical
wiring hookups must be done in accordance with all applicable local, regional, or national standards.
NOTICE TO EMPLOYERS
You must make sure that everyone who installs, uses, or services your case is thoroughly familiar with all safety
information and procedures.
Locating The Display Case
Avoid locating this unit next to sources of air flow and heat:
Heating ducts, grills/fryers, radiators, ceiling fans, exterior doors/entrances/exits, and other sources of moving air and/or
extreme hot/cold temperatures.
Removing Case From Shipping Skid
Be sure to leave shelf packaging material intact for this step. First remove the base front and rear panels Two or more
people should be involved in moving the unit from the pallet onto the ground. Remove the (4) 1/4” screws that secure the
case to the skid. These screws are located in the front and rear corners of the base rails. Base front and rear panels must
be removed to access these bolts.
LAG BOLT
LOCATIONS
REMOVE CASE OFF OF FRONT OR BACK OF SKID ONLY
PULL SKID AWAY FROM CASE
AND GENTLY SET CASE ON FLOOR
Once all the bolts are removed, slide the unit off the back of the shipping pallet, and tilt it so the rear corner touches the
ground. Then have someone move pallet out from under the case and gently tilt the case forward until it touches the floor.
