Side 1/6
AMERICAN VINTAGE II 1961 STRATOCASTER® (0110250XXX)
Page 1 of 6
Jul 7, 2022 - PR6073 - Rev. A
COPYRIGHT - 2022 - FENDER MUSICAL INSTRUMENTS CORPORATION
PARTS LAYOUT
13
26
27
10
5
6
3
2
7
1
11
12
3
30
31
29
32 33
32 33
12
15 16
17
18 19
22
20
21
19
28
20
25
23
24
14
15
4
8 9
AMERICAN VINTAGE II 1961 STRATOCASTER® (0110250XXX)
Page 2 of 6
Jul 7, 2022 - PR6073 - Rev. A
COPYRIGHT - 2022 - FENDER MUSICAL INSTRUMENTS CORPORATION
PARTS LIST
REF# DESCRIPTION PART
NUMBER
1 BODY AM VINT II 1961 STRAT 3TS 7721667500
1 BODY AM VINT II 1961 STRAT OWT 7721666505
1 BODY AM VINT II 1961 STRAT FRD 7721666540
2 NECK ASSY AM VINT II 61 STRAT RW 7721669000
3 SCREW SMA 8 X 1-3/4 OHP NI 0015636049
4 KEY GUITAR NI FENDER LOGO SET W/HDWR 0992074000
5 BUSHING STRING POST VINT SET 0994946000
6 SCREW SMAB 3 X 3/8 RHP NI 0011357049
7 STRING TREE VINTAGE NI W/HDWR 0992083000
8 SPACER STRING TREE 62 STRAT 0020423000
9 SCREW SMA 3 X 5/8 RHP NI 0011358049
10 PICKGAURD VINTAGE 62 STRAT MG/B/MG 0991343000
11 SHIELD PICKGUARD 62 STRAT 0019699049
12 SCREW SMAB 4 X 1/2 OHP NI 0015578049
13 PICKUP ASSY AM VINT II 61 STRAT 7721671000
14 TUBING LATEX CUT .300 X 1/8ID X 1/4 OD 0994916000
15 SCREW MACH 6-32 X 5/8 OHP NI 0015776049
16 SWITCH 5-WAY LEVER 0038929049
17 KNOB P/U SWITCH VINT AGED WHT 0994938000
18 CONTROL 250K 10% TPR SPLIT 0990830000
19 WASHER LOCK INTL 3/8 X .687 0016436049
20 NUT HEX 3/8-32 X 3/32 TK NI 0016352049
21 KNOB STRAT (1) VOL (2) TONE AGED WHITE 0991369000
22 CAP CERAMIC DISC .1MFD 50V 0094393000
23 FERRULE JACK CHROME 0991940100
24 JACK PHONE OPEN CIRCUIT 11 0021956049
25 SCREW SMA 5 X 5/8 OHP NI 0015602049
26 BRIDGE ASSY AM VINT STRAT CHR 0094247049
26A BRIDGE PLATE VINT STRAT 0019470000
26B BRIDGE BLOCK VINT STRAT 0019473049
26C SCREW MACH 8-32 X 3/8 FHP NI 0019656049
26D BRIDGE SADDLES SHORT/TALL SET W/HDWR 0992091000
26E SCREW MACH 4-40 X 5/8 RHP NI 0015693049
NOT PICTURED IN DIAGRAM
*=
