Side 1/16

PART No. 9379069274-05

INSTALLATION MANUAL

OUTDOOR UNIT (3 Phase Type)

For authorized service personnel only.

INSTALLATIONSANLEITUNG

AUSSENGERÄT (3-Phasen-Typ)

Nur für autorisiertes Fachpersonal.

MANUEL D’INSTALLATION

APPAREIL EXTÉRIEUR (type 3 phases)

Pour le personnel d’entretien autorisé uniquement.

MANUAL DE INSTALACIÓN

UNIDAD EXTERIOR (Tipo trifásico)

Únicamente para personal de servicio autorizado.

MANUALE DI INSTALLAZIONE

UNITÀ ESTERNA (tipo a 3 fasi)

A uso esclusivo del personale tecnico autorizzato.

ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ

ΕΞΩΤΕΡΙΚΗ ΜΟΝΑΔΑ (Τριφασικού Τύπου)

Μόνο για εξουσιοδοτημένο τεχνικό προσωπικό.

MANUAL DE INSTALAÇÃO

UNIDADE EXTERIOR (Tipo trifásica)

Apenas para pessoal de assistência autorizado.

РУКОВОДСТВО ПО УСТАНОВКЕ

ВНЕШНИЙ МОДУЛЬ (3-фазного типа)

Только для авторизованного обслуживающего персонала.

MONTAJ KILAVUZU

DIŞ ÜNİTE (3 Faz Tipi)

Yalnızca yetkili servis personeli için.

AIR CONDITIONER

Português EλληvIkά Italiano Español Français EnglishDeutsch

Русский

Türkçe

En-2

WARNING

Do not use this equipment with air or any other unspecied refrigerant in the refrigerant

lines.

Excess pressure can cause a rupture.

During installation, make sure that the refrigerant pipe is attached rmly before you run

the compressor.

Do not operate the compressor under the condition of refrigerant piping not attached

properly with 2-way or 3-way valve open. This may cause abnormal pressure in the

refrigeration cycle that leads to rupture and even injury.

When installing and relocating the air conditioner, do not mix gases other than the

specied refrigerant (R410A) to enter the refrigerant cycle.

If air or other gas enters the refrigerant cycle, the pressure inside the cycle will rise to

an abnormally high value and cause rupture, injury, etc.

For the air conditioner to operate satisfactorily, install it as outlined in this installation

manual.

Connect the indoor unit and outdoor unit with the air conditioner piping and cable

available standards parts.

This installation manual describes the correct connections using the installation set

available from our standard parts.

Also, do not use an extension cable.

Do not purge the air with refrigerants but use a vacuum pump to vacuum the installation.

There is not extra refrigerant in the outdoor unit for air purging.

Use a vacuum pump for R410A exclusively.

Using the same vacuum pump for different refrigerants may damage the vacuum pump

or the unit.

Use a clean gauge manifold and charging hose for R410A exclusively.

During the pump-down operation, make sure that the compressor is turned off before

you remove the refrigerant piping.

Do not remove the connection pipe while the compressor is in operation with 2 way or

3 way valve open. This may cause abnormal pressure in the refrigeration cycle that

leads to rupture and even injury.

CAUTION

Read carefully all security information before use or install the air conditioner.

Do not attempt to install the air conditioner or a part of the air conditioner by yourself.

This unit must be installed by qualied personnel with a capacity certicate for handling

refrigerant uids. Refer to regulation and laws in use on installation place.

The installation must be carried out in compliance with regulations in force in the place

of installation and the installation instructions of the manufacturer.

This unit is part of a set constituting an air conditioner. It must not be installed alone or

with non-authorized by the manufacturer.

Always use a separate power supply line protected by a circuit breaker operating on all

wires with a distance between contact of 3mm for this unit.

The unit must be correctly earthed (grounded) and the supply line must be equipped

with a differential breaker in order to protect the persons.

The units are not explosion proof and therefore should not be installed in explosive atmosphere.

This unit contains no user-serviceable parts. Always consult authorized service

personnel to repairs.

When moving, consult authorized service personnel for disconnection and installation of

the unit.

Children should be monitored to ensure they do not play with the device.

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be supervised to ensure that they do

not play with the appliance.

Do not touch the aluminum ns of heat exchanger built-in the indoor or outdoor unit to

avoid personal injury when you install or maintain the unit.

