Side 1/6

OPERATION AND MAINTENANCE MANUAL

RONDO’ gas cooker hobs

cod. 7052 142, 7052 642

Foster spa - via M.S. Ottone, 18/20 - 42041 Brescello (RE) Italy - www.fosterspa.com

tel. +39.0522.687425 - tel. Servizio Assistenza +39.0522.684450

fax +39.0522.686019 - fax Servizio Ricambi +39.0522.962166 e-mail: service@fosterspa.com

INSTALLATION INSTRUCTIONS

Installation

The purchaser is responsible for installation: the Manufacturer does not offer this service. Any technical assistance

activities carried out by the Manufacturer relating to faulty installation are not covered by the warranty.

The built-in hobs are designed for installation on worktops made of any material, provided these are between 25

mm and 40 mm thick and can withstand temperatures of 100°C. If the hob is installed adjacent to a cabinet on any

one of the two sides, at least 150 mm must divide the hob edge from the cabinet, while the distance between the

rear wall and hob edge must be at least 50 mm. A partition made of insulating material (wood or similar) must be

inserted in the underlying cabinet at least 20 mm from the bottom edge of the hob.

Securing the hob to the cabinet

The hob is secured to the cabinet with the aid of clamps supplied as accessories. The underside of the hob

contains pre-drilled holes through which the self-tapping plates (A) must be inserted; the relative screws (C) that

secure the fixing clamps (B) must then be screwed onto the plates.

TECHNICAL DATA

MODELS

Burners

Automatic

ignition

Safety

valve

Product dimensions

(W x D) in mm

Cut-out dimensions

(W x D) in mm

yes

Ø 520

Ø 500

Produkt Specifikationer

Mærke:	Foster
Kategori:	Komfur
Model:	Rondò Kristal Black.3F.STD
Bredde:	520 mm
Dybde:	520 mm
Højde:	- mm
Produktfarve:	Sort
Kontroltype:	Dreje
Indbygget skærm:	Ingen
Placering af apparat:	Indbygget
Installationsrum bredde:	500 mm
Installationsrum dybde:	500 mm
Installationsrum højde:	40 mm
Komfurtype:	Gaskomfur
Overfladetype:	Keramisk
Antal kogeplader / madlavningsområde:	3
Blus/kogeplade zone 1 strøm:	1750 W
Blus/kogeplade zone 2 strøm:	2700 W
Blus/kogeplade zone 1 type:	Regelmæssig
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre front
Blus/kogeplade zone 1 strømkilde:	Gas
Blus/kogeplade zone 2 type:	Stor
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Midt bagende
Blus/kogeplade zone 2 strømkilde:	Gas
Kontrolposition:	Top forside
Blus/kogeplade zone 3 type:	Simre
Blus/kogeplade zone 3 strømkilde:	Gas
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Højre forside
Tilsluttet belastning (gas):	5750 W
Antal gasbrændere:	3
Blus/kogeplade zone 3 strøm:	1000 W
Elektronisk tænding:	Ja
Simre kogeplade / madlavningsområde:	1000 W
Almindelige kogeplade / madlavningsområde:	1750 W
Stor kogeplade / madlavningsområde:	3000 W
Understøttet grydemateriale:	Støbejern
Tændblussikring:	Ja
