Side 1/2

Case Layout and Parts Identification Case Layout and Parts Identification

Micro-Tower PC Case

MARS

E4M 1. Front Panel

2. IO Port Module

3. Right Side Panel

4. Left Side Panel

5. PCIe Slots

6. Power Supply Unit Mounting Hole

7. Rear Fan

8. Motherboard Placement

9. Motherboard Mounting Holes

10. Chassis Pedestals

1. General Safety Warnings

Always ensure the computer case is placed on a stable, flat surface to prevent it from tipping over.

Keep the case away from water, moisture, or high humidity environments to avoid electrical hazards.

Do not block or obstruct the ventilation openings to ensure proper airflow and prevent overheating.

2. Electrical Safety

Disconnect the power supply before installing or modifying any internal components.

Avoid touching internal components directly; always ground yourself to prevent static discharge, which can

damage sensitive components.

Use only compatible power supplies and cables, ensuring that all connections are secure and free from

fraying or damage.

3. Handling Precautions

Handle the computer case with care during transportation to prevent physical damage.

Use appropriate tools when assembling or disassembling components inside the case to avoid injury.

Do not force components into place; ensure they align properly before securing them.

4. Fire Hazard Warnings

Ensure all components are properly ventilated and not overheating, as this can be a potential fire hazard.

Avoid overloading electrical circuits connected to the computer case to prevent overheating and potential

fire risks.

Keep flammable materials away from the computer case.

5. Child Safety

Keep the computer case and its components out of reach of children.

Do not allow children to play with or operate the computer case, especially when it is powered on.

6. Cleaning and Maintenance

Unplug the computer case from the power source before cleaning.

Use a dry, soft cloth for cleaning the exterior of the case. Do not use liquid cleaners or aerosols.

Periodically check and clean the ventilation openings to ensure proper airflow.

7. Installation Safety

Ensure that all components are installed correctly and securely before powering on the system.

Double-check connections and screws to prevent potential hazards during operation.

Follow the manufacturer's guidelines for component installation and ensure compatibility with the case.

8. Disposal Instructions

Dispose of the computer case and its components according to local electronic waste regulations.

Safety Information Package Contents

Specification

1. Gaming Case : MARS E4M

2. Chassis Protection : Styrofoam

1. Case Type: Micro Tower

2. Motherboard Support: Micro-ATX, Mini-ITX

3. Expansion Slots: 4

4. Material: SPCC, ABS

5. Product Dimension : 320 x 170 x 360 mm(12.6 x 6.7 x 12.1 inch)

6. Chassis Dimension : 290 x 170 x 350mm(11.4 x 6.7 x 13.9 inch)

7. Radiator Support : No

8. Fan Support : Rear: 1 x 80mm

9. Motherboard Sync : No

10. Drive Bays : 1 x 2.5" or 1 x 3.5"(Chassis Bottom)

11. Clearence : CPU cooler height limitation: 150mm VGA length limitation: 260mm PSU length limitation: 160mm、、

01 Place the standoffs in the appropriate

positions for your motherboard size. 02 Align the motherboard with the standoffs and

secure it with screws. 01

Slide the PSU into the bottom compartment. 02

Secure the PSU with screws and connect the

power cables to the motherboard.

Front I/O cables

GPU Installation GPU Installation

HDD Installation SSD Installation Other Supports

Troubleshooting and Maintenance

•Regularly clean the dust filters and fans to maintain airflow.

•Check all connections if the system is not powering on.

Warranty and Support Information

•Provide details on the warranty period and how to contact support for assistance

HD Audio

Power Switch

USB 3.0

Motherboard

01 02 01 02

Identify the appropriate drive bay in your case

for the hard drive.

01 02 03

Identify the PCI-E x16 slot on the motherboard, usually the largest slot, closest to the CPU.

Align the graphics card s connector with the PCI-E slot and gently press down until the card is firmly seated in the slot. ’

Secure the card to the case with screws

Attach the grouped cables to the case s cable management points. Ensure that the cables are not obstructing any ’

airflow or components

Use additional zip ties or Velcro straps to secure any loose or excess cables. You can also use cable management
