AMERICAN PERFORMER STRATOCASTER® HSS (11492XXXX)
Page 1 of 6
Sep 27, 2018 - PR235 - Rev. A
COPYRIGHT - 2018 - FENDER MUSICAL INSTRUMENTS CORPORATION
PARTS LAYOUT
2
8
1
27
29
14
13
10
11
11
34
33
35
4
12
38
37
36
38
37
36
18
16
15
65
9
7
4
3
19
17
16
15
19
18
19
18
15
26
21
20
19
18
9
23
22
24
25
28
14
31
30
14
32
30
AMERICAN PERFORMER STRATOCASTER® HSS (11492XXXX)
Page 2 of 6
Sep 27, 2018 - PR235 - Rev. A
COPYRIGHT - 2018 - FENDER MUSICAL INSTRUMENTS CORPORATION
REF# DESCRIPTION PART
NUMBER
1 BODY AM PERFORMER STRAT BLK 7714102506
1 BODY AM PERFORMER STRAT SFG 7714103557
1 BODY AM PERFORMER STRAT AUBERGINE 7714102545
1 BODY AM PERFORMER STRAT 3TSB 7714102500
2 NECK ASSY AM PERFORMER STRAT MPL 7714149000
2 NECK ASSY AM PERFORMER STRAT RW 7713148000
3 NECK PLATE STD SERIES LOGO NO TILT 0048691000
4 SCREW SMA 8 X 1-3/4 OHP NI 0015636049
5 TUNING KEYS MODERN VINTAGE SET 7713088000
6 WASHER KEY SET 0053106049
7 BUSHING KEY SET 0058820049
8 STRING GUIDE TREE AM STD SET W/HDWR 0994911000
9 SCREW SMAB 3 X 3/8 RHP STL NI 0011357049
10 PICKGUARD STRAT 1-HB MG/B/MG 0054021049
10 PICKGUARD STRAT 1-HB B/W/B 0992156000
10 PICKGUARD STRAT 1-HB P/B/P 0077907000
11 SCREW SMAB 4 X 1/2 OHP NI 0015578049
12 KNOB P/U SWITCH VINT AGED WHT 0994938000
13 SWITCH 5-WAY LEVER 0991367000
14 SCREW TF 6-32 X 3/4 RHP STL NI 0048631049
15 KNOBS STRAT AGED WHITE SET VOL (1) TONE (2) 0991369000
16 CONTROL 250K 10% TPR SPLIT 0990830000
17 CAPACITOR MPF RDL .022MF 250V 10% 0024832049
18 NUT HEX 3/8-32 X 3/32 TK NI 0016352049
19 WASHER LOCK INTL 3/8 X .687 0016436049
20 POT W/ LATCHING PUSH SWITCH KNURLED SHAFT 7713200000
21 PCB ASSY GREASE BUCKET TONE CIRCUIT 7713546000
22 FERRULE JACK CHROME 0991940000
23 JACK PHONE 1/4 OUTPUT 0047329049
24 BRIDGE ASSY VINTAGE NARROW CHR 0072290000
25 SCREWS WOOD RD PH 6 X 1-1/8 NI 0016170049
26 SPRING .150 OD 1/2” LONG .039” 0994931000
27 PICKUP ASSY AM PERF STRAT SHAWBUCKER 7713381000
28 SPRING HUMBUCKER MTG SHORT 0050167049
29 SCREW MACH 3-48 X 13/16 NICKEL 0051596049
NOT PICTURED IN DIAGRAM
*=