Do not place any other electrical products or household belongings under indoor unit or

outdoor unit. Dripping condensation from the unit might get them wet, and may cause

damage or malfunction of your property.

2. ABOUT THE UNIT

2.1. Precautions for using R410A refrigerant

WARNING

Do not introduce any substance other than the prescribed refrigerant into the

refrigeration cycle. If air enters the refrigeration cycle, the pressure in the refrigeration

cycle will become abnormally high and cause the piping to rupture.

If there is a refrigerant leak, make sure that it does not exceed the concentration limit.

If a refrigerant leak exceeds the concentration limit, it can lead to accidents such as

oxygen starvation.

Contents

1. SAFETY PRECAUTIONS ............................................................................................ 2

2. ABOUT THE UNIT

2.1. Precautions for using R410A refrigerant ............................................................ 2

2.2. Special tools for R410A ...................................................................................... 3

2.3. Accessories ........................................................................................................3

3. INSTALLATION WORK

3.1. Selecting an installation location ........................................................................ 3

3.2. Drain installation ................................................................................................. 4

3.3. Installation dimensions .......................................................................................4

3.4. Transporting the unit .......................................................................................... 5

3.5. Installation .......................................................................................................... 5

4. PIPE SELECTION

4.1. Selecting the pipe material .................................................................................5

4.2. Protection of pipes .............................................................................................5

4.3. Refrigerant pipe size and allowable piping length ..............................................5

4.4. Connectable pipe diameter and max. piping length ...........................................6

5. PIPE INSTALLATION-1

5.1. Opening a knock out hole ..................................................................................7

5.2. Brazing ............................................................................................................... 7

5.3. Indoor unit pipe connections .............................................................................. 7

5.4. Flare connection (pipe connection) .................................................................... 7

5.5. Sealing test ........................................................................................................8

5.6. Vacuum process ................................................................................................8

5.7. Additional charging ............................................................................................. 9

6. ELECTRICAL WIRING

6.1. Notes for electrical wiring ................................................................................. 01

6.2. Selecting circuit breaker and wiring 11 .................................................................

6.3. Knock out holes for wiring ................................................................................ 11

6.4. Wiring method .................................................................................................. 11

7. PIPE INSTALLATION-2

7.1. Installing insulation ........................................................................................... 21

7.2. Filling with putty ................................................................................................ 21

8. HOW TO OPERATE DISPLAY UNIT

8.1. Various setting methods ................................................................................... 21

8.2. Description of display ....................................................................................... 31

9. LOCAL SETTING

9.1. Low noise mode (Local work) 1 .......................................................................... 3

9.2. Peak cut mode (Local work) ............................................................................. 41

10. TEST RUN

10.1. Check items before performing the test run ..................................................... 41

10.2. Test run method ............................................................................................... 41

11. PUMP DOWN

11.1. Preparation for pump down .............................................................................. 51

11.2. Pump down procedure ..................................................................................... 51

12. ERROR CODE DISPLAY

12.1. How to check error code .................................................................................. 61

12.2. Error code check table ..................................................................................... 61

1. SAFETY PRECAUTIONS

Be sure to read this manual carefully before installation.•

The warnings and precautions indicated in this manual contain important information •

pertaining to your safety. Be sure to observe them.

Hand this manual, together with the operating manual, to the customer. Request the •

customer to keep them on hand for future use, such as for relocating or repairing the

unit.

WARNING This mark indicates procedures which, if improperly performed,

might lead to the death or serious injury of the user.

CAUTION

This mark indicates procedures which, if improperly performed, might

possibly result in personal harm to the user, or damage to property.

WARNING

Never touch electrical components immediately after the power supply has been turned

off. Electrical shock may occur. After turning off the power, always wait 10 minutes or

more before touching electrical components.

Request your dealer or a professional installer to install the outdoor unit in accordance

with this installation manual. an improperly installed unit can cause serious accidents

such as water leakage, electric shock, or re.

If the outdoor unit is installed in disregard of the instructions in the installation manual, it

will void the manufacturer’s warranty.

Do not turn ON the power until all work has been completed. Turning ON the power

before the work is completed can cause serious accidents such as electric shock or re.

If refrigerant leaks while work is being carried out, ventilate the area. If the refrigerant

comes in contact with a ame, it produces a toxic gas.

Installation work must be performed in accordance with national wiring standards by

authorized personnel only.

INSTALLATION MANUAL

OUTDOOR UNIT (3 Phase Type)

PART No. 9379069274-05 English
