Installation Instructions

Built-In Dishwasher

If you have questions, call GE Appliances at 800.GE.CARES (800.432.2737) or visit our website

at: GEAppliances.com. In Canada, please call 1.800.561.3344 or visit www.geappliances.ca

READ CAREFULLY

KEEP THESE INSTRUCTIONS

FOR YOUR SAFETY

Read and observe all WARNINGS and CAUTIONS

shown throughout these instructions.

While performing installations described in this booklet,

gloves, safety glasses or goggles should be worn.

IMPORTANT – Observe all governing codes and ordinances.

• Note to Installer – Be sure to leave these instructions for

the consumer’s and local inspector’s use.

• Note to Consumer – Keep these instructions with your

Owner’s Manual for future reference.

• Skill Level – Installation of this dishwasher requires

basic mechanical, electrical and plumbing skills. Proper

installation is the responsibility of the installer. Product

failure due to improper installation is not covered under

the GE Appliances Warranty. See warranty information.

• Completion Time – 1 to 3 Hours. New installations

require more time than replacement installations.

IMPORTANT – The dishwasher MUST be installed to

allow

for future removal from the enclosure if service is required.

Care should be exercised when the appliance is installed or

removed,

to reduce the likelihood of damage to the power

supply cord.

If you received a damaged dishwasher, you should

immediately contact your dealer or builder.

Optional Accessories – See the Owner’s Manual for

available custom panel kits.

Your dishwasher is a water heating appliance.

BEFORE YOU BEGIN

Read these instructions completely and

carefully.

31-31560-1 09-16 GEA

• To reduce the risk of electric shock, re, or injury to

persons, the installer must ensure that the dishwasher

is completely enclosed at the time of installation.

• FOR PERSONAL SAFETY: Remove house fuse or open

circuit breaker before beginning installation. Do not use

an extension cord or adapter plug with this appliance.

• The improper connection of the equipment grounding

conductor can result in a risk of electric shock. Check

with a qualified electrician or service representative if

you are in doubt that the appliance is properly grounded.

• If house wiring is not 2-wire with ground, a ground

must be provided by the installer. When house wiring

is aluminum, be sure to use UL-Listed anti-oxidant

compound and aluminum-to-copper connectors.

Do not remove wood base until you are ready to install

the dishwasher. The dishwasher will tip over when the

door is opened if base is removed.

CHECK THE FOLLOWING

 Tub trim does not interfere with the door

 Dishwasher is square and level at both the top and

bottom of the cabinet opening, with no twisting or

distortion of the tub or door

 All 4 legs of the dishwasher are firmly in contact with the

floor

 Drain hose is not pinched between the dishwasher and

adjacent cabinets or walls

 Tub trim is fully seated on the tub flange

WARNING

CAUTION

PARTS SUPPLIED IN

INSTALLATION PACKAGE:

• Junction box cover and #10 hex-head screw

• Hose clamp

• Drain hose (approximately 58” long)

• Drain hose hanger

• 2 #8-18 hex head screws to secure brackets to

washer tub frame

• 1 top trim piece (on some models)

• 2 side trim pieces

• 2 mounting brackets for wood countertops

or side cabinets

• 2 #8-18 x 5/8” Phillips special head screws,

to secure dishwasher to underside of

countertop or to side cabinets

• Plug buttons

• Literature, samples and/or coupons

TOOLS YOU WILL NEED:

• Phillips-head screwdriver

• 1/4” and 5/16” nutdriver

• 6” Adjustable wrench

• Level

• Carpenter’s square

• Measuring tape

• Safety glasses

• Flashlight

• Bucket to catch water when flushing the line

• 15/16” socket (optional for skid removal)

• Gloves

• Pliers

For New Installations Only:

• Tubing cutter

• Drill and appropriate bits

• Hole saw set

MATERIALS YOU WILL NEED:

• 90° elbow (3/4”hose internal thread on one

end,opposite end sized to fit water supply)

• UL-listed wire nuts (3)

• Masking Tape

Materials For New Installations Only:

• Air gap for drain hose, if required

• Waste tee for house plumbing, if applicable

• Electrical cable or Power Cord Kit WX09X70910 (5.4 Ft)

or WX09X70911 (7.9 ft) depending on your installation.

• Screw-type hose clamps

• Strain relief for electrical connection

• Hand shut-off valve (recommended)

• Hot Water Line–3/8” minimum, copper tubing

(including ferrule, compression nut) or GE Appliances

Part # WX28X326, flexible braided hose.

• WD24X10065 drain hose (12’ long), if needed.

Installation Preparation

Hole Saw Set

Measuring Tape

Tubing Cutter

Drill and Bits

Phillips-Head

Screwdriver

15/16” Socket

1/4” and 5/16”

Nutdriver

6” Adjustable

Wrench

Bucket

Flashlight

Gloves

Carpenter’s

Square

Safety Glasses

Level

Drain Hose

Hose Clamp

#8 Hex-Head

Mounting Bracket

Screws

Drain Hose Hanger

Junction

Box Cover

#10

Hex-Head

Junction

Box Screw

1/2" long

Mounting

Brackets

#8 Phillips

Special

Head Screws

5/8" long Literature

Top Trim Piece

(on some models)

Side Trim Pieces

Pliers

Hot Water Line

Strain Relief

Optional

12' Drain Hose

WD24X10065

Hose Clamps

Waste Tee

Electrical Cable

(or Power Cord,

if applicable)

Wire Nuts (3)

90°Elbow

Hand

Shut-Off

Valve

Air Gap

Coupler for

optional

drain hose

Plug Buttons

Masking Tape
