Side 1/12

MW-C

WALL MOUNT

ADAPTER

For MD-ASL15W and MD-BSL15W Monitor Mounts

User Manual

WWW.MADEBYGABOR.COM

FORWARD YOUR PROOFS

to mabel.li@asia.bhphotovideo.com

FOR APPROVAL

BEFORE FINAL PRODUCTION

DO NOT BEGIN PRODUCTION

WITHOUT PRIOR APPROVAL OF PROOFS

Manual for Wall Mount Adapter

Matte Printing

Folding

Instructions

DO NOT EDIT OR REVISE ARTWORK

We will not approve any artwork which has been altered by the vendor

Thank you for

choosing Gabor.

The Gabor MW-C is a dedicated wall mount for the MD-ASL15W (single display) and

MD-BSL15W (dual display) monitor mounts, replacing the center column and desk clamp to

offer an alternative mounting option. It’s perfect for cramped spaces or desk edges that are

too thick to accommodate a desk clamp. The MW-C frees up valuable desk space and enables

personalized monitor placement for improved safety and comfort over conventional

monitor stands.

Customer Support

ONE-YEAR LIMITED WARRANTY

This GABOR product is warranted to the original purchaser to be free from defects in materials and

workmanship under normal consumer use for a period of one (1) year from the original purchase

date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s

responsibility with respect to this limited warranty shall be limited solely to repair or replacement,

at the provider’s discretion, of any product that fails during normal use of this product in its

intended manner and in its intended environment. Inoperability of the product or part(s) shall be

determined by the warranty provider. If the product has been discontinued, the warranty provider

reserves the right to replace it with a model of equivalent quality and function.

This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration,

abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY

PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES,

INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may

also have additional rights that vary from state to state.

To obtain warranty coverage, contact the Gabor Customer Service Department to obtain a return

merchandise authorization (“RMA”) number, and return the defective product to Gabor along with

the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s

own risk and expense.

Attaching Your Monitor to the VESA Mounts

Important! Before mounting the MW-C Wall Mount Adapter, make sure your wall can support the

combined weight of your monitor(s) and the mounting assembly.

Decide where you want to mount your monitor. It should be directly in front of you, at eye level, and

approximately at an arm’s length away. You shouldn’t need to turn your head to look at your monitor.

If you have to strain to look at it, readjust its position. When using a dual-monitor setup, position your

primary monitor directly in front of you, and your secondary monitor to the side.

1. Hold the wall plate against the wall at the desired

mounting location and use the included bubble level

to make sure the plate is level.

2. Use a pencil to mark the mounting holes on the wall,

and then remove the plate from the wall. Use the top

and bottom (larger) holes in the triangular (top)

recess and the middle hole of the bottom recess.

3. Drill holes through the pencil marks and fully insert

the included screw anchors into the holes.

4. Hold the wall plate against the wall and align the

mounting holes with the anchors.

5. Use a Phillips-head power screwdriver to tighten the

included M6×50 wall screws into the anchors until

the plate is securely fastened to the wall.

KOPUL

A Gradus Group Brand

KOPUL

A Gradus Group Brand

For more information or to

arrange service, visit

www.madebygabor.com

or call Customer Service at

212-594-2353.

Product warranty is provided by the

Gradus Group. www.gradusgroup.com

Gabor is a registered trademark of the

GG1

Safety Warnings

Please read and follow these instructions

and keep this manual in a safe place.

Clean this product with only a soft, dry cloth.

Keep this product away from children.

Use only parts provided by the

manufacturer.

Make sure everything is secure before

proceeding.

Do not exceed the maximum load capacity.

Make sure your wall can support the combined

weight of your monitor and the mounting

assembly.

Mounting surfaces should be sturdy and ﬂat.

Do not install this product on a weak, uneven

surface.

All photos are for illustrative purposes only.

M6 M8 Caps Bubble Level

x1 set

A (3) M6 × 50 wall screws

B (1) M6 × 25 screw

C (3) M8 × 40 screw anchors

E Mounting peg cap

F Bubble level

G User manual

D (2) Protective caps (1 set)

Also IncludedWall plate

Product Speciﬁcations

Compatibility:

Gabor MD-ASL15W and

MD-BSL15W Monitor

Mounts

Maximum load capacity:

17.6 lb. (8 kg)

Dimensions (H × W × D):

6.6″ × 2.7″ × 2.6″

(16.8 × 6.9 × 6.6 cm)

Weight: 8.8 oz. (249 g)

6. Insert the included protective caps into the plate with

the triangular cap attaching to the middle hole of the

top recess and the other cap fitting into the holes at

each end of the bottom recess.

Attaching Your Gabor Monitor Mount

1. Mount your compatible Gabor monitor mount onto the

MW-C’s mounting peg.

2. Insert your monitor cable(s) into the cable guides on

the underside of the mounting arm(s). If you are using

the MD-BSL15W Dual-Display Mount, you have

completed the mounting instructions and can stop here.

If you are using the MD-ASL15W single-arm mount,

continue below.

3. Insert the included M6×25 screw through

the bottom of the mounting peg, and hold

the screw in place so it protrudes from the

screw hole.

4. Thread the included mounting peg cap onto

the screw as much as possible, and then push

the cap into the socket.

5. Use a short Phillips-head screwdriver to

fasten the screw until fully tightened.
